Installation Manual

GPS RECEIVER GP-310B
SAFETY INSTRUCTIONS ...........................................................................i
SYSTEM CONFIGURATION ......................................................................1
EQUIPMENT LISTS ...................................................................................2
1. MOUNTING ............................................................................................3
2. WIRING ..................................................................................................4
3. DEFAULT SETTINGS .............................................................................7
SPECIFICATIONS ................................................................................SP-1
PACKING LIST ....................................................................................... A-1
OUTLINE/INTERCONNECTION DRAWING .......................................... D-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP-310B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Furuno GP-310B

  • Page 1: Table Of Contents

    Installation Manual GPS RECEIVER GP-310B SAFETY INSTRUCTIONS ...i SYSTEM CONFIGURATION ...1 EQUIPMENT LISTS ...2 1. MOUNTING ...3 2. WIRING ...4 3. DEFAULT SETTINGS ...7 SPECIFICATIONS ...SP-1 PACKING LIST ... A-1 OUTLINE/INTERCONNECTION DRAWING ... D-1...
  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS CAUTION Do not use the equipment for other than its intended purpose. Improper use of the equipment can result in personal injury or equipment damage. No one navigation device should ever be solely relied upon for the navigation of a vessel.
  • Page 4 This page is intentionally left blank.
  • Page 5: System Configuration

    SYSTEM CONFIGURATION This antenna incorporates a GPS receiver. It can be connected directly to NAVnet equipment and Multi Display RD-30. However, if it connected to an equipment other than the NAVnet product, a junction box (local supply) is required. NAVnet Series...
  • Page 6: Equipment Lists

    EQUIPMENT LISTS Standard supply No. Name GPS Receiver Optional equipment No. Name Cable Assembly Mast mounting kit Type Code No. GP-310B Type Code No. MJ-A7SPF/SRMD-100 000-144-534 CP20-0111 004-365-780 Qty Remarks With 10m cable Qty Remarks...
  • Page 7: Mounting

    Select a location out of the radar beam. The radar beam will obstruct or prevent reception of the GPS satellite signal. The location should be well away from a VHF antenna. A GPS receiver is interfered by a harmonic wave of a VHF antenna.
  • Page 8: Wiring

    A ten meter cable is attached to this unit. If the distance between this unit and monitor more than 10 m, use optional extension cable (10 m). Up to four extension cables can be connected serially. Connecting to FURUNO NAVnet equipment w/cable 10 m Cable assy.
  • Page 9 To connect battery of over 31.2 VDC, contact your dealer to request connection of external circuit. Note2) When connecting a FURUNO external DGPS beacon receiver (such as the GR-80) to this unit, set the external DGPS beacon receiver as follows: Byte Format, 8-6;...
  • Page 10 Output/Input data format Priority Input data High XXGGA Position XXZDA UTC date XXGLL Position XXRMC Position, UTC date Note1) Data output in order from high to low priority. Note2) GPDTM data is attached in front of GPGGA, GPGLL and GPRMC when each of those sentences is output.
  • Page 11: Default Settings

    3. DEFAULT SETTINGS Setting GPS data Initial Latitude/Longitude UTC Time Antenna Height Almanac Data Almanac Date Ephemeris Data Receiver Local Zone Time parameter PDOP Geometric Datum MASK Elevation Disable satellite Smoothing Dynamic Data Output Cycle DGPS Setting Parameter 1 (LSB first) Note) For connecting to equipment other than a NAVnet product, the monitor displays the latitude and longitude of Nishinomiya, Japan as initial position for about 90 seconds after the power is turned on.
  • Page 12: Specifications

    Ambient Temperature Relative Humidity Water proofing Vibration COATING COLOR Antenna Unit GP-310B 12 channels parallel, 12 satellite tracking 1575.42 MHz C/A code All in view, 8-state Kalman filter 10 m approx., 95% of the time (HDOP 5 m approx., 95% of the time...
  • Page 13: Packing List

    PACKING LIST PACKING LIST PACKING LIST PACKING LIST GP-310B (E) GP-310B (E) GP-310B (E) GP-310B (E) N A M E ユニット ユニット UNIT UNIT ユニット ユニット UNIT UNIT GPS受信機 GPS RECEIVER (略図の寸法は、参考値です。 (略図の寸法は、参考値です。 (略図の寸法は、参考値です。 (略図の寸法は、参考値です。 DESCRIPTION/CODE № O U T L I N E GP-310B-E 000-144-512 DIMENSIONS IN DRAWING FOR REFERENCE ONLY.)...
  • Page 16 All rights reserved. All rights reserved. Printed in Japan Printed in Japan PUB.No. PUB.No. IME-44120-C IME-44120-C ( ( TENI TENI ) ) GP-310B GP-310B Your Local Agent/Dealer Your Local Agent/Dealer FIRST EDITION : FIRST EDITION : MAR. MAR. 2001 2001 : APR.
