iOptron #9102 Quick Start Manual

Quick Start Guide

®
AstroBoy -70e Computerized Telescope
With Electronic Eyepiece
#9102 (Astro Blue)
FEATURES
•
Alt-Azimuth Mount with GoToNova
•
Computerized automatic pointing and tracking
•
4,000+ object database with 256 user-definable objects.
•
4 line, 21-character LCD hand controller with backlit LED buttons for easy operation
•
Dual-axis servomotor with optical encoders
•
Drive motor with 5-speed setting for precise tracking
•
Push-to alignment
•
70mm achromatic refractor telescope for land and celestial objects observation
•
Aluminum tripod
•
Electronic Eyepiece for viewing & capturing video and photos with a computer.
PACKAGE CONTENTS
®
•
AstroBoy Telescope mount
•
70mm Refractor telescope with 45º
erect diagonal
•
1-inch aluminum tripod
ONLINE CONTENTS (click under "Support" menu button) www.iOptron.com
•
Full manual
(you can refer to the full manual for more details on set-up and operation).
•
Tips for operating
•
Reviews and feedback from other customers.
•
Connect with other users on our Facebook page (Search "Astroboy-70e").
•
Accessories information
Assembly Terms
1. Telescope Tube
2. Dovetail Lock
3. Altitude Lock
4. #8404 Hand Controller
5. Hand Controller
6. Aluminum Tripod
7. Diagonal
8. Computer
(not included)
9. Electronic Eyepiece
10. Optical Eyepieces
(not shown)
NEVER USE A TELESCOPE TO LOOK AT THE SUN DIRECTLY! Looking at or
near the Sun will cause instant and irreversible damage to your eye. Children
should always have adult supervision while observing.
