Sunbeam MR.Coffee ARX23 Service Manual

Household Products
COFFFEMAKERS
AR SERIES
900 Watts, 120 V., 60 Hz.
KEY # DESCRIPTION
1 DUST LID-WHT
1 DUST LID-BLK
2 BREW BASKET ASSY.-WHT
2 BREW BASKET ASSY.-BLK
3 DECANTER LID
4 WARMING PLATE
5 HEATER ASSY.
6** SWITCH ON/OFF
7 CONTROL MODULE
8 DECANTER
8 DECANTER
9 FEET
- INST. BOOK
** NOT SHOWN IN DRAWING
SERVICE MANUAL 2001
AR12
AR13
ARX20
ARX23
BASIC PARTS X
PART # QUANTITY REQ'D
108430-000-000
108430-006-000
108430-001-000
108430-007-000
108430-003-000 1
108430-005-000 1
108430-004-000 1
108430-002-000
108430-008-000
PD12ME
PD13ME
108430-009-000 2
107607-000-000 1
10/31/2001
2001
X PART NO.
X
X
X
X
1 2 3 4
5
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
