What's Included in the box
CBR-980 Wireless N Broadband Router
Quick Installation Guide
Setup Software & User Manual on CD-ROM
Power Adapter
Step 1: Device Setup
Insert one end of the Ethernet cable to the
LAN port and the other end to your PC.
Connect power adapter to the Router's
Power jack, and plug the other end into an
electrical outlet.
. Connect Power
Electrical Outlet
AC 100-240
Step 2: Login
On your PC or laptop, open web browser
and type
http://192.168.1.1
bar. Press
Enter
.
When login screen appears, type
both Username & Password. Click
button to continue.
Step 3: Connect to the Internet
Through 3.5G USB Modem
Click on
One Button Setup
navigation pane.
Insert your 3.5G USB Modem into the USB
port. Select
3.5G usb dongle
interface drop-down menu. Fill in
information provided by your 3G service
provider. Click
Finish
process. The router will be restarted
shortly. Once the
login page
are ready to surf the Internet!
Note: APN & Phone Number are required.
User Name & Password can be optional.
The common APN name is
phone number is
*99#.
Power Adapter
into the Address
admin
for
Login
from the left
in WAN
button to finish setup
shows up, you
internet
and the
Wireless N Broadband Router
Boundless Internet Connections
Quick Installation Guide
. Connect Ethernet cable
Connect to the Internet through 3.5G USB Modem
CBR-980
