  • Page 1 Install Guide 3 Series Freestanding Induction Self-clean Range RVIR330...
  • Page 2: Table Of Contents

    Viking Range | 3 Series Induction Range | RVIR330 Table of Contents Warnings & Important Safety Instructions _________________________________________ 2 Specifi cations ______________________________________________________________ 4 Dimensions _______________________________________________________________ 5 Clearance Dimensions (Proximity to Cabinets) _____________________________________ 6 Clearance Dimensions (Wood/Composite Overlay) ___________________________________7 Electrical Requirements ______________________________________________________ 8...
  • Page 3 Viking Range | 3 Series Induction Range | RVIR330 IMPORTANT – Please Read and Follow! • DO NOT remove permanently affi xed labels, warnings, or plates from product. This may void the warranty. • Please observe all local and national codes and ordinances.
  • Page 4: Specifi Cations

    Viking Range | 3 Series Induction Range | RVIR330 Specifi cations RVIR Induction Range Description 30” W. - 76 cm Wide Overall width 29-7/8” (76.0cm) Overall height To top of glass frame 35-7/8” (91.1 cm) min. to 37” (94.0 cm) max.
  • Page 5: Dimensions

    Viking Range | 3 Series Induction Range | RVIR330 Dimensions - 7 / ( 7 5 8 ” . 9 c 1 ” ( 2 . ( 9 1 - 7 / . 1 c 8 ” ( 9 4 ”...
  • Page 6: Clearance Dimensions (Proximity To Cabinets)

    Viking Range | 3 Series Induction Range | RVIR330 Cutout / Clearance Dimensions WARNING CAUTION To prevent possible damage to cabinets and BURN HAZARD cabinet fi nishes, use only materials and fi nishes that The use of cabinets for storage above the appliance will not discolor or delaminate and will withstand may result in potential burn hazard.
  • Page 7: Clearance Dimensions (Wood/Composite Overlay)

    Viking Range | 3 Series Induction Range | RVIR330 Clearance Dimensions - (Wood/Composite Overlay) The bottom of a standard hood should be 30” (76.2 cm) min. to 36” (91.4 cm) max. above the countertop. o d / This would typically result in the...
  • Page 8: Electrical Requirements

    • The required use of a GFI is normally related to the location of a receptacle with respect to any signifi cant sources of water or moisture. Viking Range, LLC will NOT warranty any problems resulting from GFI outlets which are not installed properly or do not meet the requirements below.
  • Page 9: General Information

    Viking Range | 3 Series Induction Range | RVIR330 General Information READ AND FOLLOW ALL WARNING AND CAUTION INFORMATION WHEN INSTALLING THIS APPLIANCE • All openings in the wall behind the appliance and in the fl oor under the appliance must be sealed.
  • Page 10: Installation

    Viking Range | 3 Series Induction Range | RVIR330 Installation Door Removal CAUTION To avoid risk of personal injury or product damages, DO NOT use the handle or oven door to lift the oven. Remove door before installation to ensure that it is not used to lift the unit.
  • Page 11: Leg Installation

    Viking Range | 3 Series Induction Range | RVIR330 Installation Leg Installation Legs are packed in styrofoam top pack. Note: It is strongly recommended Note: Legs should be installed near to where that a pallet or lift jack be used rather than appliance is to be used, as they are tilting.
  • Page 12: Electrical Connection (3-Wire)

    Viking Range | 3 Series Induction Range | RVIR330 Electrical Connection (3-wire) WARNING WARNING ELECTRICAL GROUNDING ELECTRICAL SHOCK HAZARD INSTRUCTIONS To avoid risk or electrical shock, personal To avoid risk of electrical shock, personal injury or death; grounding product to injury or death;...
  • Page 13 Viking Range | 3 Series Induction Range | RVIR330 Electrical Connection (3-wire) Bare Wire Connection Eyelet Connection To make a bare wire connection, use holes on the Attach line #1(black) and line #2(red) leads to left side of the terminal block. To connect eyelet outside terminal.
  • Page 14: Electrical Connection (4-Wire)

    Viking Range | 3 Series Induction Range | RVIR330 Electrical Connection (4-wire) WARNING WARNING ELECTRICAL GROUNDING ELECTRICAL SHOCK HAZARD INSTRUCTIONS To avoid risk or electrical shock, personal To avoid risk of electrical shock, personal injury or death; grounding product to injury or death;...
  • Page 15 Viking Range | 3 Series Induction Range | RVIR330 Electrical Connection (4-wire) Feed supply cord up through hole in Attach ground wire (green) bottom of range back with ground screw that was removed. Attach line #1 (black) and line #2 (red) Push supply cord toward terminal leads to outside terminal.
  • Page 16: Leveling/Adjustments/Alignment

    Viking Range | 3 Series Induction Range | RVIR330 Leveling/Adjustment/Alignment For uneven or sloped fl oors, level unit with metal shims only, as the adjustment required Measure the four corners in cutout may exceed the thread available in the leg.
  • Page 17: Anti-Tip Device Installation

    Viking Range | 3 Series Induction Range | RVIR330 Leveling/Adjustment/Alignment Set the high corner of range so that the top of side trim is 3/8” (0.95 cm) above countertop. Level range to high corner. Anti-tip Device Installation WARNING WARNING TIPPING HAZARD...
  • Page 18: Wall Mount Anti-Tip Installation

    Viking Range | 3 Series Induction Range | RVIR330 Wall Mount Anti-tip Installation 3 - 5 3 - 5 3 - 5 ( 9 . ( 9 . ( 9 . ” ” ” ( 1 . ( 1 .
  • Page 19: Floor Mount Anti-Tip Installation

    Viking Range | 3 Series Induction Range | RVIR330 Floor Mount Anti-tip Installation Dim A from Rear Wall 3-7/8” Without Standoff s (9.8 cm) 8 - 1 8 - 1 8 - 1 ( 2 1 ( 2 1 ( 2 0 Dim A from Rear Wall 4-5/8”...
  • Page 20: Final Installation

    Viking Range | 3 Series Induction Range | RVIR330 Final Installation Connect electrical in shaded area. See the Slide range into place. Whether using the wall or “Electrical Requirements” section for more fl oor anti-tip, be sure anti-tip information. bracket slides into the anti-tip opening.
  • Page 21: Door Replacement

    Viking Range | 3 Series Induction Range | RVIR330 Door Replacement Open door completely. Carefully realign door on hinges. Fold latches forward until locked in place. Slide in and down Close door...
  • Page 22: Final Preparation

    Viking Range | 3 Series Induction Range | RVIR330 Final Installation All stainless steel body parts should be wiped with hot, soapy water and with a liquid cleaner designed for this material. If buildup occurs, DO NOT use steel wool, abrasive cloths, cleansers, or powders! If it is necessary to scrape stainless steel to remove encrusted materials, soak with hot, wet cloths to loosen the material, then use a wool or nylon scraper.
  • Page 23: Service & Registration

    Only authorized replacement parts may be used in performing service on the appliance. All servicing should be referred to a qualifi ed technician. Contact Viking Range Corporation, 1-888-VIKING1 (845-4641), for the nearest service parts distributor in your area or write VIKING RANGE, LLC...
  • Page 24 Viking Range | 3 Series Induction Range | RVIR330 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) or visit our web site at vikingrange.com. 082971-000 (022924)
