- Page 1 OP-02 / OP-03 / OP-04 WM+PD4001368...
-
Page 2: Table Of Contents
Contents 1. OP-02 BATTERY ....................2 1-1. Using the OP-02 SLA Battery..............2 2. OP-03 RS-232C / RELAY OUTPUT ..............4 2-1. Installation ....................4 2-2. OP-03 Specifications ................. 5 2-3. Command Mode..................7 2-4. Using UFC (Universal Flex Coms) function..........11 3. -
Page 3: Battery
1. OP-02 BATTERY 1-1. Using the OP-02 SLA Battery The scale can be operated with an SLA (Sealed Lead Acid) battery that will be commercially available. The scale (with no other options) can be operated with a fully charged battery for; LCD backlight OFF and Comparator light OFF: approximately 80 hours LCD backlight OFF and Comparator light ON: approximately 55 hours LCD backlight ON and Comparator light ON: approximately 25 hours... -
Page 4: Charging The Battery
1. Disconnect the main power cord from the outlet. 2. Remove the ten hexagon head screws and open the rear cover. Take care not to drop the rear cover or the wires connecting between front display and rear cover will be damaged. 3. -
Page 5: Rs-232C / Relay Output
2. OP-03 RS-232C / RELAY OUTPUT This interface allows the FS-i series to be connected with a multifunction printer or a personal computer, and the relay outputs for comparator result are obtained. The OP-03 unit includes an interface board, a connector cable, a cable gland and two screws (M3x6). -
Page 6: Specifications
1. Disconnect the main power cord from the outlet. 2. Remove the ten hexagon screws and open the rear cover. 3. Connect the cable from external device through the cable gland to the terminal blocks on the interface board. Also connect a yellow/green wire inside the display pod directly to “FG”... -
Page 7: Data Format
Circuit diagram 1 Receive data RXD 2 Transmit data TXD 3 Data set ready DSR 4 Signal ground SG 5 Shield SHLD 6 Frame ground FG FS-i is designed as DCE (Data Communication Equipment). 1 Relay output HI 2 Relay output LO 3 Relay output OK 4 Relay common COM Solid sate relay... -
Page 8: Command Mode
Out of rage (+) + 9 9 9 9 9 9 9 9 _ k g Data output mode (F06) Stream Mode (F06-0) Data is sent continuously. The data-update rate is approximately 20 times per second. But for 2400 bps, it is too slow to send 20 times. If necessary, set the baud rate 4800 bps or more. - Page 9 Command Definition Notes Clear tare weight. Including preset tare. Send a preset tare weight in-use. Send a tare weight in-use. Send a target weight in-use. Send a HI limit value or upper limit weight in-use. Send a set value. Send a LO limit value or lower limit weight in-use. Set a target weight.
- Page 10 Set a preset tare weight. (No reply for F20-1.) P T , + 0 0 1 2 0 0 C L Command Decimal point follows the weight display. P T , + 0 0 1 2 0 0 C L Reply FS-15Ki : The preset tare weight 1.200 kg is subtracted and the display shows net weight.
- Page 11 O K , + 0 0 1 0 0 0 C L Reply FS-15Ki : Target weight 1.000 kg will be set. Set a HI limit value or upper limit weight. (No reply for F20-1.) F07-0 or F07-1 is set, the command should have “+” and 6 digit number without decimal point.
-
Page 12: Using Ufc (Universal Flex Coms) Function
Command M L , 0 1 , + 0 0 1 0 0 0 , + 0 0 0 2 0 0 , + 0 0 0 1 0 0 C L Reply M L , 0 1 , + 0 0 1 0 0 0 , + 0 0 0 2 0 0 , + 0 0 0 1 0 0 C L FS-15Ki : Store target weight 1.000 kg, upper limit weight +0.200 kg and lower limit weight +0.100 kg into the memory number “01”. - Page 13 The maximum number of text data is 300 characters. To use the UFC function, the text data has to be sent to the scale from the computer using “PF” command in the command mode (F06-1) in advance. Then, connect the scale with the printer and set the F06-2, F06-3 or F06-4. When the PRINT key is pressed or by auto-print mode (F06-2, F06-3 or F06-4), the scale will send the stored text data with the parameters replaced by the original data.
- Page 14 If you will send more than 2 lines of data, attach “&” to the end of the first line. Then, the scale considers the data to be continued. A “Space” or “,” will be used to separate these data. You can skip them to reduce the number of characters, but you cannot skip “,”...
-
Page 15: Rs-422 / 485 / Relay Output
3. OP-04 RS-422 / 485 / RELAY OUTPUT This interface allows a personal computer to connect and control up to 16 FS-i scales, and the relay outputs for comparator result are obtained. The OP-04 unit includes an interface board, a connector cable, two cable glands and two screws (M3x6). -
Page 16: Specifications
Installation is similar to the OP-03. See “2-1. Installation”. Set the function parameters F04, F05, F06, F18, F19 and F20 according your application. The function setting F19-1 must be set for RS-422 and F19-2 must be RS-485. To connect more than one scale with a computer, set a different address to each scale by F18-##. -
Page 17: Data Output
Example of connection RS-422 RS-485 Terminator (may be Terminator (may be built in the computer). built Host computer Host computer FS-i FS-i Address 01 Address 01 (F18-01) (F18-01) FS-i FS-i Address 02 Address 02 (F18-02) (F18-02) FS-i FS-i Address 16 Address 16 (F18-16) (F18-16) - Page 18 Examples of command and reply ( “_” shows “Space” (20H).) Following examples are for F20-0 (Reply to command is sent.) The address ## = 23 (F18-23). Request a weight data. @ 2 3 Q C L Command @ 2 3 S T , + 0 0 1 2 . 3 4 5 _ k g C L Reply Stable data @ 2 3 U S , + 0 0 0 7 .
