01 Safety 02 Instruments and controls Important information......... 8 Seatbelts........... 16 Overview, left-hand drive cars....40 Volvo and the environment....... 11 Airbag system........... 19 Overview, right-hand drive cars....42 Airbags (SRS)..........20 Driver's door control panel....... 44 Activating/deactivating the airbag (SRS)*. 23 Combined instrument panel......
Page 4 Table of contents 03 Climate control 04 Interior 05 Locks and alarm General information on climate control..78 Front seats..........90 Remote control key with key blade..112 Electronic climate control, ECC*....80 Electrically operated roof ......95 Privacy locking*........115 Air distribution...........
Page 5 Table of contents 06 Starting and driving 07 Wheels and tyres 08 Car care General............ 132 General............ 172 Cleaning..........190 Refuelling..........134 Tyre pressure.......... 176 Touching up paintwork......194 Starting the engine........136 Warning triangle* and spare wheel* ..179 Rustproofing...........
Page 6 Table of contents 09 Maintenance and service 10 Infotainment system 11 Specifications Volvo service........... 198 General............ 226 Type designation........258 Self-maintenance........199 Audio functions........228 Dimensions and weights......261 Bonnet and engine compartment... 200 Radio functions........232 Engine specifications......264 Oils and fluids.........
Page 7: Table Of Contents
Table of contents 12 Alphabetical Index Alphabetical Index........280...
Page 8 Table of contents...
Page 9: Introduction
Volvo dealer. are designed to convey important information IMPORTANT Volvo cars are adapted for the varying require- in a simple and clear manner. The decals in the Important texts advise of a risk of material...
Page 10 Introduction Important information Warning for personal injury Risk of property damage Information Black ISO symbols on yellow warning field, White ISO symbols and white text/image on White ISO symbols and white text/image on white text/image on black message field. Used black or blue warning field and message field.
Page 11 The driving and safety systems in the car use an authorised Volvo workshop before installing Arrows appear numbered and unnum- computers which check and share information accessories which are connected to or affect bered and are used to illustrate a move- with each other on the car's function.
Page 12: Volvo And The Environment
Introduction Volvo and the environment Volvo Cars' environmental philosophy Environmental care is one of Volvo Car Corpo- many cases the exhaust emissions are well Fuel consumption ration's core values which influence all opera- below the applicable standards. Volvo cars have competitive fuel consumption tions.
Page 13 Textile standard You can easily help reduce environmental to local regulations. Switch off the engine The interior of a Volvo is designed to be plea- impact, for example, by driving economically when stationary for longer periods. sant and comfortable, even for people with and by servicing and maintaining the car •...
Page 14 Introduction Volvo and the environment The owner's manual and the environment The FSC symbol shows that the paper pulp in this publication comes from FSC certified for- ests or other controlled sources.
Page 15 Seatbelts....................16 Airbag system..................19 Airbags (SRS)..................20 Activating/deactivating the airbag (SRS)*..........23 Side airbags (SIPS bags)................ 25 Inflatable Curtain (DMIC)................. 27 WHIPS..................... 28 Roll-Over Protection System (ROPS)............30 When the systems deploy............... 31 Crash mode.................... 33 Child safety..................... 34 Option/accessory, for more information, see Introduction.
Page 16 S A F E T Y...
Page 17: 01 Safety
The seatbelt locks and cannot be withdrawn: Never modify or repair the seatbelt yourself. • if it is pulled out too quickly. Volvo recommends that you contact an • during braking and acceleration. authorised Volvo workshop. If the seatbelt has been subjected to a major load, such as •...
Page 18 01 Safety Seatbelts Seatbelts and pregnancy vehicle as they drive (which means that they Rear seat must be able to easily operate the foot pedals The seatbelt reminder in the rear seat has two and steering wheel). They should strive to posi- subfunctions: tion the seat with as large a distance as possi- •...
Page 19 01 Safety Seatbelts Seatbelt tensioner on the seatbelt bar. Refit the seatbelt into the seatbelt guide afterwards. All the seatbelts are equipped with seatbelt tensioners. A mechanism in the seatbelt ten- sioner tightens the seatbelt in the event of a sufficiently violent collision.
Page 20: Airbag System
The airbag system is continually monitored by tem, SIPS, SRS or the IC system. Volvo rec- the system's control module. The warning ommends that you contact an authorised symbol in the combined instrument panel illu- Volvo workshop immediately.
Page 21: Airbags (Srs)
01 Safety Airbags (SRS) Airbag system WARNING NOTE Volvo recommends that you contact an The sensors react differently depending on authorised Volvo workshop for repair. the course of the collision and whether or Defective work in the airbag system could...
Page 22 01 Safety Airbags (SRS) Airbag (SRS) on the driver's side Passenger airbag (SRS) Location of the passenger airbag in left-hand drive and right-hand drive cars. The car has an SRS airbag (Supplemental The car has an airbag to supplement the pro- Restraint System) to supplement the protec- tection afforded by the seatbelt on the passen- WARNING...
Page 23 01 Safety Airbags (SRS) WARNING Never place a child in a child seat or on a booster cushion in the front seat if the airbag (SRS) is activated. Never allow a child to stand or sit in front of the front passenger seat. Children under 140 cm must never sit in the front passenger seat if the airbag (SRS) is activated.
Page 24: Activating/Deactivating The Airbag (Srs)
Switch location. Volvo recommends that you visit an author- ised Volvo workshop as soon as possible. The airbag is activated. With the switch in For information on the key blade, see this position, children taller than 140 cm page 113.
Page 25 01 Safety Activating/deactivating the airbag (SRS)* A text message and a symbol in the roof panel WARNING NOTE indicate that the airbag (SRS) for the front pas- Activated airbag (passenger seat): When the remote control key is turned to senger seat is deactivated (see preceding illus- ignition position II or III the warning symbol tration).
Page 26: Side Airbags (Sips Bags)
• Volvo recommends the use only of car seat covers approved by Volvo. Other seat covers may impede the operation of the side airbags.
Page 27: Side Airbags (Sips Bags)
01 Safety Side airbags (SIPS bags) Label, side airbag Front passenger seat, left-hand drive. Location of decal for side airbag, driver's side, The SIPS bag system consists of side airbags front, left-hand drive car. and sensors. A sufficiently violent collision trips the sensors and the side airbags are inflated.
Page 28: Inflatable Curtain (Dmic)
It is fitted along the inside of the driv- compromise the intended protection. Volvo er's and passenger doors and protects both recommends that you only ever use Volvo front seat occupants. The inflatable curtain is genuine parts that are approved for place- activated by sensors in the event of a suffi- ment in these areas.
Page 29: Whips
Never modify or repair the seat or WHIPS the seat with as little space as possible The WHIPS system is a supplement to the system yourself. Volvo recommends that between the head and the head restraint. seatbelts. Always use a seatbelt. you contact an authorised Volvo workshop.
Page 30 WARNING If a seat has been subjected to extreme forces, such as due to a rear-end collision, the WHIPS system must be checked. Volvo recommends that it is checked by an authorised Volvo workshop. Part of the WHIPS system's protective capacity may have been lost even if the seats appear to be undamaged.
Page 31: Roll-Over Protection System (Rops)
The roll bars are deployed irrespective of whether the roof is open or closed. Volvo recommends that you always contact an authorised Volvo workshop if the ROPS system has deployed.
Page 32: When The Systems Deploy
Recovering the car. Volvo recommends that • Volvo recommends that you engage an you have it conveyed to an authorised Volvo authorised Volvo workshop to handle the workshop. replacement of components in the car's safety systems.
Page 33 01 Safety When the systems deploy WARNING Never drive with deployed airbags. They can make steering difficult. Other safety systems may also be damaged. The smoke and dust created when the airbags are deployed can cause skin and eye irritation/ injury after intensive exposure.
Page 34: Crash Mode
If the car is in crash mode it must not be towed. It must be transported from its loca- Moving the car tion. Volvo recommends that you have it NORMAL MODE CRASH is shown after conveyed to an authorised Volvo workshop.
Page 35: Child Safety
Child seats and airbags are not compatible. Volvo's own child safety equipment is Volvo has child safety products that are WARNING designed for your car. Volvo recommends that designed for and tested by Volvo.
Page 36 Front seat Group 0 Volvo Child seat – rear-facing child seat, secured with Volvo Child seat – rear-facing child seat, secured with the the car's seatbelt and straps. Use a protective cushion car's seatbelt, straps and support legs. max. 10 kg between the child seat and the dashboard.
Page 37 Front seat Group 1 Volvo Child seat – rear-facing child seat, secured with Volvo Child seat – rear-facing child seat, secured with the the car's seatbelt and straps. Use a protective cushion car's seatbelt, straps and support legs. 9 – 18 kg between the child seat and the dashboard.
Page 38 For information on activated/deactivated airbag (SRS), see page 23. To install a rear-facing child seat in the rear seat, Volvo recommends that you contact an authorised Volvo dealer to have the mounting points installed. ISOFIX fixture system for child seats...
Page 39 Overview, left-hand drive cars..............40 Overview, right-hand drive cars.............. 42 Driver's door control panel..............44 Combined instrument panel..............45 Indicator and warning symbols............... 46 Information display.................. 50 Electrical socket..................52 Lighting panel..................53 Left-hand stalk switch................55 Right-hand stalk switch................58 Cruise control*..................
Page 40 I N S T R U M E N T S A N D C O N T R O L S...
Page 41: 02 Instruments And Controls
02 Instruments and controls Overview, left-hand drive cars...
Page 42 02 Instruments and controls Overview, left-hand drive cars Steering wheel adjustment Switch, optional equipment Opening handle, bonnet Switch, passenger compartment auto- matic lighting Control panel, windows and door mirrors Switch, optional equipment Direction indicators, main beam, trip com- Switch, passenger compartment lighting, puter right-hand side Lighting panel and fuel filler flap opener...
Page 43: Overview, Right-Hand Drive Cars
02 Instruments and controls Overview, right-hand drive cars...
Page 44 02 Instruments and controls Overview, right-hand drive cars Electrical socket and cigarette lighter Rearview mirror, interior Switch, roof control Ignition switch Parking brake Stalk switch, left Control panel, windows and door mirrors Keypad, steering wheel, left Glovebox Combined instrument panel Door handle and lock button Horn and airbags Indicator lamp, locking...
Page 45: Driver's Door Control Panel
02 Instruments and controls Driver's door control panel Driver's door control panel Power windows, all windows down/up Power windows Door mirror, left-hand side Door mirrors, setting Door mirror, right-hand side...
Page 46: Combined Instrument Panel
02 Instruments and controls Combined instrument panel Speedometer. Tachometer – Indicates engine speed in Temperature gauge - Used for the engine thousands of revolutions per minute (rpm). cooling system. A message will appear on Direction indicators, left. the display if the temperature becomes too Indicator and warning symbols.
Page 47: Indicator And Warning Symbols
02 Instruments and controls Indicator and warning symbols Functionality check, symbols Symbols in the centre of the instrument When the symbol illuminates: panel All indicator and warning symbols illuminate 1. Stop in a safe manner. Do not drive the car when the remote control key is turned to posi- further.
Page 48 ABS fault 3. Drive to a workshop to have the ABS sys- tem checked if the symbol remains lit. Rear fog lamp Volvo recommends that you seek assis- Stability system STC or DSTC tance from an authorised Volvo workshop. No function...
Page 49 If the faulty. symbol illuminates and the oil level is normal Volvo recommends that you contact an author- Parking brake applied ised Volvo workshop. The symbol illuminates when the parking brake is applied.
Page 50 02 Instruments and controls Indicator and warning symbols Stop the car in a safe place and check the have the brake system checked. Volvo rec- High speed level in the brake fluid reservoir, see ommends that you seek assistance from If the car is moving faster than page 206.
Page 51: Information Display
Specification Message Specification Stop the car in a safe TIME FOR REGU- Time for regular STOP SAFELY manner and turn off service. Volvo rec- LAR SERVICE the engine. Serious ommends that an risk of damage. authorised Volvo workshop carries SERVICE Volvo recommends out the service.
Page 52 10 000 km (certain the message clears, engine variants). For see page 143. information on If shown repeatedly checking the oil then Volvo recom- level, see page 203. mends that an authorised Volvo Diesel particle filter SOOT FILTER workshop is contac-...
Page 53: 12 V Electrical Socket
02 Instruments and controls Electrical socket 12 V electrical socket The electrical socket can be used for 12 V accessories, such as mobile phone chargers and coolers. The maximum current is 10 A. For the socket to supply current, the remote con- trol key must be in at least position I.
Page 54: Lighting Panel
Thumbwheel for headlamp levelling centre position. If necessary, the automatic the height of the beam. dipped beam can be deactivated. Volvo rec- Light switches 1. Turn the remote control key to position II. ommends that this is performed by an author- Thumbwheel for adjusting display and ised Volvo workshop.
Page 55: Lighting Panel
02 Instruments and controls Lighting panel The lamps are switched off automatically when Fog lamps Fuel filler flap the remote control key is turned to position I or Press button (5) to open the fuel filler flap when NOTE the car is unlocked, see page 122. Regulations for use of fog lamps vary from Instrument lighting country to country.
Page 56: Left-Hand Stalk Switch
02 Instruments and controls Left-hand stalk switch Stalk switch positions Direction indicators Switching, main and dipped beam The remote control key must be in position II Continuous flash sequence and the headlamp control in end position, see Move the stalk switch up or down to page 53, for main beam to be switched on.
Page 57 02 Instruments and controls Left-hand stalk switch Trip computer* updated every couple of seconds. When the NOTE car is stationary, " --.- " appears on the display. If a warning message interrupts while you During the period for regeneration fuel con- are using the trip computer, this message sumption may increase, see page 273.
Page 58 02 Instruments and controls Left-hand stalk switch Resetting 1. Select AVERAGE SPEED AVERAGE 2. Reset with one press on the RESET but- ton. Press and hold the RESET button for at least five seconds to reset the average speed and average consumption at the same time.
Page 59: Right-Hand Stalk Switch
02 Instruments and controls Right-hand stalk switch Windscreen wipers Windscreen/headlamp washer Single sweep Raise the stalk switch to make a Move the stalk switch toward the steering single sweep. wheel to start the windscreen and headlamp washers. The wipers will make several more sweeps once the stalk switch is released.
Page 60 02 Instruments and controls Right-hand stalk switch Rain sensor* Activating the rain sensor: selected, or the sensitivity to rain when the rain sensor is selected. Press the button (B), see page 58. A display symbol shows that the rain sensor is active.
Page 61: Cruise Control
02 Instruments and controls Cruise control* Activating Increasing or decreasing speed NOTE A temporary increase in speed (less than one minute) using the accelerator, such as while overtaking, does not affect the cruise control setting. When you release the accel- erator, the car will return to the programmed speed.
Page 62 02 Instruments and controls Cruise control* Return to the set speed – Press this button to resume the CRUISE previously set speed. appears on the combined instrument panel. Disengaging Press CRUISE to disengage the cruise CRUISE ON control. clears on the com- bined instrument panel.
Page 63: Keypad In The Steering Wheel
02 Instruments and controls Keypad in the steering wheel* Button functions The four buttons at the bottom of the steering wheel keypad control the radio and the phone. The function of a button depends on which system is active. The steering wheel keypad can be used to scroll between preset stations, change CD tracks and adjust the volume.
Page 64: Steering Wheel Adjustment, Hazard Warning Flashers
02 Instruments and controls Steering wheel adjustment, hazard warning flashers Steering wheel adjustment WARNING NOTE Adjust the steering wheel before driving off, Regulations regarding the use of hazard never while driving. Before driving, check warning flashers vary from country to coun- that the steering wheel is fixed in position.
Page 65: Parking Brake
02 Instruments and controls Parking brake Parking brake (handbrake) How to Apply the parking brake 1. Fully depress the foot brake pedal. 2. Pull the lever firmly. 3. Release the foot brake pedal and make sure that the car is at a standstill position. 4.
Page 66: Power Windows
02 Instruments and controls Power windows Operation The driver can operate all of the power win- WARNING dows from the driver's seat. The power windows are operated using the Make sure that children and other passen- controls in the doors. The ignition key must be The windows can be opened and closed in two gers cannot be trapped in any way when in position I or II for the power windows to...
Page 67 02 Instruments and controls Power windows Passenger seat WARNING The function that interrupts the movement of the windows in the event of them being blocked works with both automatic and manual closing, although not with pinch protection deployed. WARNING If there are children in the car: Remember to switch off the supply to the power windows by removing the remote control key if the driver leaves the car.
Page 68: Windows, Rearview And Door Mirrors
02 Instruments and controls Windows, rearview and door mirrors Interior rearview mirror Interior rearview mirror with Calibrating the compass compass* The earth is divided into 15 magnetic zones. Bright light from behind could be reflected in The compass is set for the geographic area to the rearview mirror and dazzle the driver.
Page 69 02 Instruments and controls Windows, rearview and door mirrors 4. Press the button (1) repeatedly until the number for the required magnetic zone ( 1– ) is shown, refer to the map of magnetic zones for the compass. 5. Wait until the display resumes showing the character 6.
Page 70 02 Instruments and controls Windows, rearview and door mirrors Door mirrors Retractable power door mirrors* NOTE The mirrors can be retracted for parking/driving The door mirrors will not be extended auto- in narrow spaces. This can be carried out in matically during unlocking if they were ignition position I and II.
Page 71 02 Instruments and controls Windows, rearview and door mirrors Blind Spot Information System, BLIS* BLIS is an information system that under cer- tain conditions can help to draw the driver's attention to vehicles moving in the same direc- tion in the so-called "blind spot", see page 151.
Page 72: Personal Preferences
02 Instruments and controls Personal preferences Possible settings Display Clock, adjustment Personal preferences can be set for some of The hour and minute are each adjusted sepa- MENU the car's functions. This applies to locks, cli- rately. mate control and audio functions. For audio EXIT 1.
Page 73: Personal Preferences
02 Instruments and controls Personal preferences On/Off Select depending on whether or Lock confirm. light Simultaneous opening of all windows not you wish the recirculation timer to be The hazard warning flashers can provide feed- This function can be selected for the unlock active.
Page 74: Homelink
02 Instruments and controls HomeLink * General The original remote controls can of course be NOTE used in parallel with HomeLink . HomeLink is designed to be inoperable if the car is locked from the outside. WARNING Save the original remote controls for future If HomeLink is used to operate a garage programming (e.g.
Page 75 02 Instruments and controls HomeLink * • 2. Position the original remote control Glow not constant: The indicator lamp Programming individual buttons flashes quickly for approx. 2 seconds 5-30 cm from HomeLink . Monitor the indi- To reprogram an individual button, proceed in and then changes over to a constant cator lamp.
Page 76 02 Instruments and controls HomeLink * • Constant glow: The indicator lamp illu- 7. Depress the programmed button on minates with a constant glow when the HomeLink , while the "programming but- button is kept depressed, this indicates ton" is still flashing, keep it depressed for that the programming is complete.
Page 77 General information on climate control........... 78 Electronic climate control, ECC*............. 80 Air distribution..................83 Fuel-driven engine block heater and passenger compartment heater*............. 84 Fuel-driven auxiliary heater* (diesel)............87 Option/accessory, for more information, see Introduction.
Page 78 C L I M A T E C O N T R O L...
Page 79: 03 Climate Control
Fault tracing and repair Display The climate control system cools or heats as Volvo recommends that you only entrust fault There is a display above the climate control well as dehumidifies the air in the passenger tracing and repair of the climate control system panel.
Page 80: Climate Control
03 Climate control General information on climate control Air vents in the dashboard Side windows and sunroof To ensure that the air conditioning works sat- Actual temperature isfactorily, close all side windows and the roof. The temperature you select corresponds to the physical experience with reference to factors Acceleration such as air speed, humidity and solar radiation...
Page 81: Electronic Climate Control, Ecc
03 Climate control Electronic climate control, ECC* Control panel AUTO Functions If you select one or more manual functions, the other functions continue to be controlled auto- 1. AUTO matically. All manual settings are switched off The AUTO function automat- when AUTO is switched on.
Page 82 03 Climate control Electronic climate control, ECC* Keep the following in mind: 3. Air quality system* NOTE Same button as recirculation. • As a rule, the air quality sensor should If the knob is turned anticlockwise and the always be engaged. The air quality system con- fan indicator in the display goes out, the fan and the air conditioning are switched off.
Page 83 03 Climate control Electronic climate control, ECC* on the button. Automatic switching off discon- 5. Air distribution 7 and 8. Heated front seats* nects the rear window and door mirrors after The airflow can be distributed To activate front seat heating: 12 –...
Page 84: Air Distribution
03 Climate control Air distribution Air distribution Use: Air distribution Use: Air to windows. Some air to remove ice and Air to the floor and windows. to ensure comfortable flows from the air vents. The misting quickly. Some air flows from the dash- conditions and good air is not recirculated.
Page 85: Fuel-Driven Engine Block Heater And Passenger Compartment Heater
03 Climate control Fuel-driven engine block heater and passenger compartment heater* General information about heaters Refuelling Battery and fuel If the battery has insufficient charge or the fuel The parking heater heats the engine and pas- level is too low, the parking heater is switched senger compartment and can be started off automatically and a message appears on directly or with the timer.
Page 86 03 Climate control Fuel-driven engine block heater and passenger compartment heater* Activating the heater Symbols and display messages Display Specification When one of the timer's settings or HEATER STOP- The heater has been DIRECT START is activated, the stopped by the car's PED - LOW BAT- information symbol in the com- electronics in order...
Page 87 03 Climate control Fuel-driven engine block heater and passenger compartment heater* Heating of the passenger compartment will TIMER 1 After setting a second start time can NOTE begin as soon as the engine coolant has be programmed with TIMER 2 by scrolling with All timer programming will be cleared if the reached the correct temperature.
Page 88: Fuel-Driven Auxiliary Heater* (Diesel)
03 Climate control Fuel-driven auxiliary heater* (diesel) Auxiliary heater (diesel) In diesel-engined cars the auxiliary heater may be required for achieving the correct tempera- ture in the engine and passenger compartment during cold weather. The heater starts automatically when extra heat is required when the engine is running.
Page 89 Front seats....................90 Electrically operated roof ............... 95 Wind deflector*..................99 Interior lighting..................100 Storage spaces in the passenger compartment........102 Cargo area.................... 106 Option/accessory, for more information, see Introduction.
Page 90 I N T E R I O R...
Page 91: 04 Interior
04 Interior Front seats Seating position Backrest rake: turn the wheel. Entry to the rear seat Control panel for power seat*. Lever (2) is not available on all seat models. WARNING Adjust the position of the driver's seat and adjust the seatbelt, see page 16, before set- ting off, never while driving.
Page 92 04 Interior Front seats Push the seat backward: Manual seat NOTE Lower the seat before it is pushed forward - otherwise there is a risk that the head restraint makes contact with the sun visor. Push the seat forward: Lift the handle Lift the handle and fold back the backrest.
Page 93 04 Interior Front seats 3. Continue to lift of the handle, and push the seat forward to the desired position and release the handle. Power seat* Push the seat forward: Lift the handle. Hold down the front section of the button. If the seat is set in a higher position - then Fold the backrest forward to the locked it will be lowered automatically to avoid the...
Page 94 Floor mats* Volvo supplies floor carpets which are espe- cially produced for your car. WARNING The floor mat at the driver's seat must be The seats can be adjusted for a certain time Lift the handle and fold back the backrest.
Page 95 04 Interior Front seats the seat again. Only one of the seat's settings Emergency stop can be adjusted at a time. If the seat accidentally begins to move, press any of the buttons to stop the function. Memory function WARNING Risk of crushing.
Page 96: Electrically Operated Roof
IMPORTANT the roof's opening and closing mechanisms. Water collecting on the roof can run down Volvo also recommends that the following is into the cargo area and the passenger com- observed: partment if the roof is opened.
Page 97: Electrically Operated Roof
04 Interior Electrically operated roof Hatch cover Opening and closing the roof Release the button when a signal sounds and the message ROOF CLOSED ROOF OPEN is shown on the information display. WARNING Never pull the release wire for the hydraulic system that is located under the rear seat cushion.
Page 98 ROOF FAILURE SEE MANUAL is shown • ROOF FAILURE SERVICE REQUIRED on the display. Following which, release The roof cannot be operated. This requires the button. service by an authorised Volvo workshop.
Page 99 04 Interior Electrically operated roof Plastic cover for temporary covering The plastic cover is stored in a bag marked plastic so that it has one tuck (1) per wiper "Cover for temporary use". blade. 6. Guide through the antenna (5). 7.
Page 100: Wind Deflector
04 Interior Wind deflector* General NOTE Be careful of the car's upholstery. The zips in the wind deflector are used for stor- ing/retrieving luggage on the rear seat. WARNING Check that the wind deflector is secured firmly. Otherwise it may detach in the event of sudden movement for example and then cause injury and damage.
Page 101: Interior Lighting
04 Interior Interior lighting Reading lamps and interior lighting Vanity mirror* Roof lighting The reading lamps are switched on or off by pressing the relevant button in the roof con- sole. Rear seat lighting Controls in roof console for front reading lamps The lamp is automatically switched on and off and passenger compartment lighting.
Page 102 04 Interior Interior lighting Automatic lighting Passenger compartment lighting comes on and remains on for 5 minutes if one of the doors Using the switch (2), see page 100, three posi- is open. tions can be selected for the lighting the pas- senger compartment: If any lighting is switched on manually and the car is locked then it will be switched off auto-...
Page 103: Storage Spaces In The Passenger Compartment
04 Interior Storage spaces in the passenger compartment Storage spaces...
Page 104: Storage Spaces In The Passenger Compartment
04 Interior Storage spaces in the passenger compartment Storage compartment in door panel (lock- Glovebox Coat hanger able*). Coat hanger, only for light garments. Storage pocket on front edge of front seat cushions. Ticket clip Glovebox Storage compartment behind the centre console Cup holder (with roller cover*) Tunnel compartment (e.g.
Page 105 04 Interior Storage spaces in the passenger compartment Storage compartment in door panel Storage compartment in rear side Storage under the front armrest panel The storage compartment is opened by lifting There is a storage space under the armrest. the lower front edge of the lid, and closed with The storage compartment is opened and There is also a smaller storage space in the a touch on its upper section.
Page 106 04 Interior Storage spaces in the passenger compartment Cup holder in centre console Close the roller cover by gripping its front edge from below and pulling forward. Storage compartment behind the handbrake In the deeper compartment there is space for 10 normal CD cases.
Page 107: Cargo Area
04 Interior Cargo area Cargo separator Loading assistance Label on cargo separator. Button for raising and lowering the roof. The purpose of the separator is to limit the NOTE In open position the roof is folded up in the amount of the load in the cargo area so that the Too much load in the cargo area prevents cargo area.
Page 108 Straps that are suitable for the Lower the roof to its lowest position, wait a cargo separator. eyelets are supplied by Volvo dealers. few seconds and then close the boot lid. 4. Press the button so that the roof is low- ered.
Page 109 04 Interior Cargo area Electrical socket in cargo area Ski hatch Close the centre section in the back of the rear seat 1. Refit the centre section with the lower part first. 2. Fold in the centre section and press until a clicking sound is heard.
Page 110 04 Interior Cargo area WARNING Stop the engine and apply the parking brake when loading or unloading long objects. A loose object weighing 20 kg can, in a frontal collision at a speed of 50 km/h carry the impact of an item weighing 1000 kg. Always secure the load.
Page 111 Remote control key with key blade............112 Privacy locking*..................115 Active locks................... 117 Keyless drive*..................118 Battery in remote control key..............121 Locking and unlocking................122 Alarm*....................126 Option/accessory, for more information, see Introduction.
Page 112 L O C K S A N D A L A R M...
Page 113: 05 Locks And Alarm
The remote control keys contain detachable If you lose a remote control key, take the car metal key blades for mechanical locking/ and the other remote control keys to a Volvo unlocking of the driver's door and glovebox. workshop - an authorised Volvo workshop is The key blades' unique code is available at recommended.
Page 114 05 Locks and alarm Remote control key with key blade interior lighting, position/parking lamps, Detachable key blade Removing the key blade number plate lighting and door mirror To remove the key blade from the remote con- lamps (option). The lighting is switched off trol key: automatically after 30, 60 or 90 seconds.
Page 115 05 Locks and alarm Remote control key with key blade Insert the key blade in the glovebox lock. NOTE When the driver's door is unlocked using the Turn the key blade 90 degrees clockwise. key blade and is opened, the alarm is trig- The keyhole is horizontal in the locked gered.
Page 116: Privacy Locking
05 Locks and alarm Privacy locking* Central locking's normal active locks with vate the alarm, to open the doors (A) and to NOTE the remote control key. drive the car (B). The information display will show CLOSE Active locks for remote control key with The remote control key is handed over without BOOT SEP.
Page 117 05 Locks and alarm Privacy locking* Deactivating privacy locking In order to reconnect the lockable storage compartments to the central locking's auto- matic system, proceed as follows: 1. Insert the remote control key's detachable key blade into the glovebox keyhole and turn 180 degrees anticlockwise.
Page 118: Active Locks
05 Locks and alarm Active locks Active locks for remote control key. Boot lid Doors For descriptions of the different storage areas, see page 102. Steering lock Ski hatch Boot lid Active locks for remote control key with lockable storage compartments. Doors Steering lock Storage compartments in door panels...
Page 119: Keyless Drive
05 Locks and alarm Keyless drive* • Keyless lock and ignition system the READ button has been pressed. Remote control key max. 1.5 m from the Never leave any remote control key in the In order to open a door or the boot lid, a remote control key must be no more than approx.
Page 120 05 Locks and alarm Keyless drive* Locking Unlocking doors with the key blade NOTE On cars with the keyless drive system and automatic transmission the gear selector must be moved to the P position and the ignition dial turned to the 0 position. Other- wise the car cannot be locked or alarmed.
Page 121 05 Locks and alarm Keyless drive* Centre console, under the rear section NOTE Door handle, right When the driver's door is unlocked using the key blade and is opened, the alarm is trig- Centre console, under the front section gered. It is switched off by inserting the remote control key in the ignition switch, see page 127.
Page 122: Battery In Remote Control Key
05 Locks and alarm Battery in remote control key Low battery in remote control key 1. Place the remote control key with the key- pad downward and prize up the cover When the battery runs down and full function- using a small screwdriver. ality cannot be guaranteed, the information KEY BATTERY symbol...
Page 123: Locking And Unlocking
05 Locks and alarm Locking and unlocking Locking/unlocking the car from Opening the boot lid mechanically WARNING outside Be aware that you can be locked in the car For cars with the Keyless system, see if it is locked from the outside with the page 118.
Page 124 05 Locks and alarm Locking and unlocking The doors and the boot lid can be locked or Lock indicator IMPORTANT unlocked simultaneously using the central The roof must be fully closed or fully open locking button on either front door. before mechanical opening can be used for the boot lid.
Page 125 05 Locks and alarm Locking and unlocking Automatic locking If someone is going to stay in the car but the Temporary deactivation doors must be locked from the outside, then When the speed of the car exceeds 7 km/h the the deadlocks function can be temporarily doors and boot lid are locked automatically.
Page 126 05 Locks and alarm Locking and unlocking Full guard sage at which the deadlocks func- tion and the alarm's movement and tilt detec- tors* are re-engaged. • If the locking system shall not be changed: Select no options at all and lock the car. Or press EXIT and lock the car.
Page 127: Alarm
- an authorised objects in the centre console's cup holder Volvo workshop is recommended. • a non-approved key is used in the ignition as such objects could accidentally trigger or if an attempt is made to force the lock the alarm.
Page 128 05 Locks and alarm Alarm* Disarming the alarm Alarm signals 1. Open the driver's door with the key blade. The alarm is triggered and the siren Press the remote control key unlock but- When the alarm is triggered, the following hap- sounds.
Page 129 05 Locks and alarm Alarm* Reduced alarm level To avoid inadvertently triggering of the alarm - the instrument panel display shows the mes- for example when leaving a dog in the car or sage Full guard at which the movement and during a ferry crossing - the movement and tilt tilt detectors and the deadlocks function are re- detectors can be temporarily switched off.
Page 130 05 Locks and alarm Alarm* 4. Open one of the doors. A siren should sound and all direction indicators should flash. 5. Deactivate the alarm by unlocking the car with the remote control key. Test of alarm for bonnet 1. Sit in the car and deactivate the movement detector.
Page 131 General....................132 Refuelling....................134 Starting the engine................136 Keyless drive*..................138 Manual gearbox..................139 Automatic gearbox................141 Brake system..................145 DSTC – Stability and traction control system*........147 Park Assist*................... 149 BLIS* – Blind Spot Information System..........151 Towing and recovery................155 Start assistance..................
Page 132 S T A R T I N G A N D D R I V I N G...
Page 133: 06 Starting And Driving
06 Starting and driving General Economical driving Slippery driving conditions Open boot lid Driving economically means driving smoothly Practise driving on slippery surfaces under Avoid driving with the boot lid open. If it is nec- while thinking ahead and adjusting your driving controlled conditions to learn how the car essary to drive with the tailgate open for a short style and speed to the prevailing conditions.
Page 134 06 Starting and driving General • When driving in water, maintain a low speed ventilation fan and do not stop the car. When the water has • windscreen wipers been passed, depress the brake pedal lightly • audio equipment (high volume) and check that full brake function is achieved.
Page 135: Refuelling
06 Starting and driving Refuelling Opening the fuel filler flap 3. Take out the cap. 2. Pull the cord hanging on the hook. 4. Hang up the cap on the inside of the fuel 3. When the fuel filler flap has opened, refit filler flap.
Page 136 06 Starting and driving Refuelling Petrol IMPORTANT Do not add cleaning additives to the petrol, unless recommended by Volvo. For more information on petrol, see page 272. Diesel At low temperatures (–5 °C to –40 °C), a paraf- fin precipitate may form in the diesel fuel, which can lead to ignition problems.
Page 137: Starting The Engine
06 Starting and driving Starting the engine Before starting the engine Starting the engine Key positions Apply the parking brake. Petrol 0 – Locked position Turn the remote control key to key position The steering lock is activated Automatic gearbox III.
Page 138 06 Starting and driving Starting the engine III – Start position WARNING The starter motor is engaged. Always remove the remote control key from When the remote control key the ignition switch when leaving the car, is released it springs back especially if there are children in the car.
Page 139: Keyless Drive
06 Starting and driving Keyless drive* General Starting the car Starting with the remote control key Depress the clutch pedal (cars with manual gearbox) or brake pedal (cars with auto- matic gearbox). Petrol engine Press in and turn the ignition dial to key position III.
Page 140: Manual Gearbox
06 Starting and driving Manual gearbox Gear positions - five-speed Gear positions - six-speed (petrol) Reverse gear inhibitor - five-speed The reverse gear inhibitor hinders the possibil- For the best possible fuel economy, use the For the best possible fuel economy, use the ity of mistakenly attempting to engage reverse highest gear possible as often as possible.
Page 141 06 Starting and driving Manual gearbox Gear positions - six-speed (diesel) Reverse gear inhibitor - six-speed Reverse gear inhibitor - six-speed (petrol) (diesel) For the best possible fuel economy, use the The reverse gear inhibitor hinders the possibil- The reverse gear inhibitor hinders the possibil- highest gear possible as often as possible.
Page 142: Automatic Gearbox
06 Starting and driving Automatic gearbox Geartronic automatic gear positions Geartronic manual gear positions NOTE The driver can also change gear manually The brake pedal must be depressed to using the Geartronic automatic gearbox. The move the gear lever from the P position. car engine-brakes when the accelerator pedal is released.
Page 143 06 Starting and driving Automatic gearbox immediately engaged. This is known as kick- Mechanical gear selector inhibitor Automatic gear selector inhibitor down. Cars with an automatic gearbox have special safety systems: If the accelerator is released from the kick- down position, the gearbox automatically Keylock changes up.
Page 144 06 Starting and driving Automatic gearbox Disengaging the gear selector inhibitor the battery is flat. Proceed as follows to move to the gearbox oil's viscosity at low tempera- the car: tures. To reduce engine emissions, the gear- box shifts up later than normal when the engine 1.
Page 145 06 Starting and driving Automatic gearbox Symbol Display Driving characteristics Action TRANSM. OVERHEAT BRAKE TO Difficulty in maintaining even speed at con- Gearbox overheated. Keep the car station- stant engine speed. HOLD ary using the foot brake Significant pulling in the car's traction. Gearbox overheated.
Page 146: Brake System
06 Starting and driving Brake system Brake servo Bear in mind that driving with a trailer puts an Dampness can affect braking additional load on the car's brakes. characteristics If the car is rolling or is being towed with the Brake components become wet when the car engine turned off, the brake pedal must be is driven in heavy rain, through pools of water...
Page 147 - an author- ised Volvo workshop is recommended. If the brake fluid is under the MIN level in the brake fluid reservoir, do not drive further before topping up the brake fluid.
Page 148: Dstc - Stability And Traction Control System
06 Starting and driving DSTC – Stability and traction control system* General Reduced operation Operation Turn thumbwheel until the STC/DSTC The stability and traction control system, STC/ menu is shown. DSTC (Dynamic Stability and Traction Control) helps the driver to avoid skidding and improves DSTC ON means that the system function the car's traction.
Page 149 Constant glow after deactivation reminds that the STC/DSTC system has been If the message remains when the engine is reduced. restarted, drive to a workshop - an authorised Volvo workshop is recommended. Symbols in the combined instrument panel DSTC system Information...
Page 150: Park Assist
Rear parking assistance is deactivated then this is automatically lowered. automatically when towing a trailer if a Volvo The tone becomes constant at a distance of genuine trailer cable is used. about 30 cm. If there are obstacles within this...
Page 151 When the speed is below attention, contact a workshop - an authorised 10 km/h the system is reactivated. Volvo workshop is recommended. The distance covered to the front of the car is about 0.8 metres. The signal for obstacles in IMPORTANT front comes from the front loudspeakers.
Page 152: Blis* - Blind Spot Information System
06 Starting and driving BLIS* – Blind Spot Information System General BLIS is an information system that under cer- Blind spots tain conditions can help to draw the driver's attention to vehicles moving in the same direc- tion in the so-called "blind spot". The system is designed to work most effec- tively when driving in dense traffic on multi-lane highways.
Page 153 06 Starting and driving BLIS* – Blind Spot Information System Activating/deactivating WARNING WARNING BLIS does not work in sharp bends. The system does not react to bicycles or mopeds. BLIS does not work when the car is revers- ing. The BLIS cameras can be disrupted by intensive light or when driving in the dark A wide trailer coupled to the car can conceal when there are no light sources (e.g.
Page 154 - an other vehicle within the blind spot then this authorised Volvo workshop is recom- BLIS ON BLIS system on. does not mean that a fault has arisen in the mended.
Page 155 06 Starting and driving BLIS* – Blind Spot Information System Own shadow on large, light, smooth surface, e.g. noise barrier or concrete road surface. Low sun in the camera. Option/accessory, for more information, see Introduction.
Page 156: Towing And Recovery
06 Starting and driving Towing and recovery Start assistance WARNING IMPORTANT Use a donor battery if the battery is discharged The steering lock remains in the position it Note that the car must always be towed with and the engine does not start. Do not tow the was in when the power was cut off.
Page 157 06 Starting and driving Towing and recovery Towing eye Use the towing eye if the car needs to be towed Screw in the towing eye firmly, right in up NOTE on the road. The towing eye is attached in the to the flange.
Page 158 06 Starting and driving Towing and recovery Recovery Call a recovery service for recovery assistance. The car must always be towed with the wheels rolling forward. IMPORTANT Cars with automatic gearbox must only be towed with drive wheels raised from the road.
Page 159: Start Assistance
06 Starting and driving Start assistance Starting with a donor battery 3. If the donor battery is in another car, switch WARNING off the engine in the other car and ensure The battery can generate oxyhydrogen gas, that the cars do not touch one another. which is highly explosive.
Page 160: Driving With A Trailer
If the towing bracket is fitted by an authorised weather. If the temperature gauge for the sudden movement and braking. Volvo workshop, then the car is delivered with engine's cooling system goes into the red the necessary equipment for driving with a zone, stop and let the engine idle for a few trailer.
Page 161 If the car is driven with a major load in a hot climate, the engine cooling fan can be replaced with one of a greater capacity than the stand- ard model. Check with your nearest Volvo dealer regarding the options for your car.
Page 162: Towing Equipment
If the car is equipped with a detachable towbar, the towball mounting instructions must be fol- lowed carefully, see page 163. WARNING If the car is fitted with a Volvo detachable towbar: • Follow the assembly instructions for the towball section carefully.
Page 163 06 Starting and driving Towing equipment* Specifications Dimensions for mounting points (mm) Fixed or detachable towbar standard 1172 Side member Ball centre Option/accessory, for more information, see Introduction.
Page 164: Detachable Towbar
06 Starting and driving Detachable towbar* Fitting the towball 2. Ensure that the mechanism is in the 3. Check that the indicator window (3) shows unlocked position by turning the key clock- red. If the window does not show red, 1.
Page 165 06 Starting and driving Detachable towbar* 4. Insert the towball section until your hear a 5. Check that the indicator window shows 6. Turn the key anticlockwise to locked posi- click. green. tion. Remove the key from the lock. Option/accessory, for more information, see Introduction.
Page 166 06 Starting and driving Detachable towbar* Removing the towball 7. Check that the towball section is secure by 8. Safety cable. pulling it up, down and back. 1. Insert the key and turn it clockwise to the WARNING unlocked position. WARNING Be sure to attach the trailer's safety cable to the correct place.
Page 167 06 Starting and driving Detachable towbar* 2. Push in the locking wheel 3. Turn the locking wheel down fully, until it 4. Push on the protective cover. and turn it comes to a stop. Hold it in this position anticlockwise until you hear a click.
Page 168: Loading
06 Starting and driving Loading General WARNING Payload depends on the car's kerb weight. The A loose object weighing 20 kg can, in a total of the weight of the passengers and all frontal collision at a speed of 50 km/h, carry accessories reduces the car's payload by a the impact of an item weighing 1000 kg.
Page 169: Adjusting Headlamp Pattern
On cars with Dual Xenon headlamps, Dual dazzling oncoming motorists. Xenon lamp replacement must be carried out at a workshop - an authorised Volvo The correct pattern will also better illuminate workshop is recommended. The headlamps the verge.
Page 170 06 Starting and driving...
Page 171 General....................172 Tyre pressure..................176 Warning triangle* and spare wheel* ............. 179 Changing wheels................... 182 Emergency puncture repair*..............184 Option/accessory, for more information, see Introduction.
Page 172 W H E E L S A N D T Y R E S...
Page 173: 07 Wheels And Tyres
07 Wheels and tyres General Driving characteristics and tyres Speed ratings New tyres The tyres greatly affect the car's driving cha- The car is approved as a whole, which means Tyres are perishable. After a racteristics. The type of tyre, dimensions, tyre that dimensions and speed ratings must not few years they begin to pressure and speed rating are important for...
Page 174 5000 km Studded tyres Use Volvo genuine snow chains or equiva- and then at 10000 km intervals. Volvo recom- Studded winter tyres should be run in gently for lent chains designed specifically for the car...
Page 175 These differ markedly from Only use wheel rims that are tested and other nut types as they have a rotating conical approved by Volvo and which are included in washer. the Volvo genuine accessories range. There are two types of wheel nut, depending...
Page 176 (to decrease the risk of skidding). Volvo recommends that you contact an author- ised Volvo workshop for checking if you are uncertain about tread depth. The arrow shows the tyre's direction of rotation.
Page 177: Tyre Pressure
07 Wheels and tyres Tyre pressure Recommended tyre pressure Stated on the label: pressure that is too low can also result in the tyres overheating and disintegrating. • Tyre pressure for the car's recommended tyre size For information on the correct tyre pressure, refer to the tyre pressure table.
Page 178 07 Wheels and tyres Tyre pressure Tyre pressure table Variant Tyre size Speed Load, 1 - 3 persons Max. load (km/h) Rear (kPa) Front (kPa) Rear (kPa) ECO pres- Front (kPa) sure 215/55 R16 91W 0-160 2.4i 160+ 215/50 R17 91W 0-160 235/45 R17 94W 160+...
Page 179 07 Wheels and tyres Tyre pressure Variant Tyre size Speed Load, 1 - 3 persons Max. load (km/h) Rear (kPa) Front (kPa) Rear (kPa) ECO pres- Front (kPa) sure 215/55 R16 91 W 0-160 160+ 215/50 R17 91W 0-160 235/45 R17 94W 160+ 235/40 R18 91Y Spare...
Page 180: Warning Triangle* And Spare Wheel
2. Lower the warning triangle's support legs. NOTE Ensure the warning triangle and its case are Volvo recommends only using the jack* that located in the spare wheel well. belongs to the car model in question. Emergency puncture repair kit For operation and location, see page 184.
Page 181 07 Wheels and tyres Warning triangle* and spare wheel* Spare wheel and tools Spare wheel and tools. The spare wheel* is supplied in a tyre bag that sure to follow the instructions on the spare is located in the cargo area's spare wheel well. wheel bag when it is refitted.
Page 182 07 Wheels and tyres Warning triangle* and spare wheel* WARNING The spare wheel bag contains impact pro- tection. The spare wheel must be inside the bag when it is stored in the car. Always fit the bag in the spare wheel well, with the text label upwards and so that the arrow is point- ing forwards in the car.
Page 183: Changing Wheels
Prize off the wheel cover with the Volvo recommends only using the jack* that ground. Check that the jack is seated cor- end of the wheel wrench, or pull it off by belongs to the car model in question.
Page 184 07 Wheels and tyres Changing wheels 7. Lift the car so that the wheel is free. Remove the wheel nuts and lift off the wheel. Fitting the wheel 1. Clean the contract surfaces on the wheel and hub. 2. Put on the wheel. Tighten the wheel nuts. 3.
Page 185: Emergency Puncture Repair
Pressure reducing valve seal a puncture as well as to check and adjust used. Volvo recommends that you visit an the tyre pressure. It consists of a compressor authorised Volvo workshop for inspection of Air hose and a bottle with sealing fluid.
Page 186 07 Wheels and tyres Emergency puncture repair* 2. Detach the decal for maximum permitted WARNING WARNING speed and affix it to the steering wheel. Do not leave children in the car without If the pressure is below 1.8 bar then the hole supervision when the engine is running.
Page 187 7. Refit the dust cap. 6. Return the emergency puncture repair kit. Inhaling car exhaust fumes could result in 7. Volvo recommends that you drive to the danger to life. Never leave the engine run- nearest authorised Volvo workshop for the ning in sealed areas or areas that lack suf- replacement/repair of the damaged tyre.
Page 188 07 Wheels and tyres Emergency puncture repair* Changing the sealing fluid canister Replace the bottle before the expiration date has passed. Treat the old bottle as environ- mentally hazardous waste. WARNING The bottle contains 1.2-Ethanol and natural rubber-latex. Harmful if ingested. Could result in allergic reaction in the event of skin contact.
Page 189 Cleaning....................190 Touching up paintwork................. 194 Rustproofing..................195...
Page 190 C A R C A R E...
Page 191: 08 Car Care
08 Car care Cleaning Washing the car very quickly. This discoloration can only be IMPORTANT removed by a specialist. Wash the car as soon as it becomes dirty. Use Dirty headlamps have impaired functional- car shampoo. Dirt and road salt can lead to ity.
Page 192: Car Care
Clean off asphalt IMPORTANT When using a pressure washer: Make sure and tar stains using Volvo tar remover or white that the nozzle of the pressure washer is not Avoid waxing and polishing on plastic and spirit.
Page 193 Washing instructions for leather required in order to maintain both characteris- upholstery tics and appearance. Volvo offers a compre- NOTE 1. Pour the leather cleaner on the dampened hensive product for the cleaning and treatment sponge and squeeze out a strong foam.
Page 194 Do not scrape or rub stains. Never use strong stain removers. Cleaning seatbelts Use water and a synthetic detergent. A special textile cleaning agent is available from your Volvo dealer. Make sure the seatbelt is dry before allowing it to retract.
Page 195: Touching Up Paintwork
08 Car care Touching up paintwork Paintwork Stone chips and scratches If the stone chip has penetrated to the bare metal Paint is an important part of the car's rust- 1. Apply a piece of masking tape over the proofing and should therefore be checked reg- damaged surface.
Page 196: Rustproofing
The car's rustproofing does not normally require treatment for approximately 12 years. After this period, it should be treated at three- year intervals. If the car needs further treat- ment, Volvo recommends that you engage an authorised Volvo workshop for assistance.
Page 197 Volvo service..................198 Self-maintenance.................. 199 Bonnet and engine compartment............200 Oils and fluids..................202 Wiper blades..................207 Battery....................208 Replacing bulbs..................210 Fuses..................... 216...
Page 198 M A I N T E N A N C E A N D S E R V I C E...
Page 199: 09 Maintenance And Service
It was checked again in accord- ance with Volvo Car Corporation regulations before it was handed over to you. To keep your Volvo as safe and reliable as pos- sible, follow the Volvo service programme specified in the Service and Warranty Booklet.
Page 200: Self-Maintenance
NOTE filled. Use washer antifreeze at tempera- High output from the ignition system. The Volvo recommends only using the jack that tures around freezing. voltage in the ignition system is highly dan- belongs to the car model in question. If a gerous.
Page 201: Bonnet And Engine Compartment
09 Maintenance and service Bonnet and engine compartment Opening the bonnet The illustration shows a left-hand drive car. 1. Pull the handle on the far left under the Engine oil dipstick WARNING instrument panel. (In right-hand drive cars Radiator Check that the bonnet locks properly when the handle is on the far right.) You will hear closed.
Page 202 09 Maintenance and service Bonnet and engine compartment Battery Relay and fuse box Air filter The location varies depending on engine alternative...
Page 203: Oils And Fluids
Using oil of a higher than specified grade is permitted. If the car is driven in adverse con- ditions, Volvo recommends using an oil of a higher grade than that specified on the decal, see page 266.
Page 204: Maintenance And Service
3. Check the oil level using the dipstick. The Volvo uses different systems for warning of low level must be between the MIN and MAX oil level or low oil pressure. Certain variants marks.
Page 205 09 Maintenance and service Oils and fluids Washer fluid, topping up WARNING NOTE Do not spill oil onto the hot exhaust manifold The oil level is only updated by the system due to the risk of fire. during driving. The system cannot detect changes when oil is filled or drained.
Page 206 TIP! Clean the wiper blades when topping up Always use coolant with anti-corrosion WARNING washer fluid. agent as recommended by Volvo. Coolant can be very hot. If the coolant • Ensure that the coolant mixture is 50% requires topping up when the engine is at water and 50% coolant.
Page 207 09 Maintenance and service Oils and fluids Checking and topping up the brake and WARNING clutch fluid If the brake fluid is under the MIN level in the brake fluid reservoir, do not drive further before topping up the brake fluid. The reason for the loss of brake fluid must be investigated.
Page 208: Wiper Blades
09 Maintenance and service Wiper blades Wiper blades 1. Turn up the wiper arm. Replacing the wiper blades, windscreen 2. Press the button located on the wiper blade mounting and pull straight out (1), parallel with the wiper arm. 3. Slide in (2) the new wiper blade until a "click"...
Page 209: Battery
09 Maintenance and service Battery Battery care Symbols on the battery NOTE The service life and function of the battery is Use protective goggles. The life of the battery is shortened if it influenced by factors such as the number of becomes discharged repeatedly.
Page 210 09 Maintenance and service Battery 8. Remove the battery. Avoid sparks and naked flames. Fitting the battery 1. Fit the battery into position. 2. Fit the clamp securing the battery. 3. Reinstall the front wall of the battery box. Risk of explosion. 4.
Page 211: Replacing Bulbs
All front bulbs (except for fog lamps) are Xenon lamp replacement must be carried changed by first removing the lamp housing out at a workshop - an authorised Volvo from the engine compartment. workshop is recommended. The headlamps must be handled with extreme caution due Removing the lamp housing to the Dual Xenon lamp's high-voltage unit.
Page 212 09 Maintenance and service Replacing bulbs on or the remote control key inserted into the Main beam ignition switch. Dipped beam Fitting a new bulb 1. Remove the entire lamp housing. 1. Fit the new bulb. It can only fit in one posi- tion.
Page 213 09 Maintenance and service Replacing bulbs Position/parking lamps Direction indicators Side marker lamps 1. Withdraw the bulb holder using pliers. Do 1. Twist the bulb holder anticlockwise and 1. Twist the bulb holder anticlockwise and not pull out the bulb holder by pulling the remove it.
Page 214 4. Unplug the connector from the bulb. Reversing lamp mend that you visit an authorised Volvo workshop. 5. Turn the bulb anticlockwise and pull it out. 6. Fit the new bulb and turn it clockwise.
Page 215 09 Maintenance and service Replacing bulbs Courtesy lighting Cargo area NOTE The rear fog lamp bulb is only used in one of the rear light clusters. In the left-hand rear light cluster on left-hand drive cars, and in the right-hand rear light cluster on right- hand drive cars.
Page 216 09 Maintenance and service Replacing bulbs Vanity mirror lighting* Fitting the mirror glass 1. First, press the three lugs at top edge of mirror glass back into position. 2. Then press the three lower lugs back into position. Interior lighting, rear Removing the mirror glass 1.
Page 217: Fuses
Each fuse box has space for several spare fuses. If the same fuse fails repeatedly then there is a fault in the component. In which case, Volvo recommends that you visit an authorised Volvo workshop for this to be checked.
Page 218 Volvo workshop. • 1–6 are of the "Midi Fuse" type and must only be replaced by a workshop. Volvo rec- ommends an authorised Volvo workshop. On the inside of the cover are tweezers to assist removing and fitting fuses.
Page 219 09 Maintenance and service Fuses Radiator fan 50 A ABS pump 30 A Power roof 30 A Power steering (excl. 1.6 litre ABS valves 20 A Supply to infotainment sys- engine) 80 A 40 A Engine functions 30 A Supply to passenger com- Windscreen wipers 30 A Ventilation fan...
Page 220 09 Maintenance and service Fuses Subwoofer 25 A Pressure switch, climate con- trol system (5 cyl.), ignition Engine control module ECM coils (petrol), glow plugs and (5-cyl. petrol), Transmission EGR emission control (5 cyl. (TCM) (5-cyl auto) 10 A diesel), fuel pump (4-cyl. die- sel) 10 A Transmission (TCM) (4-cyl.
Page 221: Relay/Fuse Box In Passenger Compartment
09 Maintenance and service Fuses Relay/Fuse box in the passenger compartment The fuse box has 50 fuse positions. The fuses completely. The fuse box can be fully are located under the glovebox. The box also unhooked. provides space for several spare fuses. Tools 4.
Page 222 09 Maintenance and service Fuses Phone, audio system, Reserve – Remote control module, RTI*, Bluetooth* 15 A siren control module 10 A Additional heater for the SRS system, engine con- passenger compartment, Data link connector trol module ECM (5-cyl.) 10 A fuel filter relay, heating 10 A (DLC), brake light switch...
Page 223 09 Maintenance and service Fuses Supply, power window, Electrical socket in cargo right rear 20 A area, accessory elec- tronic module (AEM) 15 A Lamp for door lock Reserve – Infotainment system Reversing lamp Infotainment control module (ICM), climate Reserve –...
Page 224 09 Maintenance and service...
Page 225 General....................226 Audio functions..................228 Radio functions..................232 CD functions..................237 Menu structure – audio system............. 240 Phone functions*................... 241 Menu structure – phone*............... 248 Bluetooth handsfree*................251 Option/accessory, for more information, see Introduction.
Page 226 I N F O T A I N M E N T S Y S T E M...
Page 227: General
10 Infotainment system General • Infotainment system trol panel or the steering wheel keypad*, see EXIT (6) leads back one step in the menu structure. A long press on EXIT will exit the page 62. The display (2) shows messages and menu system.
Page 228 10 Infotainment system General Dolby Surround Pro Logic II System is man- ufactured under license from Dolby Laboratories Licensing Corporation.
Page 229: Audio Functions
10 Infotainment system Audio functions Audio controls ume adjusts automatically depending on vehi- The AUX and USB inputs enable the connec- cle speed, see page 231. tion of an external audio source, e.g. an iPod or MP3 player. Audio source selection If you choose to connect an iPod , MP3 player Repeatedly pressing AM/FM switches or a USB memory stick to the USB connection...
Page 230: Infotainment System
10 Infotainment system Audio functions 2. or use the navigation control's (4) right or sory manual for USB and iPod Music Inter- NOTE left-hand button to scroll to the required face. The system supports removable media track. which is compatible with USB 2.0 and the It is also possible to change track using the Sometimes the AUX external audio source can FAT32 file system, and can handle a maxi-...
Page 231 10 Infotainment system Audio functions • SUBWOOFER * - Bass speaker level. Sub- Surround Equalizer front/rear woofer must be activated before adjust- Surround settings govern the spatial The equalizer can be used to adjust different ment is possible, see under the heading perception of the sound.
Page 232 10 Infotainment system Audio functions This calibration takes into account loudspeak- Automatic volume control ers, amplifiers, passenger compartment The auto volume control function allows the acoustics, listener position etc. for each com- audio volume to increase as the speed of the bination of car model and audio system.
Page 233: Radio Functions
10 Infotainment system Radio functions Radio controls Tuning 2. Hold a station preset button depressed until the message Station stored appears Automatic tuning on the display. 1. Select wavelength using AM/FM (1). Automatic storage of stations 2. Give a brief press on AUTO (7) seeks out the ten strongest radio sta- tions and stores them automatically in a sepa- Manual tuning...
Page 234: Radio Functions
10 Infotainment system Radio functions > The radio remains in Auto mode until it Programme functions Storing a station is exited by a brief press on AUTO (7), A selected station can be stored as a preset In FM mode, the radio can search for stations EXIT (6) or AM/FM (1).
Page 235 10 Infotainment system Radio functions ALARM! 3. Scroll to Advanced radio settings… message appears on the display Activating/deactivating TP search when an alarm message is transmitted. press ENTER. TP search is useful during long journeys while an audio source other than the radio is being 4.
Page 236 10 Infotainment system Radio functions 5. Select the desired programme types or 3. Scroll to Show PTY Regional radio programmes – REG and press ENTER. Clear all PTY… This function causes the radio to con- tinue with a regional transmitter even Search PTY Radio text if its signal strength is low.
Page 237 10 Infotainment system Radio functions Activating/deactivating EON 1. Press MENU and then ENTER. 2. Scroll to Advanced radio settings… press ENTER. 3. Scroll to EON… and press ENTER. 4. Scroll to Local Distant and press ENTER. Resetting RDS functions Resets all radio settings to the original factory settings.
Page 238: Cd Functions
10 Infotainment system CD functions CD function controls automatically. Otherwise, load a disc and Pause change to CD mode by pressing MODE. If the volume is turned down completely, the CD player is stopped. The player is restarted Starting playback (CD changer*) when volume is increased.
Page 239 10 Infotainment system CD functions matically when all files in the current directory Different messages appear on the display 3. Scroll to Single disc All discs and press have been played back. depending on which random function has been ENTER. selected.
Page 240 10 Infotainment system CD functions IMPORTANT Only use standard discs (12 cm in diameter). Do not use CD discs with adhesive disc labels. The heat in the CD player may cause the label to come off, damaging the CD player.
Page 241: Menu Structure - Audio System
10 Infotainment system Menu structure – audio system Overview AUX menu FM menu 1. AUX volume 1. News 2. News 2. TP 3. TP 3. PTY 4. Audio settings* 4. Radio text 5. Advanced radio settings 6. Audio settings* AM menu 1.
Page 242: Phone Functions
10 Infotainment system Phone functions* Overview - Phone system components Option/accessory, for more information, see Introduction.
Page 243 Contact your network operator if you • Switch off the system near blasting work. need to change your SIM card. • Volvo recommends that an authorised Volvo workshop carries out phone system servicing. Option/accessory, for more information, see Introduction.
Page 244 10 Infotainment system Phone functions* Phone controls Steering wheel keypad Double SIM cards Many network operators offer two SIM cards for the same phone number. The extra SIM card can be used in the car. Inserting the SIM card 1. Switch off the phone and open the glove- box.
Page 245 10 Infotainment system Phone functions* On/Off Activating from standby mode Call waiting Press PHONE. A two-tone signal during a phone call indicates A handset appears in the display when the Answer? that there is another incoming call. phone system is active or in standby mode appears on the display.
Page 246 6 ñ ö ò Ø see menu 5.4.3, on page 250. This function tact information then this is shown in the dis- only applies to the Volvo integrated phone sys- play. Contact information can be stored on the p q r s 7 ß...
Page 247 10 Infotainment system Phone functions* 6. Scroll to Delete Searching for contacts in the phone book and press ENTER. Calling using speed dial Use the down arrow of the navigation button Briefly press the required keypad button, Erase all contacts instead of MENU for direct access to the followed by ENTER.
Page 248 10 Infotainment system Phone functions* SMS - Short Message Service IMEI number NOTE To block the phone, you must provide your Hold in the required letter/button in the key- Reading SMS network operator with the phone's IMEI num- pad for about 2 seconds to reach the cor- 1.
Page 249: Menu Structure - Phone
10 Infotainment system Menu structure – phone* Phone menu 2.4. Speed dial 4.6.3. Not answered Call register 2.4.1. Active 4.6.4. Not reachable 1.1. Missed calls 2.4.2. Select numbers 4.6.5. Fax calls 1.2. Received calls 2.5. Erase SIM 4.6.6. Data calls 1.3.
Page 250 10 Infotainment system Menu structure – phone* Factory settings 1.5.3. Total time 3. Messages 1.5.4. Reset timers 3.1. Read Received text messages. Select whether to Description of menu options erase, forward, change or save the entire mes- 2. Phone book sage or parts of it.
Page 251 10 Infotainment system Menu structure – phone* 5.1.2. Manual select 4.3. Auto answer 5.5. IDIS Automatically answers incoming calls. If the IDIS function is deactivated, incoming 5.2. SIM security calls are not delayed, regardless of the driving 4.4. Auto redial Select if the PIN code should be on, off or if the situation.
Page 252: Bluetooth Handsfree
Alternative 1 - via the car's menu system compatible with the handsfree function. Volvo recommends that you seek assis- 1. Make the mobile phone detectable/visible tance from an authorised Volvo dealer or via Bluetooth , see the mobile phone's www.volvocars.com for information on manual or www.volvocars.com.
Page 253 10 Infotainment system Bluetooth handsfree* Alternative 2 - via the phone's menu system To call NOTE 1. Make sure that the text PHONE is shown 1. Activate the handsfree function with Some mobile phones require that the at the top of the display and that the PHONE.
Page 254 10 Infotainment system Bluetooth handsfree* More on registering and connecting Phone settings Sounds and volume NOTE Mute radio. A maximum of five mobile phones can be reg- With certain mobile phones the connection istered. Registration is performed once per is terminated when the privacy function is Ring volume phone.
Page 255 10 Infotainment system Bluetooth handsfree* Phonebook the steering wheel keypad. The search can also Inputting text be performed from the phone book's Search Input text using the keypad in the centre con- All use of the phone book presupposes that the menu under Phonebook Search:...
Page 256 10 Infotainment system Bluetooth handsfree* Phone settings 6.1. Call options 6.1.1. Auto reply 6.1.2. Voice mail number 6.2. Sounds and volume 6.3. Synchronise phone book Option/accessory, for more information, see Introduction.
Page 257 Type designation................... 258 Dimensions and weights............... 261 Engine specifications................264 Engine oil....................265 Fluids and lubricants................269 Fuel....................... 271 Catalytic converter................275 Electrical system................... 276 Type approval..................278...
Page 258 S P E C I F I C A T I O N S...
Page 259: 11 Specifications
11 Specifications Type designation...
Page 260 11 Specifications Type designation Knowing the car's type designation, vehicle identification and engine numbers can facili- tate all contact with a Volvo dealer regarding the car and when ordering spare parts and accessories. Type designation, vehicle identification number, maximum permissible weights, codes for colour and upholstery and type approval number.
Page 261 11 Specifications Type designation NOTE The labels shown in the owner's manual are not provided as exact reproductions of those in the car. The purpose is to show their approximate appearance and location in the car. The information that applies to your car in particular is available on the label in question in your car.
Page 262: Dimensions And Weights
11 Specifications Dimensions and weights Dimensions Dimensions Dimensions Dimensions Wheelbase 2640 Load height with roof up Width 1770 Load height with roof Length 4582 Width including door down mirrors 2025 Load length, floor, Front track 1550 folded seat Rear track 1836 Boot lid, raised approx.
Page 263 11 Specifications Dimensions and weights Weights Max. roof load: 75 kg. WARNING Kerb weight includes the driver, the fuel tank The car's driving characteristics change 90% full and all fluids. Towing capacity and towball load depending on how heavily it is loaded and how the load is distributed.
Page 264 11 Specifications Dimensions and weights Maximum weight, braked trailer (kg) Maximum towball load (kg) 1500 Maximum weight, unbraked trailer (kg) Maximum towball load (kg)
Page 265: Engine Specifications
11 Specifications Engine specifications Overview Engine Output Output Torque No. of Bore Stroke Swept Compres- (kW/ (hp/rpm) (Nm/ cylinders (mm) (mm) volume sion ratio rpm) rpm) (litres) B5244S4 103/5000 140/5000 220/4000 90.0 2,435 10.3:1 2.4i B5244S5 125/6000 170/6000 230/4400 90.0 2,435 10.3:1 B5254T7...
Page 266: Engine Oil
Choose a fully synthetic engine oil for adverse ting characteristics, fuel consumption and environmental impact. driving conditions. It provides extra protection for the engine. Volvo Car Corporation disclaims all war- ranty liability if engine oil of the prescribed grade and viscosity is not used.
Page 267 11 Specifications Engine oil Oil decal Engine oil grade Engine variant Volume between Volume MIN-MAX (litres) (litres) B5244S5 2.4i B5244S4 B5254T7 Oil decal location in engine compartment, see page 202. Oil grade: ACEA A3/B3/B4 Viscosity: SAE 0W–30 When driving under adverse conditions, use ACEA A5/B5 SAE 0W-30.
Page 268 11 Specifications Engine oil Engine oil grade Engine variant Volume between Volume MIN-MAX (litres) (litres) 2.0D D4204T Oil decal location in engine compartment, see page 202. Oil grade: WSS-M2C913-B Viscosity: SAE 5W–30 When driving under adverse conditions, use ACEA A5/B5 SAE 0W-30. Including filter change...
Page 269 11 Specifications Engine oil Engine oil grade Engine variant Volume between Volume MIN-MAX (litres) (litres) B5244S5 2.4i B5244S4 B5254T7 D5244T8 D5244T9 (Only Belgium) Oil decal location in engine compartment, see D5244T13 page 202. Oil grade: ACEA A5/B5 Viscosity: SAE 0W–30 Including filter change Europe only, for other markets see oil ACEA A3/B3/B4...
Page 270: Fluids And Lubricants
Do not mix with any other transmission fluid. If the transmission is topped up with a dif- ferent fluid, contact a workshop nearby for servicing. Volvo recommends that you con- tact an authorised Volvo workshop. Gearbox oil Engine...
Page 271 Use a washer antifreeze recommended by Volvo, mixed with water for temper- atures below freezing. Water quality must fulfil the standard STD 1285.1. Refrigerant quantity varies depending on engine variant. Volvo recommends that you contact an authorised Volvo workshop for the correct information.
Page 272: Fuel
11 Specifications Fuel Consumption, CO emissions and tank volume Engine Gearbox Emissions of car- Consumption Tank volume (litres) bon dioxide CO (litre/100 km) (g/km) B5244S5 Manual 5 speed (M56) approx. 62 2.4i B5244S4 Manual 5 speed (M56H) approx. 62 2.4i B5244S4 Automatic gearbox (AW55-51) approx.
Page 273 Always refuel with unleaded petrol so as the car's performance. Mixing different types of fuel or the use of not to damage the catalytic converter. fuel not recommended invalidates Volvo's • Do not use additives not recommended guarantees, and any associated service by Volvo.
Page 274 Only use diesel fuel from and generate increased wear and engine or if you suspect that the car has been filled well-known producers. Never use diesel of damage that is not covered by the Volvo with contaminated fuel. dubious quality. warranty.
Page 275 11 Specifications Fuel speed. Fuel consumption may increase slightly IMPORTANT during regeneration. If the filter fills up it may be incapable of The rear window heating may be activated functioning. Then it can be difficult to start automatically to increase the load on the the engine and there is a risk that the filter will have to be replaced.
Page 276: Catalytic Converter
11 Specifications Catalytic converter General The purpose of the catalytic converter is to purify exhaust gases. It is located in the flow of exhaust gases close to the engine so that it quickly reaches operating temperature. The catalytic converter consists of a monolith (ceramic or metal) with channels.
Page 277: Electrical System
11 Specifications Electrical system General If the battery is changed, replace it with a bat- tery of the same cold start capacity and reserve 12 V system with a voltage-regulated alterna- capacity as the original (see the decal on the tor.
Page 278 11 Specifications Electrical system Lighting Output (W) Type Courtesy lighting, cargo area lighting, number plate lighting Vanity mirror* Tubular lamp Front position/parking lamps, front side marker lamps Fog lamps Glovebox lighting Tubular lamp Option/accessory, for more information, see Introduction.
Page 279: Type Approval
11 Specifications Type approval Remote control key system Certification of the Keyless Drive system Country and Siemens VDO Automotive A.G. hereby certifies region that this equipment type 5WK4 8952, 5WK48956, 5WK48812 conforms to the A, B, CY, CZ, D, DK, essential characteristic requirements and other E, EST, F, FIN, GB, Delphi hereby...
Page 280 11 Specifications...
Page 281 12 Alphabetical Index disarming..........127 Auto volume control........ 231 RDS traffic warning......233 Auxiliary heater.......... 87 reduced alarm level......128 Average fuel consumption......56 electronic climate control..... 82 testing the alarm system....128 ABS fault..........47, 145 Antenna location, Keyless drive....120 Additional heater (Diesel)......
Page 282 12 Alphabetical Index Boot lid operation........244, 252 location in the car, table....... 35 driving with open boot lid....132 volume in phone......... 245 safety............ 34 locking/unlocking........ 122 Car care........... 190 Child seat........... 34 Brake and clutch fluid......206 Car care, leather upholstery....192 Child seats..........
Page 283 12 Alphabetical Index Colour code, paint........194 Display, messages........50 Combined instrument panel...... 45 Display lighting.......... 54 Economical driving........132 Compass........... 67 Dolby Surround Pro Logic II.... 226, 230 ECO pressure.......... 176 calibration..........67 Door mirrors..........69 table............ 176 setting the zone........67 Driver's door control panel....
Page 284 12 Alphabetical Index Engine specifications....... 264 Fog lamps Geartronic..........141 rear............54 Entry, keyless..........72 General information on fuel..... 271 Fog lamps, on/off........54 Environmental labelling, FSC, owner's Glovebox..........103 manual............13 Frequency update, automatic....235 locking..........114 EON - Enhanced Other Networks.... 235 FSC, environmental labelling.....
Page 285 12 Alphabetical Index IDIS – Intelligent Driver Information Sys- Jack............179 Lambda-sond.......... 275 tem............242 Leather upholstery, washing instructions 192 Ignition keys..........137 Lighting IMEI number..........247 approach light, duration....... 69 automatic lighting....... 101 Immobiliser........112, 137 Kerb weight..........262 automatic lighting, dipped beam..
Page 286 12 Alphabetical Index front............ 210 speedometer......... 45 interior lighting, roof......215 tachometer........... 45 main beam.......... 211 Main/dipped beam, see Lightning..... 53 trip meter..........45 number plate lighting......214 Main beam Misting parking lamps........212 flashing..........55 attending to the windows..... 78 position lamps........
Page 287 12 Alphabetical Index keyless entry......... 72 Power steering fluid, checking and topping lock confirm. light......... 72 up............. 206 PACOS............23 recirculation timer......... 71 Power windows......... 65 unlock confirm. light......72 PACOS, switch.......... 23 passenger seat........66 Petrol grade..........272 Paintwork Privacy locking.........
Page 288 12 Alphabetical Index Reading lamps, see Lighting....100 Remote control key......... 137 battery replacement......121 Rear seat detachable key blade......113 Safety boarding..........90 functions..........112 safety systems, table......31 Rearview and door mirrors Remote control key system, type appro- Scan automatic retracting/extending..
Page 289 12 Alphabetical Index Soot filter........... 50, 274 Storage compartment......102 Timer CD discs..........104 ECC............81 Soot filter full..........274 Storage spaces in the passenger compart- Tools............179 Sound ment............102 audio settings......228, 229 Total airing function......... 123 audio source........228 Storing stations, manual and automatic..
Page 290 12 Alphabetical Index Tyres media player........228 snow chains........173 direction of rotation......175 programme types....... 236 spare wheel........179 driving characteristics......172 Whiplash injury.......... 28 general..........172 WHIPS maintenance........172 child seat/booster cushion....28 pressure........176, 177 whiplash injury........28 puncture repair........
Page 291 12 Alphabetical Index...
Page 292 Notes...
Page 293 Notes...
Page 294 Notes...
Page 295 Notes...
Page 296 Notes...
Page 297 Notes...

Volvo C70 Owner's Manual

Introduction

1 Safety

2 Instruments and Controls

3 Climate Control

4 Interior

5 Locks and Alarm

6 Starting and Driving

7 Wheels and Tyres

8 Car Care

9 Maintenance and Service

11 Specifications

Quick Links

Owners Manual

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Volvo C70

Summary of Contents for Volvo C70

Table of Contents
