GMR
Properly install your GMR 400/600/1200 xHD radar according to the following instructions. If you experience difficulty installing the
chartplotter, seek the assistance of a professional installer, or contact Garmin
Before installing your GMR 400/600/1200 xHD radar, confirm that the package contains the items listed on the box. If any parts are missing,
contact your Garmin dealer immediately.
WarnInG: Always wear safety goggles, ear protection, and a dust mask when drilling, cutting, or sanding.
WarnInG: The selected radar mounting location must be able to hold the weight of the radar and withstand any inertial forces.
WarnInG: The radar transmits electromagnetic energy. It is important that the radar is turned off or the DC power input is disconnected when
personnel are required to come close to the radar to perform work on the radar assembly or associated equipment. Electromagnetic energy is harmful.
CaUTIOn: When the radar is transmitting, do not look directly at the antenna at close range, because the eyes are the most sensitive part of the body to
electromagnetic energy.
nOTICe: When drilling or cutting, always check the opposite side of the drilling or cutting surface.
Product Registration
Help us better support you by completing our online registration today. Go to http://my.garmin.com. Keep the original sales receipt, or a
photocopy, in a safe place.
Contact Garmin
Contact Garmin Product Support if you have any questions while installing your GMR 400/600/1200 xHD radar. In the USA, go to
www.garmin.com/support, or contact Garmin USA by phone at (913) 397.8200 or (800) 800.1020.
In the UK, contact Garmin (Europe) Ltd. by phone at 0808 2380000.
In Europe, go to www.garmin.com/support and click
phone at +44 (0) 870.8501241.
Needed Tools
For Installing the Radar:
• #2 Phillips screwdriver
• 5 mm Allen wrench
• Drill and drill bits
• Wrench and socket set
For Installing the Optional Field-Installable RJ-45 Network Connector:
• Knife
• Pliers
• 15 mm wrench
• AMP modular-plug hand tool and die set or compatible equivalent
September 2012
400/600/1200 xHD Radar Installation Instructions
™
Contact Support
Product Support.
®
for in-country support information, or contact Garmin (Europe) Ltd. by
190-01266-02 Rev. D
Printed in Taiwan
