SERVICE MANUAL

Picture tube
Phosphor Type
Transmission Ratio
Faceplate
Viewable image size
Resolution
Horizontal
Vertical
Display picture size
Input signal
Video
Sync
0.25 - 0.27 mm aperture grill pitch,
21 inches measured diagonally,
90 degree deflection
P22
Approx. 39%
Anti Reflective (AR)/Anti Static (AS)
coating
Approx. 403.8
302.2 mm (w/h)
(16
12 in.) 19.8" viewing image
Max. 1600 dots
Max. 1200 lines
Approx. 388
291 mm (w/h)
(15
3
/
11
1
/
in.)
8
2
or
Approx. 364
291 mm (w/h)
3
1
(14
/
11
/
in.)
8
2
Analog RGB (75
typical)
0.7 Vp-p, Positive
External HD/VD, Composite
Polarity Free TTL
Video Composite (Sync on green)
0.3 Vp-p, Negative
SPECIFICATIONS
Deflection frequency
Horizontal
Vertical
AC input voltage/current
Inrush current
Power consumption
Maximum
Nominal
Dimensions
Net weight
Shipping weight
Environmental Temperature
Operating
Non-operating
Environmental Humidity
Operating
Non-operating
Design and specifications are subject to change without notice.
D1626HT
US Model
Canadian Model
AEP Model
EQ Model
SH Model
J Model
Chassis No. SCC-L04K-A
N3
CHASSIS
30 to 107 kHz
48 to 160 Hz
100 to 240 V, 50 – 60 Hz, 2.0 – 1.0 A
120 VAC/50 A
240 VAC/80 A
160 W
120 W, 409 BTU/h
498
505
474 mm (w/h/d)
5
3
(19
/
20
18
/
in.)
8
4
Approx. 31 kg (68 lb 5 oz)
37 kg (81 lb 9 oz)
10˚ to 40˚ C (50˚ to 104˚ F)
0˚ to 60˚ C (32˚ to 140˚ F)
10% to 80% (Non-condensing)
5% to 90% (Non-condensing)

COLOR MONITOR

R

Advertisement

Table of Contents
loading

Related Manuals for Dell D1626HT - UltraScan 1600HS - 21" CRT Display

Summary of Contents for Dell D1626HT - UltraScan 1600HS - 21" CRT Display

  • Page 1: Service Manual

    D1626HT SERVICE MANUAL US Model Canadian Model AEP Model EQ Model SH Model J Model Chassis No. SCC-L04K-A CHASSIS SPECIFICATIONS Picture tube 0.25 - 0.27 mm aperture grill pitch, Deflection frequency 21 inches measured diagonally, Horizontal 30 to 107 kHz 90 degree deflection Vertical 48 to 160 Hz...
