Viking RVER330 Installation

ELECTRIC SELF-CLEAN RANGE
RVER330-5B – 30" WIDE

Features and Functions

• Wide variety of surface element sizes and wattages,
including a fifth element
– Left front – 8 1/2" 2,000-watt dual element
– Left rear – 6 1/2" 1,200-watt single element
– Center – 12" 3,200-watt triple element
– Right front – 6 1/2" 1,200-watt single element
– Right rear – 8 1/2" 2,000-watt dual element
• QuickCook Surface Elements utilize ribbon technology to
TM
reach full power in about three seconds
• Exclusive – largest oven cavity in the industry
– 4.7 cu. ft. overall
– 4.1 cu. ft. measured to AHAM Standards
(See specifications chart for oven interior dimensions)
• High performance cooking modes include Bake, Convection
Bake, TruConvec Convection Cooking, Convection Roast,
TM
Hi Broil, Medium Broil, Low Broil, Convection Broil,
Convection Dehydrate, and Convection Defrost
• Exclusive – Patented Vari-Speed Dual Flow
System has the largest convection fan in the industry;
the 8 1/2" fan works bi-directionally for maximum
airflow and excellent cooking results
• Concealed 10-pass dual-bake element provides precise
temperature control
30" Wide Electric Range
(Shown with optional 6" H. backguard)
TM Convection
• 10-pass broiler with heat reflector provides superior broiling
performance
• Rapid Ready Preheat provides superfast preheating
TM
• Oven has six porcelain-coated rack supports and comes
standard with one TruGlide
standard racks
• Halogen oven lighting provides excellent visibility throughout
oven cavity
• Shipped standard with Island trim
Easy Operation and Cleanup
• Extremely large self-clean convection oven
• Strong, wear-resistant glass ceramic surface with stainless steel
frame offers excellent cleanability
• Durable metal die-cast knobs with child-proof,
push-to-turn safety feature
• Customer-removable knobs for easy cleaning
Installation Accessories
• 6" high backguard (RD30BG6)
• High shelf (RD30HS24)
• Countertop side trim (P24CST)
• Countertop rear trim (P30CRT)
• Curb base and custom curb base front (P30CBF4)
Finishes
• Available in Stainless Steel (SS), Black (BK), and White (WH)
Warranty Highlights
• Three-year full – complete product
• Ninety-day full – cosmetic parts such as glass, painted items,
and decorative items
• Lifetime limited – stainless steel exterior
• Ten-year limited – porcelain oven
• Five-year limited – surface/tube burners
full extension oven rack and two
TM
®
