  • Page 1 S550.1D S850.1D S1300.1D S2000.1D...

  • Page 3: Control Functions

    FEATURES DOUBLE SIDE PCB AND SMD COMPONENTS. FULL MOSFET DESIGN. LPF AND SUBSONIC CROSSOVER. ADJUSTABLE BASSBOOST LEVEL. ACTIVE X-OVER FUNCTION. HEAVY-DUTY ALUMINUM ALLOY HEATSINK. HIGH (Speaker) OR LOW (RCA) LEVEL INPUTS. OVERLOAD, OVERHEAT, HIGH/LOW VOLTAGE PROTECTION. ROHS COMPLIANT. CONTROL FUNCTIONS 1.

  • Page 4: Panel Layout

    13. Protection Indicator The red LED will light up or be flashing if there is a fault presented to the amplifier. Please disconnect the amplifier and resolve the fault before reconnecting the amplifier. PANEL LAYOUT Fig 1. S550.1D/S850.1D/S1300.1D/S2000.1D Panel layout 12 13...

  • Page 5: Installation Precautions

    PANEL LAYOUT INSTALLATION PRECAUTIONS Before you install the amplifier, investigate your car's layout very carefully. Take special care when you work near the gas tank, fuel lines, hydraulic lines and electrical wiring. Before making or breaking power connections in your system, disconnect the vehicle battery. Confirm that your head unit or other equipment is turned off while connecting the input jacks and speaker terminals.

  • Page 6: Connecting The Amplifier

    Fig 2. Mount bottom amplifier CONNECTING THE AMPLIFIER 1. Select cable and fuse according to the following table. MODEL S2000.1D S1300.1D S850.1D S550.1D CABLE 2-4# 4-6# 4-6# FUSE 200A 120A 2. Connect the amplifiers ground cable to a close, bare metal part of the frame or chassis.

  • Page 7: Wiring Diagram

    WIRING DIAGRAM Fig 3. Mono amplifier wiring (1 woofer load) RCA signal Source Unit REMOTE signal...
  • Page 8 Fig 4. Mono amplifier wiring (High level input mode) Source Unit ON/OFF control signal...
  • Page 9 WIRING DIAGRAM Fig 5. Mono amplifier wiring (multi woofers) RCA signal Source Unit REMOTE signal *Equivalent parallel woofer load cannot be less than the minimum load rating. The 2 negative terminals are paralleled inside the amplifiers, as are the 2 positive terminals. These are monoblock amplifiers, not multi- channel amplifiers.

  • Page 10: Troubleshooting

    TROUBLE SHOOTING Symptom Possible Remedy Amplifier Check to make sure you have a good ground connection. will not Check that there is battery power on the (+)terminal . power up Check all fuses, replace if necessary . Make sure that the Protection LED is not illuminated. Protection Check for short circuits on speaker leads.

  • Page 11: Specifications

    SPECIFICATIONS Model S550.1D S850.1D PX1.1300D PX1.2000D RMS power at 14.4V 1Ohm Load 550W x 1 850W x 1 1300W x 1 2000W x 1 2Ohm Load 400W x 1 600W x 1 900W x 1 1300W x 1 4Ohm Load 240W x 1 350W x 1 520W x 1...

This manual is also suitable for:

Sedona s2000.1dSedona s550.1dSedona s850.1d
