P/I P65UP8
R
Baseboard for CPU Cards
USER'S MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Asus P I-P65UP8 CP6ND

Summary of Contents for Asus P I-P65UP8 CP6ND

  • Page 1 P/I P65UP8 Baseboard for CPU Cards USER’S MANUAL...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Asus Contact Information

    +1-408-474-0569 Email: tsd-usa@asus.com.tw WWW: www.asus.com ASUS COMPUTER GmbH Marketing Info Address: Harkort Str. 25, 40880 Ratingen, BRD, Germany Telephone: 49-2102-445011 Fax: 49-2102-442066 Email: info-ger@asus.com.tw Technical Support Hotline: 49-2102-499712 BBS: 49-2102-448690 Email: tsd-ger@asus.com.tw WWW: www.asuscom.de FTP: ftp.asuscom.de/pub/ASUSCOM ASUS P/I-P65UP8 User’s Manual...

  • Page 4: Table Of Contents

    CONTENTS I. INTRODUCTION ............7 How this Manual is Organized ............7 Item Checklist .................. 7 Features of the ASUS P/I-P65UP8 Baseboard ........ 8 II. FEATURES ..............8 Parts of the ASUS Baseboard ............9 III. INSTALLATION ............. 10 ASUS Baseboard Layout ............... 10 Installation Steps ................
  • Page 5 (This page was intentionally left blank.) ASUS P/I-P65UP8 User’s Manual...

  • Page 6: Federal Communications Commission Statement

    Canadian Department of Communications Statement This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Cana- dian Department of Communications. ASUS P/I-P65UP8 User’s Manual...

  • Page 7: Introduction

    (1) Floppy ribbon cable for (1) 5.25inch floppy and (2) 3.5inch floppies (1) bag of spare jumpers (1) Motherboard User’s Manual (1) SCSI Utilities User’s Manual (1) C-P6ND or C-PKND CPU card (1) Infrared module (optional) ASUS P/I-P65UP8 User’s Manual...

  • Page 8: Features Of The Asus P/I-P65Up8 Baseboard

    II. FEATURES Features of the ASUS P/I-P65UP8 Baseboard The P/I-P65UP8 is carefully designed for the demanding PC user who wants great versatility in a computer system. This baseboard: • Versatile Processor Support: Supports dual 150–200MHz Pentium Pro or dual 233–333MHz Pentium II processors.

  • Page 9: Parts Of The Asus Baseboard

    II. FEATURES Parts of the ASUS Baseboard Onboard Universal Programmable 3 Primary S3 VGA Serial Bus Flash ROM Keyboard PCI Slots 4 Secondary Parallel & PCI Slots Serial Connectors 3 ISA Slots Onboard VGA memory sockets IDE 1 & 2...

  • Page 10: Installation

    Lithium Cell S3 VGA Chipset Intel Chipset Intel i960 Chipset 960SEL Symbios Logic 7880IDSEL SCSI Chipset Adaptec SCSI Chipset DRAMRAS HDLED A HDLED RTC RAM HDLED B CR2032 3Volts Lithium Cell i960’s BIOS Power NVRAM Battery Test ASUS P/I-P65UP8 User’s Manual...
  • Page 11 30 Speaker Output Connector (4 pins) 19) SCSI-50, SCSI-68 p. 31 Ultra-Fast and Ultra-Wide SCSI Connectors 20) PWRCON, PWR-CON2 p. 32 AT Power Supply Connector (12-pin block) 21) ATXPOWER p. 32 ATX Power Supply Connector (20-pin block) ASUS P/I-P65UP8 User’s Manual...

  • Page 12: Installation Steps

    3. Hold components by the edges and try not to touch the IC chips, leads or connectors, or other components. 4. Place components on a grounded antistatic pad or on the bag that came with the component whenever the components are separated from the system. ASUS P/I-P65UP8 User’s Manual...

  • Page 13: Jumper Settings

    DRAMRAS Setting Single Sided DRAM [1-2] Double Sided DRAM [2-3] DRAMRAS DRAMRAS Double Sided Single Sided DRAMS DRAMS DRAM RAS Setting ASUS P/I-P65UP8 User’s Manual...
  • Page 14 Set to SCSI ID 15, if you wish for the onboard Symbios 53C876 device to boot. 7880IDSEL Setting ID 9-Boot [2-3] ID 15-No boot [1-2] 7880IDSEL 7880IDSEL SCSI ID 9 SCSI ID 15 7880 ID Setting ASUS P/I-P65UP8 User’s Manual...
  • Page 15 The CMOS RAM containing the BIOS setup information may be cleared by this action. You must enter BIOS to “Load Setup Defaults” and re-enter any user information after removing and reapply- ing this jumper. ASUS P/I-P65UP8 User’s Manual...
  • Page 16 [short] [open] [open] [short] 66MHz [----] [----] [----] 300MHz 4.5x [open] [short] [open] [short] 66MHz [----] [----] [----] 266MHz 4.0x [short] [short [open] [short] 66MHz [----] [----] [----] 233MHz [open] [open] [short] [short] 66MHz [----] [----] [----] ASUS P/I-P65UP8 User’s Manual...
  • Page 17 III. INSTALLATION (This page was intentionally left blank) ASUS P/I-P65UP8 User’s Manual...

  • Page 18: System Memory (Dram)

    EDO DRAM modules when 960SEL jumper is set to “I2O.” The i960 does not require memory in the “Bridge” mode. Use i960 SIMM socket 1 when using only one module. The i960 does not support parity or ECC. ASUS P/I-P65UP8 User’s Manual...

  • Page 19: Dram Memory Installation Procedures

    4. The plastic guides should go through the two mounting holes on the sides and the clips should snap on the other side. 5. To release the memory module, squeeze both clips outward and rock the module out of the clips. ASUS P/I-P65UP8 User’s Manual...

  • Page 20: Central Processing Unit

    III. INSTALLATION 3. Central Processing Unit The P/I-P65UP8 baseboard provides a CPU card slot that can be used with the ASUS C-PKND or C-P6ND CPU cards, which are available separately. You must purchase any one of these CPU cards (see next page for a brief description) to complete the system’s board.
  • Page 21 Refer to your respective CPU card’s docu- mentation for details. General Installation Procedures for the ASUS CPU Card: 1. Remove the CPU card from its packaging without touching the integrated circuit (IC) chips, connectors, and other components. Place it onto the antistatic bag.

  • Page 22: Expansion Cards

    If using PCI cards on shared slots, make sure that the drivers support “Share IRQ” or that the cards do not need IRQ assignments. Conflicts will arise between the two PCI groups that will make the system unstable or cards inoperable. ASUS P/I-P65UP8 User’s Manual...

  • Page 23: Assigning Dma Channels For Isa Cards

    IMPORTANT: To avoid conflicts, reserve the necessary IRQs and DMAs for legacy ISA cards (under PNP AND PCI SETUP of the BIOS SOFTWARE, choose Yes in IRQ xx Used By ISA and DMA x Used By ISA for those IRQs and DMAs you want to reserve). ASUS P/I-P65UP8 User’s Manual...

  • Page 24: External Connectors

    (Pin 5 is removed to prevent inserting in the wrong orienta- tion when using ribbon cables with pin 5 plugged). Pin 1 Orient the red stripe on the floppy ribbon cable to Pin 1 Floppy Disk Drive Connector ASUS P/I-P65UP8 User’s Manual...
  • Page 25 COM1 (using 9-pin male) and COM2 (using 25-pin male) to a free expansion port. TIP: You may also remove the bracket COM 1 connectors and mount them directly to the case to save expansion slot space. Serial Port Connectors ASUS P/I-P65UP8 User’s Manual...
  • Page 26 TIP: If the case-mounted LED does not light, try reversing the 2-pin plug. HD LED A (for Symbios Ch A) HD LED (for Adaptec and IDE) HD LED B (for Symbios Ch B) IDE Activity LED Lead ASUS P/I-P65UP8 User’s Manual...
  • Page 27 Match the small indentation on the chip’s sloped edge with the socket’s cut corner. Place the chip flat and evenly into the socket and press firmly but carefully so that the chip enters evenly. When installed, the chip should be flush with the socket. ASUS P/I-P65UP8 User’s Manual...
  • Page 28 1: USB +5Volt 4: USB Port 0 – 3: USB Port 1 – 6: USB Port 0 + 5: USB Port 1 + 8: Ground 7: Ground 10: (no connection) 9: (no connection) USB Module Connector ASUS P/I-P65UP8 User’s Manual...
  • Page 29 III. INSTALLATION 11. ASUS System Monitoring Module Connector (20-1 pin SERVER_CON) This connector is for an optional ASUS System Monitoring Module for moni- toring system temperature and fan RPM. Pin 1 Server Connector 12. Chassis Open Alarm Connector (4-1 pin CHASSIS) This connector is for an optional ASUS System Monitoring Module for moni- toring chassis open/close status.
  • Page 30 Power LED PLED# Ground KLock# Keyboard Lock ExtSMI# SMI Lead Ground Ground PWRBT# ATX Power +5 Volts Ground Speaker Switch* Ground Connector Ground ResetCon Reset SW Ground SPKR Requires an ATX power supply. System Panel Connectors ASUS P/I-P65UP8 User’s Manual...
  • Page 31 SCSI device connection on one channel (two types of connectors are provided). Connect one chain of 50-pin SCSI devices and/or one chain of 68-pin SCSI device not to exceed a maximum of 15 SCSI devices on each channel. ASUS P/I-P65UP8 User’s Manual...
  • Page 32 +5V Standby +5.0 Volts Power Good -5.0 Volts Ground Ground 5.0 Volts Ground Ground Ground Power Supply On +5.0 Volts Ground Ground +3.3 Volts -12.0 Volts +3.3 Volts +3.3 Volts Power Connector on Motherboard ATX Power Connector ASUS P/I-P65UP8 User’s Manual...

  • Page 33: Vga Installation

    1. Click OK to use the default selection: Driver from disk provided by hard- ware manufacturer 2. Insert ASUS support CD and click Browse button - Open window appears 3. Select your CD-ROM drive in the Drives: box 4. Select VGA\WIN95 5.

  • Page 34: Windows 95 Video Driver Installation

    CD-ROM drive is letter D) or click Browse button to select the path of the display driver for Windows 95. Click OK. You will see a list of ASUS VGA devices. Select the appropriate VGA device and press OK to start installation.

  • Page 35: Windows 95 Display Settings

    Adjust performance Adjust Set to default values display size Change Refresh Rate: List of refresh rate options Customize refresh rate Set to default sup- Add to list ported refresh rate Test customized Delete refresh rates from list ASUS P/I-P65UP8 User’s Manual...
  • Page 36 Settings: Allows you to change your display settings, adjust screen resolution and color depth, virtual desktop, color palette and font size. Current Adjust refresh rate screen resolution Adjust color Adjust virtual desktop size Adjust font size ASUS P/I-P65UP8 User’s Manual...

  • Page 37: Windows Nt 4.0 Video Driver Installation

    7. Windows NT will prompt you for the correct path, enter the path of driver in CD-ROM such as D:\VGA\NT40 (assuming your CD-ROM drive is letter D). 8. A list of ASUS S3 series video adapters will be displayed. Select the one you are using, then click on the OK button.

  • Page 38: Windows Nt 3.51 Video Driver Installation

    5. Click Change Display Type button. 6. Click Change button. 7. Click Other. 8. Insert the ASUS support CD into your CD-ROM drive. For Windows NT 3.51, type the following: D:\VGA\NT351 (assuming your CD-ROM drive is letter D) 9. Click OK button.

  • Page 39: Ibm Os/2 Video Driver Installation

    3. Double-click the Command Prompts folder 4. Double-click the OS/2 Full Screen object 5. Insert the ASUS support CD (assuming your CD-ROM drive is letter D) 6. Type D:\VGA\OS2\ENGLISH <Enter> and SETUP.CMD <Enter> 7. In the Monitor Configuration Selection Utility, select Install Using Defaults for Monitor Type 8.
  • Page 40 IV. VGA Installation (This page was intentionally left blank) ASUS P/I-P65UP8 User’s Manual...
