Exploded Views-Mechanical Parts List - Infinity TSS-SUB4000 Service Manual

TSS-SUB4000
Ref #
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Not
Shown
TSS-SUB4000 EXPLODED VIEW
Description
Grille
Woofer/Trim Ring Screw
Trim Ring
Woofer 12" (305mm) MMD
Port Tube
TSS-SUB4000 Amplifier
Amplifier Screw
TSS-SUB4000 Cabinet
Rubber Foot
Foot Screw
Gasket
LED
Plastic Plate
Aluminum Plate
Power Transformer
Part Number
329-120-05097-0VA
351-AM04030A893
213-120-05033-0BA
30PR14BW-DW01
249-HIPS-05021-0VA
Not for Sale
352-FM04020D605
Not for Sale
320-RUB-05030-0BA
352-CM04025D604
333-EVA-05091-0WA
166-A055A8GX
Not Serviceable
Not Serviceable
150-R1107008
7
Qty
1
8
1
1
1
1
12
1
4
4
1
1
1
1
1
