Chapter 6 - Basic Configuration Guide
DECnet Protocol
Required for DECnet
WAN interfaces which are set for Frame Relay operation do not need
any additional parameters set in order to function.
DECnet must be turned on globally, and turned on for a particular port,
in order to be used.
WAN interfaces which are set for Frame Relay operation do not need
any additional parameters set in order to function.
•
Set DECnet on (globally, and for this port)
CV: Use the DECnet Routing Dialog Box (under Global/DECnet
Routing) and the DECnet: WAN Dialog Box.
TB: Use configure and set the Mode keyword in the DECnet WAN 0
(and/or WAN 1) section.
Note: Setting DECnet on for any port with the command line also
v
sets DECnet on globally. In CompatiView you must set a global
parameter and a port-specific parameter.
SMDS Configuration
This section covers the settings required for SMDS (Switched
Multi-megabit Data Service) operation of the MicroRouter 2200R WAN
0 interface (IP only). SMDS is a connectionless, packet-switched
service that offers LAN-to-LAN connectivity across a wide area at up to
1.544 Mbps.
Note: The IP protocol settings and the physical communication
v
settings are the same as they would be for Frame Relay operation. The
only parameters which should be set differently for SMDS are the Link
Configuration and the SMDS addressing section.
Link Configuration
SMDS is presently supported in the MicroRouter
1250i1270i2250R2270R only via dedicated line operation.
•
Set Dedicated connection
•
Set SMDS connection
CV: Use the Link Configuration: WAN Dialog Box.
TB: Use configure and then set the Mode and ConnectMode
