Adapter for
Flat Panel TV Wall Mount
for models MAF10, MAF20, MAF30, MAF40, and MAF50
Fits TVs With 100mm x 200mm VESA Hole Pattern
This adapter fits TVs with mounting holes that are further
apart than the holes on the wall mount's TV mounting
plate. This adapter makes it possible to mount those TVs
on the TV mounting plate and, then, on the wall, using the
RCA Universal Flat Panel TV Wall Mount (sold separately).
Please remove all parts from this package and read the
installation instructions carefully.
Attaching the adapter
Before you can attach the TV mount plate to your TV,
you need to attach the adapters in this package to the TV
mount plate.
The package comes with the bolts, washers you'll use to
attach the adapter to the TV mount plate.
NOTE:
Use the included hardware for mounting
purposes. This hardware has been provided to ensure
a safe and secure mount.
1.
Place one of the adapter plates against the face of the
TV mount plate. Make sure the side of the plate with
two recessed holes is facing you.
2.
Line up the inside holes on the adapter with the
outermost holes on the top of the TV mount plate.
Insert two of the included bolts through these holes.
User's Manual - English
3.
Place the lock washers on the exposed ends of the
bolts, as close as you can to the TV mount plate.
4.
Screw the nuts onto the exposed ends of the bolts.
5
. Repeat steps 1-4 with the other adapter plate on the
outermost holes on the bottom of the TV mount plate.
6.
Tighten all four bolts completely.
Attaching the TV mount plate
MAF200KIT
In this section, you will use the hardware that comes with
the Wall Mount package.
1.
Unplug your flat panel TV before starting this step of
the installation.
IMPORTANT:
may cause damage to the viewing surface.
2.
Before attaching the TV mount plate and adapter to the
TV, determine which hardware to use. Examine the
back of your TV. If the back is flat, use the M4x12mm
bolts. If your TV has a recessed back, use the longer
M4x30mm bolts and 1/2" spacers.
3.
After you have determined which bolts to use, attach
the TV mount plate and adapter to the back of your TV
(use the outermost holes on the adapter).
NOTE:
Be careful not to over-tighten the bolts.
Continue with wall mount installation:
Follow the instructions that come with the wall mount for
attaching the wall mount plate to the wall and attaching
the TV mount plate to the wall mount plate.
NEVER lay the TV face down as this
Limited Lifetime Warranty
Audiovox Electronics Corporation (the "Company") warrants to you the
original retail purchaser of this product that should it, under normal use
and conditions, be proven defective in material or workmanship during
its lifetime while you own it, such defect(s) will be repaired or replaced (at
the Company's option) without charge for parts and repair labor.
To obtain repair or replacement within the terms of this Warranty, the
product is to be delivered with proof of warranty coverage (e.g. dated bill
of sale), specification of defect(s), transportation prepaid, to the Company
at the address shown below. Do not return this product to the Retailer.
This Warranty does not cover product purchased, serviced or used
outside the United States or Canada.
This Warranty is not transferable and does not extend to costs incurred for
installation, removal or reinstallation of the product. This Warranty does
not apply if in the Company's opinion, the product has been damaged
through alteration, improper installation, mishandling, misuse, neglect,
or accident.
THE EXTENT OF THE COMPANY'S LIABILITY UNDER THIS
WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT
PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY'S
LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER
FOR THE PRODUCT.
This Warranty is in lieu of all other express warranties or liabilities. ANY
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
SHALL BE LIMITED TO DURATION OF THIS WARRANTY. IN NO CASE
SHALL THE COMPANY BE LIABLE FOR ANY CONSEQUENTIAL OR
INCIDENTAL DAMAGES WHATSOEVER. No person or representative is
authorized to assume for the Company any liability other than expressed
herein in connection with the sale of this product.
Some states/provinces do not allow limitations on how long an implied
warranty lasts or the exclusion or limitation of incidental or consequential
damage so the above limitations or exclusions may not apply to you. This
Warranty gives you specific legal rights and you may also have other
rights which vary from state/province to state/province.
U.S.A.: Audiovox Electronics Corporation, 150 Marcus Blvd.,
Hauppauge, New York 11788
CANADA: Audiovox Return Center, c/o Genco, 6685 Kennedy Road,
Unit 3, Door 16, Mississauga, Ontario L5T 3A5
Trademark(s) Registered
All other brands and product names are trademarks or registered
trademarks of their respective owners.
© 2007 Audiovox Accessories Corporation
111 Congressional Blvd., Suite 350
Carmel, IN 46032
MAF200KIT_NA_IB_00
www.rcaaccessories.com
