3.5

Ai Tweaker menu

The Ai Tweaker menu items allow you to configure overclocking-related items.
Be cautious when changing the settings of the Ai Tweaker menu items. Incorrect field
values can cause the system to malfunction.
The configuration options for this chapter vary depending on the CPU and DIMM model you
installed on the motherboard.
Main Ai Tweaker
Configure System Performance Settings

Ai Overclock Tuner

CPU Ratio Setting

Intel(R) SpeedStep(TM) Tech

Intel(R) TurboMode Tech

Xtreme Phase Full Power Mode
DRAM Frequency
QPI Frequency
DRAM Timing Control
CPU Differential Amplitude
CPU Clock Skew
******* Please key in numbers directly! *******
CPU Voltage Mode
Offset Voltage
IMC Voltage
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
Scroll down to display the following items:
DRAM Voltage
CPU PLL Voltage
PCH Voltage
iGPU Voltage
***********************************************
Load-Line Calibration
CPU Spread Spectrum
PCIE Spread Spectrum
v02.61 (C)Copyright 1985-2009, American Megatrends, Inc.
3.5.1 Ai Overclock Tuner [Auto]
Allows selection of CPU overclocking options to achieve desired CPU internal frequency.
Select either one of the preset overclocking configuration options:
Manual
Auto
D.O.C.P
X.M.P.
The configuration options for the following sub-item vary depending on the DIMMs you
install on the motherboard.
ASUS P7H55-M PRO
BIOS SETUP UTILITY
Advanced Power
[Auto]
[Auto]
[Enabled]
[Enabled]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Offset]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
[Auto]
Allows you to individually set overclocking parameters.
Loads the optimal settings for the system.
Overclocks DRAM frequency by adjusting BCLK frequency.
If you install memory module(s) supporting the eXtreme
Memory Profile (X.M.P.) Technology, choose this item to set the
profile(s) supported by your memory module(s) for optimizing
the system performance.
Boot Tools Exit
Warning: this function
belongs to overclock-
ing, and it may cause
instability.
Select a CPU level,
and the rest will be
auto-adjusted. If you
want to adjust more,
set Ai Overclock Tuner
to Manual after you
select a CPU level.
Select Screen
←→
Select Item
↑↓
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
3-15
