Dell OptiPlex 580 - Small Form Factor Service Manual page 8

The diagnostic lights are not lit
after the computer successfully
boots to the operating system.
A possible processor failure has
occurred.
Memory modules are detected, but
a memory failure has occurred.
A possible graphics card failure has
occurred.
A possible floppy drive or hard
drive failure has occurred.
A possible USB failure has occurred. Reinstall all USB devices and check all cable connections.
No memory modules are detected.
Memory modules are detected, but
a memory configuration or
compatibility error has occurred.
A possible expansion card failure
has occurred.
Another failure has occurred.
Back to Contents Page
Reseat the processor (see Processor information for your computer).
l
If the problem persists, contact Dell.
l
If two or more memory modules are installed, remove the modules, then reinstall one module
l
and restart the computer. If the computer starts normally, continue to install additional
memory modules (one at a time) until you have identified a faulty module or reinstalled all
modules without error.
If available, install working memory of the same type into your computer.
l
If the problem persists, contact Dell.
l
Reseat any installed graphics cards.
l
If available, install a working graphics card into your computer.
l
If the problem persists, contact Dell .
l
Reseat all power and data cables.
If two or more memory modules are installed, remove the modules, then reinstall one module
l
and restart the computer. If the computer starts normally, continue to install additional
memory modules (one at a time) until you have identified a faulty module or reinstalled all
modules without error.
If available, install working memory of the same type into your computer.
l
If the problem persists, contact Dell.
l
Ensure that no special requirements for memory module/connector placement exist.
l
Ensure that the memory you are using is supported by your computer (see the Specifications
l
section for your computer).
If the problem persists, contact Dell.
l
Determine if a conflict exists by removing an expansion card (not a graphics card) and
l
restarting the computer.
If the problem persists, reinstall the card you removed, then remove a different card and
l
restart the computer.
Repeat this process for each expansion card installed. If the computer starts normally,
l
troubleshoot the last card removed from the computer for resource conflicts.
If the problem persists, contact Dell.
l
Ensure that all hard drive and optical drive cables are properly connected to the system
l
board .
If there is an error message on the screen identifying a problem with a device (such as the
l
floppy drive or hard drive), check the device to make sure it is functioning properly.
If the operating system is attempting to boot from a device (such as the floppy drive or
l
optical drive), check system setup to ensure the boot sequence is correct for the devices
installed on your computer.
If the problem persists, contact Dell.
l
