OWNER'S MANUAL AND INSTALLATION
Register your product at www.samsung.com/global/register
CONTENTS
.............................................................. 2
SETTING UP THE REFRIGERATOR ....................................................... 4
MAJOR FEATURES.................................................................................... 4
CONTROL PANEL ...................................................................................... 5
DIGITAL PANEL........................................................................................... 6
TEMPERATURE CONTROL ..................................................................... 7
ICE AND COLD WATER DISPENSER ..................................................... 7
SHELVES AND BINS.................................................................................. 8
FOOD STORAGE GUIDE .......................................................................... 9
DRAWER GUIDE ......................................... 11
DRAWER GUIDE........................................... 12
REMOVING THE FREEZER ACCESSORIES......................................... 13
REMOVING THE FRIDGE ACCESSORIES.......................................... 13
REMOVING THE ARCTIC SELECT ZONE ACCESSORIES................. 14
REMOVING THE FRESH SELECT ZONE ACCESSORIES .................. 14
CLEANING THE ACCESSORIES ............................................................ 15
CHANGING THE INTERIOR LIGHT ........................................................ 16
WATER FILTER ......................................................................................... 18
DOORS...................................................................................................... 18
INSTALLATION OF THE REFRIGERATOR ............................................ 20
ADJUSTING THE HEIGHT BETWEEN THE DOORS............................ 21
REMOVING THE REFRIGERATOR DOORS.......................................... 24
REATTACHING THE REFRIGERATOR DOORS .................................... 25
CHECKING THE WATER DISPENSER LINE.......................................... 32
INSTALLATION OF THE WATER DISPENSER LINE ............................. 32
BEFORE YOU CALL FOR SERVICE....................................................... 37
SIDE BY SIDE
REFRIGERATOR
....................................................... 4
............................................... 19
DA99-01418B REV(0.0)
