Example 10–2: Displaying Devices on an AlphaServer 4100 (cont.)
dkd100.1.0.4.1 DKd100
dkd200.1.0.4.1 DKd200
dkd300.1.0.4.1 DKd300
polling kzpsa0 (DEC KZPSA) slot 5, bus 0 PCI, hose 1
kzpsa0.7.0.5.1 dke TPwr 1 Fast 1 Bus ID 7 L01 A11
dke100.1.0.5.1 DKe100
dke200.2.0.5.1 DKe200
dke300.3.0.5.1 DKe300
polling floppy0 (FLOPPY) pceb IBUS hose 0
dva0.0.0.1000.0 DVA0
polling kzpsa1 (DEC KZPSA) slot 4, bus 0 PCI, hose 0
kzpsa1.7.0.4.1 dkf TPwr 1 Fast 1 Bus ID 7 E01 A11
dkf100.1.0.5.1 DKf100
dkf200.2.0.5.1 DKf200
dkf300.3.0.5.1 DKf300
polling tulip0 (DECchip 21040-AA) slot 3, bus 0 PCI, hose 0
ewa0.0.0.3.0 00-00-F8-21-0B-56
Example 10–3 shows the output from the show config console command
entered on an AlphaServer 8200 system.
Example 10–3: Displaying Configuration on an AlphaServer 8200
>>> show config
Name
TLSB
4++ KN7CC-AB
5+ MS7CC
8+ KFTIA
C0 Internal PCI connected to kftia0
0+ QLogic ISP1020 10201077
1+ QLogic ISP1020 10201077
2+ DECchip 21040-AA
4+ QLogic ISP1020 10201077
5+ QLogic ISP1020 10201077
6+ DECchip 21040-AA
C1 PCI connected to kftia0
0+ KZPAA
1+ QLogic ISP1020 10201077
2+ KZPSA
3+ KZPSA
4+ KZPSA
7+ DEC PCI MC
Example 10–4 shows the output from the show device console command
entered on an AlphaServer 8200 system.
Configuring Systems for External Termination or Radial Connections
RZ26N 0568
RZ26 392A
RZ26N 0568
TPwr 1 Fast 1 Bus ID 7
RZ28 442D
RZ26 392A
RZ26L 442D
RX23
TPwr 1 Fast 1 Bus ID 7
RZ26 392A
RZ28 442D
RZ26 392A
Twisted-Pair
Type Rev Mnemonic
8014 0000 kn7cc-ab0
5000 0000 ms7cc0
2020 0000 kftia0
pci0
0001 isp0
0001 isp1
21011 0023 tulip0
0001 isp2
0001 isp3
21011 0023 tulip1
11000 0001 kzpaa0
0005 isp4
81011 0000 kzpsa0
81011 0000 kzpsa1
81011 0000 kzpsa2
181011 000B mc0
to Non-UltraSCSI Devices 10–11
