DESKPOWER 6000/SS Series User's Manual
Fujitsu endeavours to ensure that the information in this document is correct, but accepts no liability
for any error or omission in the same. Any procedures described in this document for operating Fujitsu
products should be read and understood by the operator before such products are used. To ensure
that Fujitsu products function without risk to safety and health, such procedures should be strictly
observed by the operator. The development of Fujitsu products and services is continuous and
published information may not be up to date. Any particular issue of a product may contain facilities
not described herein. It is important to check the current position with Fujitsu. Specifications and
statements as to performance in this document are Fujitsu estimates intended for general guidance.
They may require adjustment in particular circumstances and should therefore not be taken as formal
offers or commitments.
DESKPOWER is a trademark of Fujitsu Limited. The following are registered trademarks of Microsoft
Corporation: MS, MS-DOS, Windows
®
NT, Windows
®
for Workgroups, Windows
®
98, Window
®
2000.
®,
Pentium
Celeron and MMX™ technology are trademarks of Intel Corporation. Phoenix and Phoenix
logo are registered trademarks of Phoenix Technologies ,Ltd .
All other products are trademarks or registered trademarks of their respective companies.
© Copyright 2001 Fujitsu Limited. All rights reserved. No part of this publication may be copied,
reproduced, or translated without the prior written consent of Fujitsu Limited. No part of this publication
may be stored or transmitted in any electronic form without the written consent of Fujitsu Limited.
DECLARATION OF CONFORMITY
according to FCC Part 15 Class B
This device complies with Part 15 Class B of the FCC Rules. Operations are subject to the following
two conditions:
(1) This device may not be allowed to cause harmful interference, (2) This device must accept any
interference received, including interference that may cause undesired operation.
Wesbite: www.fujitsu-pc-asia.com
i

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu DESKPOWER 6000/SS Series

Summary of Contents for Fujitsu DESKPOWER 6000/SS Series

  • Page 1 Fujitsu endeavours to ensure that the information in this document is correct, but accepts no liability for any error or omission in the same. Any procedures described in this document for operating Fujitsu products should be read and understood by the operator before such products are used. To ensure that Fujitsu products function without risk to safety and health, such procedures should be strictly observed by the operator.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions carefully. Save these instructions for future reference. 2. Follow all warnings and instructions marked on the product. 3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.
  • Page 3 13. Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: a. When the power cord or plug is damaged or frayed. b. If liquid has been spilled into the product. c. If the product has been exposed to rain or water. d.
  • Page 4 Follow the PC system handling instructions of operator’s guide. Fujitsu, as a member of the International Energy Star Program, recognizes that this equipment is compliant with the standard of the International Energy Star Program.

  • Page 5: Conventions Used In This Manual

    Conventions used in this manual Warning messages This manual uses various pictorials. This manual uses various safety signs and symbols so that you can use the PC system safely and prevent personal injury and/or property damage. The following gives the signs and their explanations. Be familiar with these signs before proceeding to the subsequent sections of this manual.
  • Page 6 Command entry (from keyboard) A command entry is represented in this manual as follows: diskcopy • If two letters are separated by a space as indicated by the top arrow, press the [Space] bar once. Commands, an example of which is given above in lowercase, can also be entered in uppercase. •...
  • Page 7 Otherwise, electric shock may occur. DESKPOWER MODEL FPC-S90000 CP070181-01 ® 200-240V(1.75A)/100-120(3.5A) 50/60Hz MADE IN SINGAPORE By Fujitsu Limited Japan(J) FUJITSU LIMITED To prevent electric shock, WARNING switch off the PC and connected peripherals and Electric shock unplug power cords from...
  • Page 8 Manual configuration Chapter Introduction This chapter provides basic information on the PC, such as the names and functions of individual parts, and also explains the basic operation of the PC, such as turning the power on or off. Chapter Hardware This chapter provides basic information on how to handle the peripherals installed (or can be installed) on the PC.

  • Page 9: Table Of Contents

    Contents CHAPTER 1 Introduction 1 Part Names and Functions ... 2 Front of the PC unit ... 2 Back of the PC unit ... 4 Inside the PC unit ... 6 Motherboard ... 7 2 Keyboard ... 8 3 Mouse ... 10 Using the mouse ...
  • Page 10 3 Increasing the Memory Capacity ... 39 Location of memory modules ... 40 Applicable memory modules ... 40 Installing memory modules ... 41 4 Installing Expansion Cards ... 44 Location of expansion cards ... 45 Applicable expansion cards ... 45 Installing an expansion card ...

  • Page 11: Chapter 1 Introduction

    CHAPTER 1 Introduction...

  • Page 12: Part Names And Functions

    1 Part Names and Functions This section explains the names and functions of the parts of the PC unit and the motherboard. Front of the PC unit...
  • Page 13 Power switch Press this switch to turn on the PC or set the system to the standby mode. Power lamp This lamp lights up when the PC is on. It lights up in green when the PC is in operation and in amber when the PC is in the standby (power- saving) mode.

  • Page 14: Back Of The Pc Unit

    Back of the PC unit...
  • Page 15 Venthole An opening provided to let heat go out of the PC. Inlet Connect the power cable of the PC unit to this connector. Outlet Connect the power cable of the display to this outlet. Burglarproof lock Install a lock to protect the device inside the PC against theft. Expansion slot Insert an optional expansion card to this slot.

  • Page 16: Inside The Pc Unit

    Inside the PC unit Expansion slot Insert an optional expansion card to this slot. This slot accommodates a PCI card. A SCSI card allows you to use an external hard disk drive or magneto-optical disk drive. Power supply unit Internal hard disk This is an IDE-compliant hard disk.

  • Page 17: Motherboard

    Motherboard DIMM slots Memory modules are inserted into these slots. When seen from the front of the PC unit, DIMM1 and DIMM2 are arranged in this order from the right. Secondary IDE connector (IDE2) A standard CD-ROM is connected. Primary IDE connector (IDE1) A standard hard disk is connected.

  • Page 18: Keyboard

    2 Keyboard This section explains the functions of the keys on the keyboard. The keyboard shown in this diagram is an example. Depends on the model, the keyboard layout may differ but the function of the keys is similar. Point The functions assigned to the keys vary depending on an OS or program running on your PC.
  • Page 19 Caps Lock/Alphanumeric key Use the Caps Lock/Alphanumeric key to type alphabetical characters. Press [Caps Lock] to switch between uppercase and lowercase. Ctrl (control) key Use the Ctrl key in combination with another key. Its function varies with each application. 10 Windows key Press the Windows key to display the “Start”...

  • Page 20: Mouse

    3 Mouse Left button Scroll button Right button Point • Clean the mouse regularly. Using the mouse Moving the mouse Lightly hold the mouse and place your index and middle fingers on the left and right buttons on the mouse. Slide and move the mouse over a plane surface, such as a desktop. As you move the mouse, an arrow (called the mouse pointer) moves in the same way on the screen.
  • Page 21 Double-clicking Click-Click Double-clicking is a series of action of pressing and releasing the left mouse button twice. Pointing Pointing is an action of moving the mouse pointer to an object or item such as a menu. If the pointed menu item has subordinate items ( is displayed at the right end), the items are displayed. Dragging Release Press...

  • Page 22: Installation

    4 Installation This section explains how to install your PC and also provides note on using the PC. Installation area Do not install the PC in the following areas: - Areas that are humid, dusty, or subjected to oil mist. - Poorly ventilated areas - Areas where fire is used - Bathrooms and other areas where water may splash...
  • Page 23 Mount the feet on the PC unit. Fix the feet by tightening screws into two holes marked “DOUBLE” on the bottom of the feet. • Single foot Take the following steps to place your PC vertically on a wall. Disassemble the feet. Mount one of the feet on the PC unit.
  • Page 24 Horizontal placement Disassemble the feet. Place the PC unit on the disassembled feet. Point The PC unit can be installed horizontally by using five rubber feet at the center and four corners of the PC body. When using the rubber feet, avoid interference with the foot for vertical placement. Clean the areas for the rubber feet before attaching them.

  • Page 25: Example Of Installation

    Example of installation Install your PC as shown in the figures below. The PC unit can be installed either vertically or horizontally. Pay attention not to block the ventholes. Vertical placement Display Keyboard Mouse Horizontal placement You can place a display (17 inches or smaller, weighing 19 kg or less) on the PC unit. Display Keyboard Point...

  • Page 26: Connection

    PC and all devices connected to it, and unplug them. Otherwise, an electric shock may occur. Use a Fujitsu-supplied display, keyboard, and mouse. Otherwise, an electric shock, a fire or fault may occur. CAUTION Connect the cables correctly.

  • Page 27: Connecting The Display, Keyboard, Mouse, And Lan Cables

    Connecting the display, keyboard, mouse, and LAN cables Point As a LAN cable, use a commercially available twisted pair cable. In connecting a LAN cable, a core must be mounted. Connect the power cable to the outlet. Connect the plug on one end of the power cable (for CRT), which is supplied with the PC unit, to the outlet of the PC unit.
  • Page 28 Connect the mouse. With the mark on the connector of the mouse cable facing right, plug the connector into the mouse terminal on the back of the PC unit, labeled with a mouse symbol of the same color as the mouse connector.
  • Page 29 • Connecting to the CRT connector • Connecting to the DVI connector...

  • Page 30: Connecting The Power Cable

    Connecting the power cable After connecting the display and other peripheral devices, connect the power cable of the PC unit. Note the following: Do not connect or disconnect the plug with wet hands. Do not damage or modify the power cable. Do not compress, pull, bend, twist, or heat the power cable.
  • Page 31 Connect the power cable plug to the inlet on the back of the PC unit. Connect the power cable plug to an outlet. Connect the plug on the other end of the power cable to an outlet. When connecting the power cable to a two-pin outlet, attach the adapter plug supplied with the power cable to the cable plug and then connect to the outlet.

  • Page 32: Turning On The Power

    When the PC is turned on, the system performs POST (Power-On Self-Test) to check the internal hardware components. Meanwhile, the Fujitsu logo appears on the screen. Do not turn off the system during POST. When the upper cover has been removed for installing a built-in option, make sure that the...

  • Page 33: Turning On The Power

    Press the power switch on the PC. The power lamps on the display and PC light up in green. When the PC is turned on, the Fujitsu logo appears, then the system starts up. Power switch After power-on, set up Windows.

  • Page 34: Turning Off The Power

    7 Turning Off the Power This section explains how to turn off the power. Notes on power-off Before turning off the power, terminate all work and save data. Before turning off the power, confirm that the floppy disk and the hard disk access lamps are off.
  • Page 35 For Windows NT Click the [Start] button, then click [Shut down]. The [Shut down Windows] dialog box appears. Click [Shut down the computer], then click [Yes]. The power is automatically turned off. Point The power can also be turned off in the following procedure. Press the [Ctrl] + [Alt] + [Delete] keys.
  • Page 36 For Windows Me Click the [Start] button, then click [Shut down Windows]. The [Shut down Windows] dialog box appears. Select [Shutdown] and click [OK]. The power is automatically turned off. The PC is reset. Point The power can also be turned off in the following procedure. Press the [Ctrl] + [Alt] + [Delete] keys.

  • Page 37: Resetting

    8 Resetting After software installation or when software hangs, the PC must be reset (restarted). This section explains how to reset (restart) the PC. Point Resetting (restarting) the PC clears data in the memory. Save data before resetting (restarting) the PC. Resetting the PC For Windows 98 Click the [Start] button, then click [Shut down Windows].
  • Page 38 For Windows 2000 Click the [Start] button, then click [Shut down]. The [Shut down Windows] dialog box appears. Click the [Restart] button, then click [OK]. Point The PC can also be reset (restarted) in the following procedure. Press the [Ctrl] + [Alt] + [Delete] keys. The [Windows security] dialog box appears.

  • Page 39: Cd-Rom

    9 CD-ROM The PC has a DVD-ROM and CD-R/RW (Combo) drive as a standard. This section explains how to handle, insert, and remove CDs. Notes on handling To prevent faults, note the following when handling CDs. Notes on handling CDs Do not use a ball-point pen or pencil on the label (printed side).

  • Page 40: Inserting Or Removing A Cd

    Inserting or removing a CD Inserting a CD Press the Eject button. Pressing the center of the Eject button slightly opens the CD tray. Pull the tray with hands. Pull the tray by holding the center as shown in the figure. Busy lamp Eject button Tray...
  • Page 41 Making the label side facing left, engage the CD with the projection in the center of the tray until a snap can be heard. Hold the tray so as to prevent if from falling. Label side Point Be sure to engage the CD with the projection in the center of the tray until a snap can be heard. Otherwise, a fault may occur.

  • Page 42: Floppy Disk

    10 Floppy Disk Floppy disks are used to store data and programs. This section explains how to handle, insert, and remove floppy disks. Notes on handling To prevent faults, note the following when handling floppy disks. Keep them dry. Do not open the shutter to touch the disk inside. Do not bend or compress them.
  • Page 43 Removing the floppy disk Confirm that the floppy disk access lamp is off. Point Do not press the floppy disk eject button while the floppy disk access lamp is on. Data stored on the disk may be damaged. Press the floppy disk eject button. Floppy disk access lamp...

  • Page 44: Hard Disk

    11 Hard Disk A hard disk is pre-installed in the PC. This section explains precautions on handling the hard disk. Notes on handling the hard disk To prevent faults, note the following when handling the hard disk. Data is read from the hard disk or written to it while the internal disk that stores data is rotating at high speeds.

  • Page 45: Chapter 2 Hardware

    CHAPTER 2 Hardware...

  • Page 46: Before Installing A Peripheral Device

    This PC can accommodate various peripheral devices to expand its functions. Some peripheral devices may not be used on your PC. WARNING Use only peripheral devices recommended by Fujitsu. Otherwise, an electric shock, a fire or fault may occur. CAUTION When installing or removing a peripheral device, do not remove screws other than those specified in the manual.

  • Page 47: Notes On Handling

    When installing a peripheral device, note the following. Whenever possible, use peripheral devices supplied by Fujitsu. Malfunction or damage caused by the use of a third-party product instead of the Fujitsu device shall not be covered by the warranty. Before using a peripheral device in a category for which Fujitsu does not supply genuine products, contact the third-party manufacturer to ask whether the device is compatible with the PC.

  • Page 48: Removing The Cover

    2 Removing the Cover When mounting a peripheral device, remove the upper cover so that the inside can be seen. Removing the upper cover When mounting an internal option, remove the upper cover so that the inside can be seen. Remove the feet, if any, from the PC unit.

  • Page 49: Increasing The Memory Capacity

    Before installing or removing a memory module, turn off the PC and all devices connected to it, and unplug them. Otherwise, an electric shock may occur. Use Fujitsu-supplied memory modules. Otherwise, an electric shock, a fire or fault may occur. CAUTION When installing or removing a memory module, do not remove screws other than those specified.

  • Page 50: Location Of Memory Modules

    Location of memory modules Memory modules are inserted into memory slots inside the PC unit. Applicable memory modules Use Fujitsu-supplied, 168-pin SDRAM DIMM memory modules. Memory module combinations Up to 512 megabytes of expansion RAMs can be installed on the PC.

  • Page 51: Installing Memory Modules

    Installing memory modules Remove the upper cover. Remove the expansion card mounting bracket. Remove the four screws and lift the bracket vertically. When an expansion card has been installed, remove the cable from the card and remove the bracket. Remove the reinforcement bracket. Remove one screw to remove the bracket.
  • Page 52 Insert a memory module into the slot. Insert the memory module upright into the slot while aligning the notch on the memory module with that on the slot. When the memory module is inserted correctly, the hooks on both side rise. Make sure that the memory module is hooked securely.
  • Page 53 Reinstall the upper cover. Point Pull the hooks on both sides of the slot outward. Do not pull the hooks too violently. Otherwise, the memory module may jump out of the slot and become faulty.

  • Page 54: Installing Expansion Cards

    Before installing or removing an expansion card, turn off the PC and all devices connected to it, and unplug them. Otherwise, an electric shock may occur. Use Fujitsu-supplied expansion cards. Otherwise, an electric shock, a fire or fault may occur. CAUTION When installing or removing an expansion card, do not remove screws other than those specified.

  • Page 55: Location Of Expansion Cards

    Location of expansion cards PCI1 PCI2 Applicable expansion cards The PC accommodates an expansion card for the PCI bus. For expansion cards to operate, “resources” must be assured. The floppy disk drive or hard disk drive built in the PC uses a path predetermined for each device to exchange data with the CPU or memory.

  • Page 56: Installing An Expansion Card

    Installing an expansion card Disconnect the power plug from the outlet. Remove the upper cover. Remove the expansion card mounting bracket. Remove the four screws and lift the bracket vertically. When an expansion card has been installed, remove the cable from the card and remove the bracket.
  • Page 57 Install the expansion card mounting bracket. Secure the bracket with the four screws removed in Step 3. Reinstall the upper cover. Point For removal, follow the opposite procedure from that for installation. Turn on the PC. For Windows 95/98/2000/Me model The system configures the device driver and resource to enable the expansion card.

  • Page 58: Chapter 3 Troubleshooting

    CHAPTER 3 Troubleshooting...

  • Page 59: Problems

    1 Problems This section identifies problems relating to each function.Read wherever applicable. The access lamp stays off. The PC may be faulty. Consult with the Fujitsu Service Center or the store where you purchased this computer. Nothing appears on the display.
  • Page 60 The PC cannot be turned on or the power lamp does not light up. Make sure that the power cable is correctly connected to the outlet. Data cannot be read from the CD-ROM drive. Check the following: Is the CD placed correctly? If not, reset it with its label side facing left. Is the CD placed in the opposite direction? If so, reset it with its label side facing left.
  • Page 61 Network connection cannot be established. Check the following: Is the network cable connected correctly? For 100Mbps communication, is a category 5 UTP cable used? Does the ACT/LNK lamp of the hub unit light up? When the TCP/IP protocol is used, make sure that connection is established using the Ping command.

  • Page 62: Chapter 4 Technical Information

    CHAPTER 4 Technical Information...

  • Page 63: Maintenance Of The Hardware

    1 Maintenance of the Hardware Maintenance of the PC unit This PC can accommodate various peripheral devices to expand its functions. Some peripheral devices may not be used on your PC. WARNING Before starting maintenance, turn the PC unit and the connected devices off and disconnect the power plugs.

  • Page 64: Maintenance Of The Mouse

    Maintenance of the mouse Clean the surface using a soft, dry cloth. If the mouse ball does not roll smoothly, remove and clean the ball as follows: Remove the mouse bottom cover. Turn the cover on the bottom of the mouse in the direction of the arrow to remove. Remove the ball and clean with water.

  • Page 65: Cleaning Of The Floppy Disk Drive

    Cleaning of the floppy disk drive The floppy disk drive head (the component to read and write data) becomes dirty after used for extended periods. A dirty head prevents proper reading from or writing to a floppy disk. Using a cleaning floppy disk to clean the floppy drive when your drive dirty.

  • Page 66: Security Of The Case

    2 Security of the Case To protect the equipment inside the PC (ex. hard disk and CPU) from burglaries, the cover of the PC can be locked. Remove the upper cover. Install the security key mounting bracket, which is supplied with the PC, to the back of the upper cover.

  • Page 67: Other Precautions

    PC, including the peripheral devices, off. If interference occurs on a television or radio, review the items listed above. If interference still occurs, contact your nearest Fujitsu Service Center or the shop where you purchased the PC.

  • Page 68: Usb Keyboard (Windows 98 Model)

    USB keyboard (Windows 98 model) After selecting [Control Panel]-[Accessibility Options]-[FilterKeys]-[Settings] and enabling [Use Shortcut], the shortcut key function is disabled and [Use FilterKeys] is not set even after the [Right Shift] key has been pressed for 8 or more seconds. In this case, use the mouse to set the [Use FilterKeys] checkbox.

  • Page 69: Replacement Of Display

    Replacement of display If the display is replaced with a different type (especially with an LCD), a display error such as a blank screen may occur. In this case, replace the display as follows: For Windows 95/98/Me model Set the resolution to 640 x 480 (the setting before replacement). Set the refresh rate to “Adapter default”...

  • Page 70: Power-Saving Function

    In this case, disable the power-saving function. Peripheral devices/cables Use a Fujitsu-supplied product for a peripheral device or cable to be connected to the PC. Some commercially-available peripheral devices or cables cannot be connected to the PC properly.

  • Page 71: Hardware Specifications

    4 Hardware Specifications Specifications of PC unit Product name DESKPOWER 6000/SS Pentium BIOS ROM 512KB (FLASH ROM) Main memory 128MB (168-pin SDRAM DIMM), Maximum: 512MB Floppy disk 3.5-inch x 1 Hard disk 30/60 GB (standard) Optical Device (Optional) DVD-ROM and CD-R/RW drive (Combo)

  • Page 72: Lan Adapter Specifications

    Since the disk capacity specified in this manual is based on the conversions of 1MB = 1,000 actual capacity displayed on Windows using the conversions of 1MB = 1,024 specified in this manual. Disk capacities are based on conversion of 1 MB = 1000 of 1 MB = 1024 bytes and 1 GB = 1024 Point...

  • Page 73: Graphical Specifications

    Graphical specifications Video controller Display mode Video output signal Video memory Connector specifications The pin assignments and signal names of each connector are as follows: CRT connector Pin No. Signal name GREEN BLUE 5 to 8 HSYNC VSYNC Built-in Intel 82815 Graphics Memory Controller Hub 1280 x 1024 maximum (1024 x 768 maximum for digital output) Video: analog RGB, synchronization signal:...
  • Page 74 DVI connector Pin No. Signal name TX2– TX2+ TX2/4 Shield TX4- TX4+ DDC Clock DDC Data TX1– TX1+ TX1/3 Shield TX3– TX3+ Hot Plug Detect TX0– TX0+ TX0/5 Shield TX5- TX5+ TXC Shield TXC+ TXC– Description Output Data channel 2– Output Data channel 2+ —...
  • Page 75 LAN connector (100BASE-TX/10BASE-T) Pin No. Signal name TD– RD– Parallel connector Pin No. Signal name STROBE DATA 0 DATA 1 DATA 2 DATA 3 DATA 4 DATA 5 DATA 6 DATA 7 BUSY SELECT AUTOFD ERROR INIT SLCTIN 18 to 25 Description Output Transmit data+...
  • Page 76 Serial connector Pin No. Signal name Mouse connector Pin No. Signal name DATA Keyboard connector Pin No. Signal name DATA Description Input Carrier detect Input Receive data Output Transmit data Output Data terminal ready — Ground Input Data set ready Output Request to send Input...
  • Page 77 USB connector 1 2 3 4 Pin No. Signal name –DATA +DATA Description — Cable/power –data signal +data signal — Cable/ground...

  • Page 78: Index

    Index Burglarproof lock ... 5 Busy lamp ... 3 CD-ROM drive ... 3, 29 Connection ... 16 keyboard ... 18 LAN cable ... 18 mouse ... 18 PC unit ... 18 power cable ... 17 Cover ... 38 CRT connector ... 5 Display ...
  • Page 79 Mouse ... 10 clicking ... 10 connector ... 5 double-clicking ... 11 dragging ... 11 moving ... 10 pointing ... 11 scrolling ... 11 Outlet ... 5 Parallel connector ... 5 Peripheral device ... 36 Power lamp ... 3 switch ... 3 Power supply unit ...
