Dacor DYWS4 Quick Start

Dacor DYWS4 Quick Start

Wine dispensing system
Hide thumbs Also See for DYWS4:
1
2
3
4
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction and Installation Manual, Manual

WARNING

Instructions:
STEP 1
Move the wine dispensing system to a location
with a dedicated 120 Volt, 3-prong grounded
electrical outlet close by and adequate ventila-
tion.
STEP 2
Plug one end of the plastic gas tubing into the
inert gas connector on the back of the system
(see below).
STEP 3
Make sure the cable coming from the power
supply (black box) on the back of the system is
connected to the Power Input connector on the
back of the unit.
Plastic gas
tubing connects
here
DYWS4 Wine Dispensing System
●
Read all instructions in the use and care manual before
operation.
●
EXCESSIVE WEIGHT WARNING: Two people are required
to safely move this appliance.
●
Use only the gas regulator and argon gas cylinders in-
cluded with the system.
Power supply output
connects here
Power
supply

Gas and Electrical Connections

1" (2.5 cm)
120 Vac power
cord connects to
power supply
Connect to 120 Vac, 60
Hz. electrical outlet
QUICK START
min.
Provide Proper Air Flow
GUIDE
Part No. 107499 Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DYWS4 and is the answer not in the manual?

Questions and answers

Related Manuals for Dacor DYWS4

Summary of Contents for Dacor DYWS4

  • Page 1 QUICK START DYWS4 Wine Dispensing System GUIDE WARNING ● Read all instructions in the use and care manual before operation. ● EXCESSIVE WEIGHT WARNING: Two people are required to safely move this appliance. ● Use only the gas regulator and argon gas cylinders in- cluded with the system.
  • Page 2 Do not separately. Order on-line at www. everythingdacor.com or by calling use a wrench or overtighten. Argon Dacor Customer Service at (800) 793-0093 ex. 2822. Your first gas STEP 10 Turn the regulator knob in the ON cylinder argon gas cylinder is provided free direction until it stops.

  • Page 3: Quick Start Guide

    Quick Start Guide STEP 13 Open a wine bottle and place it on a flat, dry surface. Green STEP 14 Insert the included head selection tool into Head Selection Tool the bottleneck to determine the correct (color White coded) gasket size. STEP 15 If you do not have a dispensing head with the Dispensing correct color gasket installed: head...
  • Page 4 (on bottom of spout cover) STEP 26 Push the purge button (P) next to the display above the bottle that has just been DACOR inserted. The food grade argon will replace 2008 the air in the bottle, assuring preservation. Red Wine The wine is now ready for serving.
