Dell Latitude D630 XFR Quick Reference Manual

Dell Latitude D630 XFR Quick Reference Manual

With touch fully rugged notebook
Hide thumbs Also See for Latitude D630 XFR:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, User Manual
Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you make better use of your computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.
WARNING: A WARNING indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injury.
Information in this document is subject to change without notice.
© 2007 Dell Incorporated. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Incorporated is strictly forbidden.
This document is provided for informational purposes only, and may contain typographical errors and technical inaccuracies. The content is
provided as is, without express or implied warranties of any kind.
Trademarks used in this text: Dell, the DELL logo, Latitude, Wi-Fi Catcher, and ExpressCharge are registered trademarks of Dell Inc.;
Augmentix and the Augmentix logo are registered trademarks of Augmentix Corporation; Xtreme Terrain Grade (XTG), Rugged Redefined,
QuadCool, Armored Protection System (APS), and DirectVue are trademarks of Augmentix Corporation; Microsoft, Windows and Windows Vista
are registered trademarks of Microsoft Corporation; Touchkit is a trademark of eGalax_eMPIA Technology Inc. (EETI).
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their
products. Dell Incorporated disclaims any proprietary interest in trademarks and trade names other than its own.
1
2
2.1
2.1.1
2.1.2
Hinged Door
2.1.3
2.2
3
3.1
3.2
TM
Dell
XFR630 with Touch
Fully Rugged Notebook

Table of Contents

Quick Reference Guide

Advertisement

Table of Contents
loading

Related Manuals for Dell Latitude D630 XFR

Summary of Contents for Dell Latitude D630 XFR

  • Page 1: Table Of Contents

    Trademarks used in this text: Dell, the DELL logo, Latitude, Wi-Fi Catcher, and ExpressCharge are registered trademarks of Dell Inc.; Augmentix and the Augmentix logo are registered trademarks of Augmentix Corporation; Xtreme Terrain Grade (XTG), Rugged Redefined, QuadCool, Armored Protection System (APS), and DirectVue are trademarks of Augmentix Corporation;...
  • Page 2 When to Use the Dell Diagnostics 6.2.2 Starting the Dell Diagnostics From Your Hard Drive 6.2.3 Starting the Dell Diagnostics From the Drivers and Utilities CD 6.2.4 Dell Diagnostics Main Menu Table of Figures FIGURE 2 1 REMOVING A COMPARTMENT DOOR...

  • Page 3: Finding Information

    Documentation and drivers are already installed on your computer. You can use the media to reinstall drivers and to run Dell Dell Drivers and Utilities CD Optionally available in the · Diagnostics (see "Dell Diagnostics").

  • Page 4: Setting Up Your Computer

    Software upgrades and troubleshooting hints, relevant self-support information. Dell Support Utility frequently asked questions, hot topics, and Access the Dell Support Utility from general health of your computer icon in the taskbar. For more information, see "Dell Support Utility" in your XFR630 with Touch Fully Rugged Notebook User’s...
  • Page 5 The figure above shows the sequence to remove a compartment door. Two quarter-turn latches are used to secure each compartment door to the computer. The removal of both the battery and disk compartment doors is shown. To remove a compartment door follow these steps: 1.

  • Page 6: Friction Fit Door

    Arrow shows latch release Hinged door Latch locking mechanism direction The hinged door is utilized on doors on the back and side panels of the computer. The hinged door is secured by a sliding latch The devices and/or connectors protected by these doors can be accessed by pushing the latch in the direction indicated by the arrow and then rotating the door away from the computer along its hinge.

  • Page 7: About Your Computer

    AC adapter AC adapter connector 4. Open the computer display by pressing on the display latch and lifting the display. Then press the power button to turn on the computer. See "Front View" for the power button’s location. NOTE: It is recommended that you turn on and shut down your computer at least once before you install any cards or connect the computer to a docking device or other external device, such as a printer.

  • Page 8: Left Side View

    Display latch Power button DirectVue Touch Display Biometric (fingerprint) Device status lights Keyboard reader - optional Stylus and stylus tether Stylus housing (with Touch Speaker (with Touch Display option) Display option) Touch pad/Track stick Handle Touch pad buttons Track stick Keyboard status lights Volume control buttons Ambient light sensor (ALS)

  • Page 9: Right Side View

    Figure 3 3 XFR630 Left Panel with Connectors/Devices Revealed Air vents (protected from Security cable slot Audio connectors (2) ingress) Smart card slot (with 1394 connector Wireless switch blank) PC card/ExpressCard slot The following is applicable to UL 1604 and CSA C22.2 No. 213 compliant systems: WARNING - Explosion Hazard - Do not disconnect equipment unless power has been removed or the area is known to be non-hazardous WARNING - Explosion Hazard - Do not utilize any of the connectors/hubs unless area is known to be...

  • Page 10: Back View

    The connectors and devices on the computer are protected from ingress by dense magnesium hinged and friction fit doors. This protection is a component of the Armored Protection System (APS). Figure 3 5 XFR630 Right Side with Connectors/Devices Revealed XBay expansion bay XBay device latch release USB connectors (2) The following is applicable to UL 1604 and CSA C22.2 No.

  • Page 11: Bottom View

    The connectors and devices on the computer are protected from ingress by dense magnesium hinged and friction fit doors. This protection is a component of the Armored Protection System (APS). Figure 3 7 XFR630 Back View with Connectors Revealed Network connector Modem connector USB connectors (2) (RJ-45)

  • Page 12: Accessing The Battery Compartment

    Docking device connector Hard disk drive Memory module cover door compartment cover Battery compartment cover The compartments on the bottom of the computer are protected from ingress by dense magnesium compartment doors. This protection is a component of the Armored Protection System. The following is applicable to UL 1604 and CSA C22.2 No.

  • Page 13: Removing The Battery

    CAUTION: Using an incompatible battery may increase the risk of fire or explosion. Replace the battery only with a compatible battery purchased from Dell. The battery is designed to work with your computer. Do not use a battery from other computers with your computer.
  • Page 14 Docking device connector Door Latch cover The following steps provide instructions on how to open the docking device connector door: 1. While sliding the door latch (2) to the open position, lift and push back the door. Figure 3 11 Opening the XFR630 Docking Device Connector Door – Step 2 2.

  • Page 15: Accessing The Hard Disk Drive Compartment

    1. The locking mechanism that secures the XFR630 Notebook’s docking device connector is disengaged by sliding the mechanism to the left. 2. As the locking mechanism is moved to the left, the door must be lifted and the door pulled forward until it securely latches back into its closed position.

  • Page 16: Directvue Tm Touch Display Information

    To remove the hard disk drive: 1. If the computer is connected to a docking device (docked), undock it. See the documentation that came with your docking device for instructions. 2. Ensure that the computer is turned off. 3. See “Bottom View” for the location of the hard disk drive compartment. If the 2 optional screws that secure the quarter-turn latches are installed, remove the 2 screws on the latches on the hard disk drive compartment using a #1 Philips screw driver.

  • Page 17: Using A Battery

    The Touchkit software utility consists of tabs that allow you to determine the best settings for your touch screen configuration. The Tools tab provides access to calibration and touch position tools. NOTE: Your touch screen is configured and calibrated at the factory. However, if you notice that the calibration is not as precise as you would like, you can use the 4 Points Calibration tool to align the touch screen.

  • Page 18: Checking The Battery Charge

    5.2.1 Dell™ QuickSet Battery Meter If Dell QuickSet is installed, press <Fn><F3> to display the QuickSet Battery Meter. The Battery Meter displays status, battery health, charge level, and charge completion time for the battery in your computer. For more information about QuickSet, right-click the Quickset icon in the taskbar, and click Help.

  • Page 19: Check The Battery Charge

    NOTE: You can check battery health in one of two ways: by using the charge gauge on the battery as described below or by using the Battery Meter in Dell QuickSet. For information about QuickSet, right-click the icon in the taskbar, and click Help.

  • Page 20: Storing A Battery

    When you connect the computer to an electrical outlet or install a battery while the computer is connected to an electrical outlet, the computer checks the battery charge and temperature. If necessary, the AC adapter then charges the battery and maintains the battery charge. For more information about resolving problems with a battery, see "Power Problems"...

  • Page 21: Dell Diagnostics

    Use an anti-virus program that includes anti-spyware protection (your program may require an upgrade) to scan the computer and remove spyware. RUN THE DELL DIAGNOSTICS — See "Dell Diagnostics". If all tests run successfully, the error condition is related to a software problem.

  • Page 22: Starting The Dell Diagnostics From The Drivers And Utilities Cd

    Dell Diagnostics Main Menu 1. After the Dell Diagnostics loads and the Main Menu screen appears, click the button for the option you want. NOTE: It is recommended that you select Test System to run a complete test on your computer.
  • Page 23 Allows you to customize the test by changing the test settings. 5. When the tests are completed, close the test screen to return to the Main Menu screen. To exit the Dell Diagnostics and restart the computer, close the Main Menu screen.
