- Page 1 DFT-2010DVBT 20 TFT LCD TV+DVBT " Operating Instructions PAL/SECAM B/G,D/K, I, AC 110-240V 50/60Hz YPbPr IN, AV IN, HDMI, VGA, SCART TELETEXT DVBT FUNCTION SUPPORT FOR SUBTITLE...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Troubleshooting Tips Table of Contents Specifications The Causes of interference Installation Important Safety Instruction Warnings and Cautions Installation Functional Parts(TV) Rear view of TV set Remote Control unit 11-13 MENU Screens 14-15... -
Page 4: Specifications
SPECIFICATIONS Receiving System: B/G, D/K, I, Colour System: PAL, SECAM, 511.13mm(20 inch) diagonal LCD Panel: Ext.Antenna: 75 Ohm Ext. In/Out: PC Audio Input, SCART IN, HDMI, YPbPr, AV IN, VGA, earphone Speaker: 16 Ohm x 2 Audio Output: Power Consumption: AC 90-240V 50/60Hz,60W W522X D91.5XH426(mm) Dimension:... -
Page 5: Installation
INSTALLATION Thank you very much for your purchase of this product, the most natural Colour Television Receiver. To enjoy your set to the full from the very beginning, read this manual carefully and keep it handy for ready reference. INSTALLATION Locate the receiver in the room where direct light does not strike the screen. -
Page 6: Important Safety Instruction
IMPORTANT SAFETY INSTRUCTION WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER OR BACK. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lighting flash with arrow head within a triangle is intended to tell the user that parts inside the product are a risk of electric shock to persons. -
Page 7: Warnings And Cautions
WARNINGS AND CAUTIONS Caution Do not drop or push objects into the television cabinet slots or openings. Never spill any kind of liquid on the television receiver. Caution Do not insert anything in the ventilation holes. If metal or something flammable enters, it may result in fire or electric shock. Caution Do not place objects on this unit, it may damage the screen surface. - Page 8 WARNINGS AND CAUTIONS Caution Never stand on, lean on, or suddenly push the television or its stand. You should pay special attention to children. Serious injury may result if it should fall. Caution Do not place your television on an unstable cart , stand , shelf or table.
-
Page 9: Warnings And Cautions
WARNINGS AND CAUTIONS Warning Take care not to connect many appliances to the same mains socket as this could result in fire or electric shock. Warning High voltages are used in the operation of this television receiver. Do not remove the cabinet back from your set. Refer servicing to qualified service personnel. -
Page 10: Installation
¼ò ½é ¼ò ½é INSTALLATION Requires two AAA batteries(supplied). Procedure 1. Turn the remote control face down. Remove batterycover by pressing down on the marking on the cover and sliding it off in the direction indicated. 2. Install batteries matching(+) and(-) polarity signs. 3. -
Page 11: Functional Parts(Tv)
FUNCTIONAL PARTS(TV) Front View of LCD Set MENU SOURCE MUTE 1. LED indicator lamp/power 2. Remote Sensor 3. MUTE Button 4. SOURCE Button 5. MENU Button 6. P+ Button 7. P- Button 8. V+Button 9. V- Button 10. Standby Button To turn the TV power ON Put the TV set on the correct place, then connect the DC plug of the AC-DC adaptor to the DC 12V socket at the back of the TV set. -
Page 12: Rear View Of Tv Set
REAR VIEW OF TV SET DC IN 12V HEADPHONE PC IN FULL-SCART RF INPUT(ANT.) YPbPr HDMI AV IN V GA HDMI DC-12V PC-AUDIO SCART VIDEO NOTE Precautions when connecting to other equipment When using external equipment with this TV set, please read the instruction manual of the external equipment. Switch off all power supplies to the equipment and TV set before connection. -
Page 13: Remote Control Unit
REMOTE CONTROL UNIT POWER button Press this button to switch on the TV when at standby MUTE POWER mode or enter standby mode. MUTE button Press this button to mute or restore sound. P. P P. P P.P Button P. P P. - Page 14 REMOTE CONTROL UNIT SUBTITLE Button MUTE POWER DVBT button.Press this button to select a subtitle language. LIST Button DVBT button.press this button to display all P. P P. P programs. FAV Button DVBt button. Press this button to display the favorable SMODE programs.
-
Page 15: Teletext Operations
TELETEXT OPERATIONS For models with Teletext function only. TEXT Button Press this button to enter or exit the teletext mode. MUTE POWER HOLD Button Press this button to hold the Teletext page on display to prevent the page from changing. Press again to release the hold state. -
Page 16: Menu Screens
MENU SCREENS This TV allows you to adjust any setting from the menu screens using ¡°MENU¡±,¡°V+/-¡±and ¡°P+/-¡±buttons. Press ¡°MENU¡±button to display the menu, press¡°P+/-¡±to change menu from one to another, ¡°V+/-¡± to enter the chosen menu, press¡°P+/-¡±to select the item, and then press ¡°V+/-¡±to adjust each item. Press ¡°MENU¡±... -
Page 17: Menu Screens
MENU SCREENS 4.DTV Setup. Main Menu In DVBT mode,press MENU to enter the setup page. With VOL-/VOL+ and PROG-/PROG+ buttons,select CHANNEL MANAGEMENI the item what you want. press MENU to exit. AREA I GERMANY AUTO SEARCH MANUAL SEARCH 5.PC MENU(under PC mode only) Main Menu PC SETUP You can adjust the CONTRAST, BRIGHTNESS... -
Page 18: Troubleshooting Tips
TROUBLESHOOTING TIPS Before calling for service, you can check the following items on symptoms and solutions. No picture: Check other channel, maybe station problem. Adjust the tuning control. Ensure that the input setting is at TV state. Ensure that the LCD is on. Ensure that the equipment is connected properly. -
Page 19: The Causes Of Interference
THE CAUSES OF INTERFERENCE Incorporated in your TV receiver are the most up-to-date devices to eliminate interference.Local radiation however, can create disturbances which visibly affect your picture. Proper installation, a good aerial are your best safe-guards against these disturbances. RF INTERFERENCE Moving ripples across the screen are caused by nearby transmitting or receiving short-wave radio equipment. - Page 20 »ù±¾²Ù×÷ »ù±¾²Ù×÷...
