OWNER'S GUIDE
Model #1.7RS
Keyless Entry / Security /
Introduction
Welcome to the convenience and security of your Model One system. Model One
systems are designed and manufactured by Omega Research and Development, a
world leader in vehicle convenience and security since 1975. Your system offers easy,
carefree operation, and the modular design allows its many impressive features to be
customized to suit your needs
Therefore, please note that this guide is written to reflect:
-
that a power doorlock interface is installed with your system. This interface may
vary from one vehicle to the other, and in some cases may involve optional
components.
-
that the vehicle's horn is used for the audible output; an optional electronic siren
is also available.
-
the Programmable Features in the default settings; the operations of these
features, if selected otherwise, are also explained in detail.
The addition of an optional sensor is also affects the exact operations, as several types
of auxiliary threat-detection sensing devices are available.
This sophisticated, state-of-the-art product deters theft of your vehicle, and its
contents. Model One systems are designed for professional installation, and are
available through new car retail outlets only.
ONE
Starting
COPYRIGHT: OMEGA RESEARCH & DEVELOPMENT, INC. 1999
Page - 3
Table Of Contents
Introduction
Remote Transmitter, LED Status Light & Valet Switch
Active Arming & Sensor By-Pass .............................................................................
Passive Arming ........................................................................................................
Disarming .................................................................................................................
The Armed System .................................................................................... 9-11
.........................................................................................................
Selectable Code Override ..................................................................................
Remote Panic .......................................................................................... 14-15
The LED Status Light
System Status, ATV
Audible and Visual Indicators ................................................................... 17-18
Option Output and Additional Output ............................................................. 19
Shock Sensor Port with Prewarn ................................................................... 22
Programming Transmitters ....................................................................... 22-25
Programming Features ............................................................................. 25-28
Programmable Features ........................................................................... 29-39
Limited Lifetime Warranty ............................................................... Back Cover
Your Model One system has three principal user components: the Remote
Transmitter, the red LED Status Light and the Valet Switch.
The Remote Transmitter: Each system is capable of being operated by up to four
different remote transmitters. The remote transmitter has four push-button switches,
each being labeled as to function. These are:
-
The LOCK button arms the security system, which also locks the doors. This
button can also operate an additional "option" output.
-
The UNLOCK button disarms the security system, unlocking the doors. This
operation can be configured to unlock the driver's door only upon one press of the
button; then, if desired, all of the doors upon a second press of the button.
-
The OPTION button is used to silently arm or disarm the system, and can also
operate an additional remote control function such as trunk release.
-
The PANIC button is used to easily engage and disengage the panic feature.
-
Pressing LOCK and UNLOCK buttons for 2 seconds activates remote starting.
The Red LED Status Light: Informs you at a glance of the different conditions the
security system is in and also serves as a visual deterrent to break-ins and theft.
The Valet Switch: Is used to access Valet Mode, which allows the operator to
suspend some of the system's normal functions. The valet switch may also be used,
instead of the remote transmitter, to override an armed and activated system.
..................
) ................................ 5
TM
& Zone Violation ......................
Page - 2
Page - 4
3-4
6-7
7-8
8-9
11-12
12-14
15-17
