SUMMIT CONVECTION OVEN
MODEL: SUMG-100 (GAS)
Toll Free Phone, (US & Canada): (800) 427-6668
Toll Free Fax, (US & Canada): (800) 361-7745
http://www.garland-group.com
FORM # SUMG-100 Conv Oven (Rev3)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUMG-100 (GAS) and is the answer not in the manual?

Questions and answers

Related Manuals for U.S. Range SUMG-100 (GAS)

Summary of Contents for U.S. Range SUMG-100 (GAS)

  • Page 1 SUMMIT CONVECTION OVEN MODEL: SUMG-100 (GAS) Toll Free Phone, (US & Canada): (800) 427-6668 Toll Free Fax, (US & Canada): (800) 361-7745 http://www.garland-group.com FORM # SUMG-100 Conv Oven (Rev3)
  • Page 2 Page 2 FORM # SUMG-100 Conv Oven (Rev 3) FORM # SUMG-100 Conv Oven (Rev 2)

  • Page 3: Table Of Contents

    SUMMIT CONVECTION OVEN MODEL: SUMG-100 (GAS) Contents: Control Panel – IM200 – Solid State Controls W/Electro-Mechanical Timer ... Page 4 Oven Interior Components ... Page 8 Burner Section ... Page 10 Dependent Door Section (For Units Manufactured To April 14, 2005) ... Page 12 Dependent Door Section (For Units Manufactured After April 14, 2005) ...

  • Page 4: Control Panel - Im200 - Solid State Controls W/Electro-Mechanical Timer

    IM200 MANUAL CONTROL PANEL MODELS: SUMG-100 IM200 Manual Control Panel Page 4 FORM # SUMG-100 Conv Oven (Rev 3)
  • Page 5 ITEM PART # 1815001 Honeywell Ignition Module 1935601 Johnson Ignition Module, IPI CK02-008 Ignition Module, IPI Kit 1804726 Wiring Harness Ignition 115/60 1949595 Wiring Harness Pilot Ignition 1949593 Wiring Harness Pilot Ignition 1842901 Flange Mount Oven Probe 1906002 Probe - Rtd, Flange Mount 1842902 Probe Interconnect Harness 1906003...
  • Page 6 ITEM PART # 1946690 Control Panel Assembly - IM200 1956002 Timer - 1 Hr, 240V W/Alarm 1955601 Potentiometer-IM200 150-500Deg 1765802 Fluted Knob W(2) Set Screws 1955401 Switch-Rocker,Dpdt On-Off-On 1955402 Switch-Rocker,Dpdt High/Low 1955403 Switch-Rocker,Spst Momentary 1006493 Pilot Light Green 240V 1936102 Indicator Lamp-Green, 250V 1270000 Amber Pilot Light 28V...
  • Page 7 NOTES FORM # SUMG-100 Conv Oven (Rev3) Page 7...

  • Page 8: Oven Interior Components

    INTERIOR OVEN COMPONENTS MODELS: SUMG-100 Interior Oven Components Page 8 FORM # SUMG-100 Conv Oven (Rev 3)
  • Page 9 ITEM PART # 1921399 Panel - Cavity Back, Gas GCE 1921599 Panel - Cavity Top, Standard Gas GCE 1922399 Panel - Cavity Bottom, Standard GCE 1928101 Panel - Cavity Back, S/S 1925601 Panel - Cavity Top, Standard SS CP 1922301 Panel - Cavity Bottom,Standard SS 1928203 Plate - Core Probe Patch...

  • Page 10: Burner Section

    OVEN BURNER MODELS: SUMG-100 60/80K BTU Burner Section Page 10 FORM # SUMG-100 Conv Oven (Rev 3)
  • Page 11 ITEM PART # 1095499 Straight Connector Assembly 3/8X7/16 CC 1095499 Straight Connector Assembly 3/8X7/16 CC 1004845 Reducer Coupling 1/2 X 3/8 1811101 Coupling 1/4 CC X 1/4 CC 1916101 Manifold 1804350 #50 - Natural Orifice 1804356 #56 - LPropane Orifice 1804348 Natural Orifice (.078”) 1027499...

  • Page 12: Dependent Door Section (For Units Manufactured To April 14, 2005)

    DEPENDENT DOOR SYSTEM MODELS: SUMG-100 For unit manufactured up to April 14/05 DOOR SEALS (no latch) DOOR SEALS (no latch) (w/ latch) CHAIN Dependent Door System Page 12 FORM # SUMG-100 Conv Oven (Rev 3)
  • Page 13 Door Section - Units Manufactured Up To April 14, 2005 ITEM PART # 1924395 Handle - Door, Black 1924396 Handle - Door, Black 1923997 Panel - Left Door Liner Window 1923996 Panel - Left Door Liner Solid 1923899 Frame W/A - Left Door 1010999 Oven Door Window (3/16”...
  • Page 14 Door Section - Units Manufactured Up To April 14, 2005 ITEM PART # Plate Door Handle 1928209 From serial # 0301CJ0082 Door Chain Assembly 4520166 Include Items: 30, 31, 32, 33, 34 Door Left W/Window 1924869 Include Items: 2, 8, 3, 20, 4, 1, 5a Door Right W/Window 1924965 Include Items: 6b, 7b, 9, 20, 4, 11...
  • Page 15 NOTES FORM # SUMG-100 Conv Oven (Rev3) Page 15...

  • Page 16: Dependent Door Section (For Units Manufactured After April 14, 2005)

    DEPENDENT DOOR ASSEMBLIES MODELS: SUMG-100 SUMMIT For Units Manufactured After April 14/05 Door Seals Door Switch Section Chain Right Door Left Door Page 16 FORM # SUMG-100 Conv Oven (Rev 3)
  • Page 17 Door Assemblies - Units Manufactured After April 14, 2005 ITEM PART # 1924396 Door Handle - Black Panel - Left Door Liner Window 1923997 Used in Prison Door Assembly Also Panel - Left Door Liner Solid 1923996 Used in Prison Door Assembly Also Panel - Right Door Liner Solid 1923998 Used in Prison Door Assembly Also...
  • Page 18 Door Assemblies - Units Manufactured After April 14, 2005 ITEM PART # 8001210 Nut Hex 3/8-16 Stl 2P 8000308 Washer - Flat 3/8x3/4 Stl 2P Kits Door Assemblies - Units Manufactured After April 14, 2005 4520318 Door Left W/Window 4520319 Door Right W/Window 4520321 Door Right Solid...
  • Page 19 NOTES FORM # SUMG-100 Conv Oven (Rev3) Page 19...

  • Page 20: (For Units Manufactured To April 14, 2005)

    DEPENDENT DOOR SYSTEM (PRISON) MODELS: SUMG-100 SUMMIT For Units Manufactured Up To April 14, 2005. DOOR SEALS DOOR (no latch) SEALS (w/latch) CHAIN Dependent Door System Page 20 FORM # SUMG-100 Conv Oven (Rev 3)
  • Page 21 Door Section - Prison Package - Units Manufactured Up To April 14, 2005 ITEM PART # 1924396 Handle - Door, Black 1923997 Panel - Left Door Liner Window 1923996 Panel - Left Door Liner Solid 1923899 Frame W/A - Left Door 1010999 Oven Door Window (3/16”...

  • Page 22: (For Units Manufactured After April 14, 2005)

    DEPENDENT DOOR ASSEMBLIES MODELS: SUMG SUMMIT (PRISON) For Units Manufactured After April 14/05 Door Seals Door Switch Section Chain Right Door Left Door Page 22 FORM # SUMG-100 Conv Oven (Rev 3)
  • Page 23 Door Assemblies - Prison Package - Units Manufactured After April 14, 2005 ITEM PART # 1924396 Door Handle - Black 1923997 Panel - Left Door Liner Window 1923996 Panel - Left Door Liner Solid 1923998 Panel - Right Door Liner Solid 4520373 Weld Assembly Frame Left Door Extended Bearing Plate Weld Assembly Frame Right Door...

  • Page 24: Main Exterior

    MAIN EXTERIOR MODELS: SUMG-100 Main Exterior.dwg Page 24 FORM # SUMG-100 Conv Oven (Rev 3)
  • Page 25 ITEM PART # Covers Side & Top - Stainless Steel & Prison Package 1917602 Cover - Top, SS 1920201 Cover - Body Side Left, SS 1918701 Cover - Body Side Right, SS 1920701 Cover - Main Top Trim 1925901 Cover - Control Panel, RT SS USR 1925801 Cover - Control Panel Left USR 1925301...
  • Page 26 ITEM PART # 1926531 Heavy Duty Caster - Double Deck 1926532 Heavy Duty Caster - Double Deck w/Brake 1926521 Lo Profile Caster - Double Deck 1926522 Lo Profile Caster - Double Deck w/Brake 1029426 3/8 BX Cable 26 Long 1927898 Cover - External Terminal Block (208/240V 60HZ Gas) 1193900 Terminal Block 3 Pole (208/240V 60HZ Gas)

  • Page 27: Parts Digital Photos

    G03559-1 TRANSFORMER 50/60HZ - CLASS 1955501 P OWER ONTROL 1906002 P – F ROBE LANGE FORM # SUMG-100 Conv Oven (Rev3) 1918201 P 1956001 T OARD CK02-008 I OUNT 115V OLAR – 1H . 115V IMER GNITION ODULE Page 27...
  • Page 28 1935802 P “B” 1935801 P ILOT ATURAL ILOT SSEMBLY ROPANE OUNT 1935701 V 4” ALVE UAL W SHUT WC (60 & 80K) RISON ACKAGE ONVECTION 1757998 L ATCH ENCH SSEMBLY Page 28 FORM # SUMG-100 Conv Oven (Rev 3)
  • Page 29 1925005 D 1955001 MICRO SWITCH HI-TEMP ATCH RACKET 15 AMP FORM # SUMG-100 Conv Oven (Rev3) Page 29...

  • Page 30: Revision History

    REV. # PAGE # ITEM # 17, 18, 19 13,14 16,17,18 22,23 10.11 Page 30 US RANGE PARTS IDENTIFICATION Revision Histor NOTE Parts List Book Released Rearranged Item Number Part Numbers Added 1955001 Replaced by 4519715 New Part Number Added CK1138 Replaced By 4520166 3 New Pages Added –...
  • Page 31 NOTES FORM # SUMG-100 Conv Oven (Rev3) Page 31...
