Prestige Owner’s Manual Owner's Manual

Long range remote start security system with plug-in shock sensor & starter disable
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Long Range Remote Start Security System
With Plug-In Shock Sensor & Starter Disable
IMPORTANT ! In order to provide you with the highest level of security to your
vehicle, this system is equipped with selectable manual override circuitry. It is
possible that you will need to override you security system if the transmitter
becomes lost, or inoperative due to battery failure. Reading the sections on
"Manually Overriding Your System" is necessary to fully understand the procedure
required to enable your vehicle in such situations. In addition, the chart on the last
page of this manual has a section for the particular features and options installed
in your vehicle as well as the override method selected. Although the default
mode is "Valet Switch" operation, the system can be configured for "Custom
Code" operation for enhanced security. Confirm the override mode selected on
the last page of this manual, and familiarize yourself with the section on it's opera-
tion.
FEATURES :
1 Two Way 6 Button LCD Remote Control & 1 One Way 5 Button Remote
Control
Seven Channel Code Learning Programmable Receiver
External Superheterodyne Transceiver Antenna
Single Or Two User Programmable W/Separate Control Outputs
Single Button Lock/Unlock or Separate Button Lock/Unlock or Both
Remote Keyless Entry With Optional Access Guard (must have power door
locks)
Selectable Manual Override Mode
New Enhanced Panic Feature (Any button other than unlock stops siren, no
change to the units state)
Smart Disarm (If triggered, elect to shut off siren, or disarm entire unit )
Adjustable Shock Sensor Via The Transmitter (Pre-Detect Off, Pre & Full Detect
Off, City Mode)
Safe Start Output Controlled From Channel 3 (Option Channel 3 For Trunk, Or
For R/S)
24 Hour Time Start Mode
Cold Temperature Start Mode
2 or 4 Hour Automatic Start Mode
Parking Meter Count Down Timer On LCD Remote
Additional Count Down Timer Mode
Remote Panic In All Modes (Press & Hold Lock /Unlock Button For 3 Seconds
To Engage)
Improved Custom Code Override, User Selectable and Programmable
Protected PBLED, (Push Button LED Valet/Program/Manual Override Switch )
7-Function LED-Arm / Disarm / Zone 1 / Zone 2 / Zone 3 / Valet / Arming
Intrusion Alert With Memory
Instant Siren Activation
Starter Disable Output
Model XR9000
Owner's Manual
Page 1
128-7863
1 of 20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Owner’s Manual and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Prestige Owner’s Manual

Summary of Contents for Prestige Owner’s Manual

  • Page 1 Model XR9000 Owner’s Manual Long Range Remote Start Security System With Plug-In Shock Sensor & Starter Disable IMPORTANT ! In order to provide you with the highest level of security to your vehicle, this system is equipped with selectable manual override circuitry. It is possible that you will need to override you security system if the transmitter becomes lost, or inoperative due to battery failure.

  • Page 2: Your "Code Hopping" Transmitters

    Additional Engine Immobilizer Output, (Optional Relay Required) True Last Door Arming (Hardwire Only) Defective Zone By-Pass Defective Zone Chirp Confirmation (Unit Chirps To Report Zone Cleared) 6 Tone Mini Siren Car Horn Output For Additional Alarm Response (Improved Timing To Minimize RF Interference.) Additional Negative Trigger Input (Hood and Trunk) RF Inhibit With Ignition On...

  • Page 3: Arming The System - Active

    simply press button 1, (lock), two times within a one second time period. The system will now respond to that transmitter each time a button is pressed. NOTE: This system is custom configurable and can be set up to operate with a number of options controlled from any transmitter button or button com- bination.

  • Page 4: Arming The System - Passive (Automatic)

    Doors Lock - Optional NOTE: If the optional Headlamp illumination feature has been added, and has been selected for operation when arming, as an added convenience, the sys- tem will turn on the headlights when the system is armed. The LCD Remote has the following response: ARMING THE SYSTEM - PASSIVE (AUTOMATIC) (Must be activated during programming) 1.
  • Page 5 transmitter button is activated, the drivers door only will unlock, pressing the unlock button a second time will cause all doors to unlock. NOTE: If your transmitter has been configured with single button Lock/Unlock, to activate the all door unlock feature operate the Lock/Unlock button a second time within 3 seconds of the first unlock command.

  • Page 6: While The System Is Sounding

    WARNING SIGNALS section of this manual to identify which zone was triggered. Doors Unlock - Optional 2 Step Doors Unlock - Optional NOTE: If the optional Headlamp illumination feature has been added and has been selected for operation when disarming, as an added convenience, the system will turn on the headlights when the system is disarmed.
  • Page 7 1. Open the vehicle door. The alarm will sound. 2. Turn the ignition key to the on position. 3. Within 5 seconds, press and release the PBLED override switch. The alarm system will stop sounding and enter the (bypassed) mode. You can now start and operate the vehicle normally.

  • Page 8: Eliminating The Normal Arm/Disarm Chirps

    (As per the example, press and release 2 times to set the units digit to 2). 8. Turn the ignition switch to the off position. Immediately observe the LED flash pattern. You will note the LED flashing five times, pause, and then flash two times, pause. This pattern will be repeated three times indicating the new code (52) has been accepted and stored in memory.
  • Page 9 again for 3 seconds. If the button is not pressed, the alarm will automatically stop after 30 seconds. Also if any transmitter button other than the Lock or Unlock button is pressed and released, the Panic mode will be turned off immediately.

  • Page 10: Remote Starting The Vehicle

    programmed, simply press the lock button of your keychain transmitter anytime during the remote start cycle. The shock sensor will be shunted for the entire run cycle and will resume normal operation after the remote start unit shuts off. Check with your installation center to determine if this feature has been pro- grammed into your system.

  • Page 11: Operating On Automatic Start Up Timer Mode

    2. Depress the brake pedal. 3. Open the hood. 4. Place the system in the Remote Start Override mode. 5. Race the engine to above 4000 RPM. OPERATING ON AUTOMATIC START UP TIMER MODE Your system has the ability to automatically start the vehicle every 2 or 4 hours over a 48 hour period.
  • Page 12 NOTE: The feature that has been added to channel 3 will always be activated using the same transmitter button that remotely starts the vehicle. There is no way to move the channel 3 function to a different transmitter button. ADDITIONAL REMOTE FUNCTION (CHANNEL 4) This system has an additional feature that can be connected to a number of different optional accessories.

  • Page 13: Telematic Upgrade

    1) Place the gear selector in park. 2) Set the parking, (hand), brake. 3) Be certain your foot is off the brake pedal. 4) Press the program/Push-Button switch 2 times within 5 seconds. The parking lights will flash two times indicating the mode was successfully en- tered.
  • Page 14 When the Panic Mode has been activated and the system is armed the vehicle's lights will flash, the siren and lock icon will be displayed on the LCD screen and the siren will beep. If the system is disarmed and the Panic Mode is activated, the lights will flash unlock icon will be displayed and the siren will beep on the LCD screen.
  • Page 15 the door is closed or the zone clears, the transmitter will chirp 1 time, and the display will clear. When the vehicle is armed, and the hood or trunk, is opened or ajar, the transmitter will chirp 3 times, the lights will flash, and the display will indicate a hood or trunk trigger as shown on the previous page.
  • Page 16 ADDITIONAL REMOTE FEATURES: The two way remote control unit allows you to access status information from the vehicle, check temperature, light the display, toggle the transmitter from beep tones to vibrate mode, initiate daily start timer, and temperature start. Selection of these and other features are shown below: NOTE: Transmitter must be within operating range of the vehicle, approximately 1000 ft.
  • Page 17 activated at the vehicle, you can toggle the feature on simultaneously pressing the Lock + Option buttons of the transmitter. The 24 hour icon will appear and the transmitter will emit a tone confirming the feature is active. Note: the unit will start once and run for the prescribed time. If you require more frequent starting please refer to auto start up timer mode shown earlier in this guide.
  • Page 18 Battery Indicator: Your transmitter has a battery indicator that is shown in the upper right corner of the screen as shown left. This icon indicates a new battery shown with 3 bars. As the battery deteriorates, the bars will disap- pear.
  • Page 19 Page 19 128-7863 19 of 20...
  • Page 20 * These chirps are optional, and can be de - activated. PARKING LAMP INDICATORS 1 FLASH 2 FLASHES DISARM 3 FLASHES DISARM / INTRUSION © 2006 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, NY 11788 128-7863 Page 20 128-7863 20 of 20...
