Package Contents - Canon imagePROGRAF iPF9400 User Manual

j
a
e
c
b
d
l
k
g
z
i
y
a. Weight Flange 1 (2), Weight Flange 2 (2)
b. Weight Joint
c. Weight Roll (7)
d. Weight Roll Storage Box
e. Weight Flange Storage Box
f. Left Media Take-up Unit
g. Right Media Take-up Unit
h. Left Fastener for Media Take-up Unit
i. Right Fastener for Media Take-up Unit
j. Leg Cover (2)
k. Starter Ink Tanks
• BK, MBK, C, M, Y, PM, PC, GY, PGY, R, G, B
l. Printhead (2)
m. Media Take-up Sensor
n. M4 Hex Screws (35)
o. M8 Hex Bolts (8)
p. Wrench
q. Allen Wrench (2)
r. 3-inch paper core attachment #2
s. 3-inch paper core attachment #1
t. Documentation
u. Set of CD-ROMs
v. Ejection Support (6)
w. Cord Holder (2)
x. Accessory Pocket
y. Power Cord
z. Rewind 3-inch Adapter (2)
a. b.

Package Contents

t
u
r s
v w
x
m
n o
p
f h
q
Basket BU-01 (optional)
c.
a
f.
b
b
a
c
d
e
c
d
• The black belts are used on Tipping installation for the printer. Do not
remove or cut the belts. Otherwise, Tipping installation is no longer possible.
Other documentation may also be included in the package.
d. e.
g. h.
2
a. Bottom Stand Stay
b. Top Stand Stay
c. Left Stand Leg
d. Right Stand Leg
e. Packaging Material for
Printer Installation (2)
a
b
e
f
a. Printer
b. Roll Holder
c. Rewind Spool
d. Cardboard Stand Holder
e. Bottom Sheet
f. Adjustment paper
a. Basket Cloth
b. Basket Rod (2)
c. Middle Basket Rod
d. Basket Arm L
e. Basket Arm R
f. Rod Holder Adapter (2)
g. Rod Holder (2)
h. M4 Hex Screws (2)
