- Page 1 DFT-1504 BLACK 15 " TFT LCD TV Operating Instructions PAL/SECAM B/G,D/K, I, L/L AC 90-240V 50/60Hz SCART IN, PC IN TELETEXT NTSC PLAYBACK...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Table of Contents Troubleshooting Tips Specifications The Causes of interference Installation Important Safety Instruction Warnings and Cautions Setup Functional Parts Rear view of TV set Remote Control unit 11-12 TELETEXT Operations MENU Screens 14-15... -
Page 4: Specifications
SPECIFICATIONS Receiving System: B/G, D/K, I, L/L Colour System: PAL, SECAM 381mm(15 inch) diagonal LCD Panel: Ext.Antenna: 75 Ohm Coaxial Cable Ext. In/Out: PC Input, SCART IN Speaker: 8 Ohm x 2 Audio Output: Power Consumption: AC 90-240V 50/60Hz,60W W385 xD180 xH371(mm) Dimension: Net Weight: 3.5KG... -
Page 5: Installation
INSTALLATION Thank you very much for your purchase of this product, the most natural Colour Television Receiver. To enjoy your set to the full from the very beginning, read this manual carefully and keep it handy for ready reference. INSTALLATION Locate the receiver in the room where direct light does not strike the screen. -
Page 6: Important Safety Instruction
IMPORTANT SAFETY INSTRUCTION WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER OR BACK. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lighting flash with arrow head within a triangle is intended to tell the user that parts inside the product are a risk of electric shock to persons. -
Page 7: Warnings And Cautions
WARNINGS AND CAUTIONS Caution Do not drop or push objects into the television cabinet slots or openings. Never spill any kind of liquid on the television receiver. Caution Do not insert anything in the ventilation holes. If metal or something flammable enters, it may result in fire or electric shock. Caution Do not place objects on this unit, it may damage the screen surface. - Page 8 WARNINGS AND CAUTIONS Caution Never stand on, lean on, or suddenly push the television or its stand. You should pay special attention to children. Serious injury may result if it should fall. Caution Do not place your television on an unstable cart , stand , shelf or table.
- Page 9 WARNINGS AND CAUTIONS Warning Take care not to connect many appliances to the same mains socket as this could result in fire or electric shock. Warning High voltages are used in the operation of this television receiver. Do not remove the cabinet back from your set. Refer servicing to qualified service personnel.
-
Page 10: Setup
¼ò ½é ¼ò ½é ¼ò ½é ¼ò ½é SETUP Remote Control Battery Installation Requires two AAA batteries(supplied). Procedure 1. Turn the remote control face down. Remove battery cover by pressing down on the marking on the cover and sliding it off in the direction indicated. 2. -
Page 11: Functional Parts
FUNCTIONAL PARTS Front View of LCD Set MENU TV/AV 1. LED indicator lamp 2. Remote Sensor 3. Standby Button 4. TV/AV Button 5. MENU Button 6. P+ Button 7. P- Button 8. V+Button 9. V- Button To turn the TV power ON Put the TV set on the correct place, then connect the DC plug of the AC-DC adaptor to the DC 12V socket at the back of the TV set. -
Page 12: Rear View Of Tv Set
REAR VIEW OF TV SET DC IN 12V HEADPHONE PC IN SCART RF INPUT(ANT.) TO DC IN 12V TO POWER SOURCE NOTE Precautions when connecting to other equipment When using external equipment with this TV set, please read the instruction manual of the external equipment. Switch off all power supplies to the equipment and TV set before connection. -
Page 13: Remote Control Unit
REMOTE CONTROL UNIT POWER ON/STANDBY button Press this button to switch on the TV when at standby mode or enter POWER standby mode. MUTE button Press this button to mute or restore sound. P. P P. P P. P P. P P.P Button Press this button to select the desired picture mode: NORMAL/SOFT/RICH/CUSTOM. - Page 14 REMOTE CONTROL UNIT MENU Button Press this button to enter the menu screens for various optional POWER adjustable settings. PROG+/- Button Press the program up button to select the program forwards. Press P. P P. P the program Down button to select the program Backwards. VOL+/- Button Press volume up/down buttons to adjust sound level.
-
Page 15: Teletext Operations
TELETEXT OPERATIONS For models with Teletext function only. POWER TEXT Button Press this button to enter or exit the teletext mode. INDEX Button Press the button to go to the index page. P. P P. P REVEAL Button Press this button to reveal the hidden information for some Teletext pages(e.g. -
Page 16: Menu Screens
MENU SCREENS This TV allows you to adjust any setting from the menu screens using ¡°MENU¡±,¡°V+/-¡±and ¡°P+/-¡±buttons. Press ¡°MENU¡±button to display the menu, press¡°P+/-¡±to change menu from one to another, ¡°V+/-¡± to enter the chosen menu, press¡°P+/-¡±to select the item, and then press ¡°V+/-¡±to adjust each item. Press ¡°MENU¡±... - Page 17 MENU SCREENS SETUP MENU SETUP BULE SCREEN: You can set background ON or OFF. TXT LANGUAGE. BLUE SCREEN TXT LANGUAGE WEST ADJUST SELECT EXIT OSD MENU You can choose the language, adjust the H-position, LANGUAGE ENGLISH V-position, duration and halftone. HPOS VPOS DURATION...
-
Page 18: Troubleshooting Tips
TROUBLESHOOTING TIPS Before calling for service, you can check the following items on symptoms and solutions. No picture: Check other channel, maybe station problem. Adjust the tuning control. Ensure that the input setting is at TV state. Ensure that the LCD is on. Ensure that the equipment is connected properly. -
Page 19: The Causes Of Interference
THE CAUSES OF INTERFERENCE Incorporated in your TV receiver are the most up-to-date devices to eliminate interference.Local radiation however, can create disturbances which visibly affect your picture. Proper installation, a good aerial are your best safe-guards against these disturbances. RF INTERFERENCE Moving ripples across the screen are caused by nearby transmitting or receiving short-wave radio equipment. - Page 20 »ù±¾²Ù×÷ »ù±¾²Ù×÷...
