D-Link DIR-505L Quick Installation Manual

Quick installation guide
Hide thumbs

Advertisement

Quick Links

Quick Install Guide
SharePort Mobile Companion
Start Here - Select The Mode

Router Mode

This feature behaves as a router in areas where you
cannot take your home router so that you may
wirelessly connect to the internet.
QRS Mobile Setup For Router Mode (iPhone and iPad Only)
2
1
Router/AP
Settings
Scan the QRS Mobile code
Move the switch on the DIR-
to download QRS Mobile
505L to "Router/AP Mode"
App from the App Store to
and plug it into a wall outlet.
your iPhone or iPad. You can
also search "QRS Mobile"
From your iOS mobile device,
from the App Store.
click Settings. Then, click
Wi-Fi.
Router/Access Point Mode
1
Router/AP
Power off
Charger
Router/AP
Repeater
Wi-Fi
Hotspot
Outlet
Ethernet
Find an outlet close to an Internet- enabled device.
Then, move the switch to "Router/AP Mode" and plug
the DIR-505L into a wall outlet. Verify that the power
LED has turned green.

Repeater Mode

Repeater Mode
2
1
Repeater
Power off
Charger
Router/AP
Repeater
Wi-Fi
Hotspot
54mm
Move the switch to "Repeater
From your laptop or mobile device go
Mode". Then, plug the DIR-505L
to your Wireless Utility to display the
into a wall outlet and verify that
available wireless networks and select
the power LED has turned green.
the network that is displayed on your
companion card (ex: dlink-a8fa). Then,
enter the Wi-Fi password included in your
card (ex: akbdj19368).
AP Mode
Use Access Point (AP) mode if you want to connect
wireless clients (such as laptops, tablets, smartphones, and
media players) to your wired network (via router, switch, or
PowerLine devices).
3
Power off
Charger
Router/AP
Power off
Charger
Repeater
Router/AP
Wi-Fi
Repeater
Hotspot
Wi-Fi
Hotspot
90mm
D-Link DIR-505 Mobile Companion Wi-Fi Configuration Note
Web browser link:
Web browser link:
http://dlinkrouter or
http://dlinkrouter or
http:// 192.168.0.1
http:// 192.168.0.1
Default configuration
Your configuration
Username: "Admin"
Username: Admin
Password: "" (leave the field blank)
Password:
Wi- Fi Name (SSID) :
54mm
Wi- Fi Name (SSID) :
dlinka8fa
Wi-Fi Password :
Outlet
Ethernet
akbdj19368
Wi-Fi Password :
Outlet
Ethernet
Wireless Utility to displays the available
wireless networks and select the Wi-Fi
name that is shown on your companion
card (ex: dlink-a8fa). Then, enter the
Wi-Fi password included in your card (ex:
akbdj19368).
2
Internet
Connect one end of the Ethernet cable into the
Ethernet port of the Internet-enabled device (e.g.
modem, router) and then plug the other end of this
cable into the Ethernet port of the DIR-505L.
3
90mm
D-Link DIR-505 Mobile Companion Wi-Fi Configuration Note
Web browser link:
Web browser link:
http://dlinkrouter or
http://dlinkrouter or
http:// 192.168.0.1
http:// 192.168.0.1
Default configuration
Your configuration
Username: "Admin"
Username: Admin
Password: "" (leave the field blank)
Password:
Wi- Fi Name (SSID) :
Wi- Fi Name (SSID) :
dlinka8fa
Wi-Fi Password :
akbdj19368
Wi-Fi Password :
Open a web browser and type
http://dlinkrouter (Windows) or
http://dlinkrouter.local (Mac/
iPhone/iPad) . Please follow the
on-screen instructions to complete
the setup.

Package Contents

• SharePort Mobile Companion
• Ethernet Cable
If any of the above items are missing, please contact your reseller.

Operation Mode

Charger Mode is only used to charge your mobile
device such as an iPad, iPhone & Android etc. While
the DIR-505L is on charge mode, all other functions
will be disabled.
LEDs
Power LED - A solid green light indicates
a proper connection to the power supply.
The light will be solid red during boot up
and during a factory reset.
DIR-505L
Pleaser refer to the user manual for further
information regarding SharePort Mobile
App. Please download the user manual from
http://www.dlink.com/support/
Repeater Mode
This feature extends your wireless coverage allowing you
to share your wireless signal with all your portable devices
Start Here
such as your mobile device or laptop.
4
5
Once it connected, click on the QRS
Please follow the on-screen
Mobile icon from your iOS mobile
instructions to complete the setup.
device. Then click Start to continue.
3
90mm
D-Link DIR-505 Mobile Companion Wi-Fi Configuration Note
Web browser link:
Web browser link:
http://dlinkrouter or
http://dlinkrouter or
http:// 192.168.0.1
http:// 192.168.0.1
Default configuration
Your configuration
Username: "Admin"
Username: Admin
Password: "" (leave the field blank)
Password:
Wi- Fi Name (SSID) :
54mm
dlinka8fa
Wi- Fi Name (SSID) :
Wi-Fi Password :
akbdj19368
Wi-Fi Password :
From your laptop or mobile device go to your
Wireless Utility to display the available wireless
networks and select the Wi-Fi name that is shown
on your companion card (ex: dlink-a8fa). Then,
enter the Wi-Fi password included in your card
(ex: akbdj19368).
4
Select the configuration method and click
Next.
For Manual configuration, select the Wi-Fi
network you would like the DIR-505L to
connect to wirelessly.
QRS Mobile App for iOS Device
Scan this QR code using your iOS mobile
device. You will be directed to the App store
to download the QRS Mobile App so that
you may begin the Installation process.
SharePort Mobile App for iOS Device
Scan this QR code using your iOS
mobile device to download the App
and begin file sharing.
Requirements: Compatible with
iPhone, iPod touch and iPad. Requires
iOS 4.3 or later.
Note: The SharePort Mobile App only
works on Router and Wi-Fi Hotspot
Mode.
This feature allows you to have your own private network
from anywhere that you may travel.
6
Once the screen appears, you
have successfully completed the
setup. Please click Save and write
down the Wi-Fi Name (SSID) and
password on your companion
card for future reference.
4
Open a web browser. First time users will
automatically be directed to the setup wizard. Please
follow the on-screen instructions to complete the setup.
If this is your second time type http://dlinkrouter
(Windows) or http://dlinkrouter.local (Mac/iPhone/
iPad) in the address bar. Once the setup is complete
then proceed to the next step.
5
Enter the Wi-Fi Password and click Next.
Once the second screen appears, you have
successfully completed the setup. Please
click Save and write down the Wi-Fi Name
(SSID) and Password on your companion card
for future reference.
Wi-Fi Hotspot Mode
7
From your iOS mobile device go
to your wireless utility to display
the available wireless networks
and select the network that you
created for internet access.
5
From your laptop or mobile device go to
your wireless utility to display the available
wireless networks and select the network
that you created for Internet access.
6
From your laptop or mobile device
go to your wireless utility to display
the available wireless networks and
select the network that you previously
connected to in Step 5 for internet access.
