WHYNTER ECO-FRIENDLY 14,000 BTU PORTABLE AIR CONDITIONER WITH 3M FILTER
co
MODEL# : ARC-143MX
Instruction Manual
Congratulations on your new WHYNTER product. Please read this Instruction Manual carefully before using
this product to ensure proper operation. Keep this manual in a safe place for future reference.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Whynter ARC-143MX
Summary of Contents for Whynter ARC-143MX
- Page 1 WHYNTER ECO-FRIENDLY 14,000 BTU PORTABLE AIR CONDITIONER WITH 3M FILTER MODEL# : ARC-143MX Instruction Manual Congratulations on your new WHYNTER product. Please read this Instruction Manual carefully before using this product to ensure proper operation. Keep this manual in a safe place for future reference.
- Page 2 Please follow the instructions provided in this user guide to obtain the very best performance from your portable air conditioner and take full advantage of the many features your portable air conditioner offers you. We trust that your Whynter air conditioner will provide the performance and reliability that we stand for.
-
Page 3: Safety Precautions
Your safety and the safety of others are very important to us. To reduce the risk of fire, electrical shock or injury when using your appliance, follow these basic precautions. SAFETY PRECAUTIONS Before the portable air conditioner is used, it must be properly positioned and installed as detailed in this manual. -
Page 4: Operating Condition
Always place the unit on even and hard and level surface. Do not sit or place objects on the unit. Do not allow children to climb, stand or hang on the unit. The air conditioner could tip over and get damaged and/or seriously injure somebody. -
Page 5: Identification Of Accessories
IDENTIFICATION OF ACCESSORIES IMAGE ACCESSORY NAME QUANTITY Exhaust hose 2 pieces Fixture 2 pieces Screws 8 pieces Hose connector 4 pieces 1 set Window slider kit Cover 2 pieces Remote control 1 piece P a g e... -
Page 6: Identification Of Parts
IDENTIFICATION OF PARTS Front 1. Air vent 2. Control panel Rear 3. Evaporator air intake / air filter 4. Air intake hose 5. Air exhaust hose 6. Casters 7. Drain port 8. Power cord P a g e... -
Page 7: Operating Your Air Conditioner
OPERATING YOUR AIR CONDITIONER Before you begin, thoroughly familiarize yourself with the control panel, remote control and all of the functions. Follow the symbol for the desired function. The unit can be controlled by the unit control panel alone or with the remote control. CONTROL PANEL Timer Power Control... -
Page 8: Installation Instructions
4. Only extend the exhaust hoses to the necessary length. We do not recommend extending the exhaust hose more than 9' long. If you are interested in purchasing an additional 5’ exhaust hose please contact info@whynter.com for retail sales information. P a g e... - Page 9 Window kit Installation When you use this air conditioner unit, hot air must be exhausted out of the room to complete the air exchange of the condenser. When the unit is operating in dehumidifying and fan-only mode, no exhaust is required. Your window kit has been designed to fit most standard vertical and horizontal windows.
-
Page 10: Air Filters Installation
AIR FILTERS INSTALLATION Your Whynter portable air conditioner is equipped with a washable Pre-Filter and a 3M™ Antimicrobial High Air Flow (HAF) Air Filter. The washable Pre-Filter removes large particles such as dust, pet hair and dander. The 3M™ Antimicrobial High Air Flow (HAF) Air Filter is a frameless and self-supporting air filter designed to do the following. -
Page 11: Operation Instructions
OPERATION INSTRUCTIONS BEFORE USING YOUR PORTABLE AIR CONDITIONER Remove the exterior and interior packaging. Before connecting the unit to the power source, let it stand upright for approximately 4 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. -
Page 12: Water Drainage
TIMER (DELAYED SWITCH ON / OFF) FUNCTION This function mode enables a delayed switch ON or delayed switch OFF of the air conditioner. The time (hours) delay can be set, enabled and disabled. The timer is adjustable between 1-24 hours. SETTING SWITCH OFF TIMER With the air conditioner operating in any function mode, press the Timer Control button. -
Page 13: Remote Control
REMOTE CONTROL The portable air conditioner can be switched on by the remote control. NOTE: Other appliances in the same room controlled by a remote control (TV, radio, stereo, etc.), may cause interferences. Electronic and fluorescent lamps may interfere with the signal transmissions between the remote control and the air conditioner. -
Page 14: Care And Maintenance
CARE AND MAINTENANCE IMPORTANT: Switch off the air conditioner and disconnect the plug from the power outlet Drain water by removing the drain plug. Always transport the air conditioner in an upright position only. CLEANING THE PRE-FILTER ... -
Page 15: Technical Data
TECHNICAL DATA Model ARC-143MX Cooling capacity 14,000 BTU Power supply 115v/ 60Hz Maximum power input 1250 Watts Maximum input 10.8 Amps Dehumidifying capacity 91 Pts / Day Thermostat 61°F to 89°F Refrigerant R-410A Air flow (max.) 384 m3/ Hour Fan speeds 3 (H, M, L) 49”... -
Page 16: Troubleshooting
TROUBLESHOOTING Problem Possible Causes Solutions The portable air Power failure / outage. Restore the power supply. conditioner does not turn on The automatic switch, line Flip the switch / change the fuse / turn the fuse, or breaker has been breaker back on. - Page 17 Windows or doors are open. Close all windows and doors. The unit has worked for a long time, but the There are too many people in You may need additional cooling or another room is not cold the room. air conditioner. enough There is direct sunshine into Close curtains or blinds and try to minimize...
- Page 18 MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. WHYNTER SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY.
