    CDMA PORTABLE PCS TELEPHONE ELECTRONIC SCH-6100 SERVICE Manual CDMA PORTABLE PCS TELEPHONE CONTENTS 1. Specfication 2. NAM Programming 3. Test Procesure - Test command 4. Product Support Tool 5. Exploded Views and Parts List ME NU TA LK EN D 6.
  • Page 2 1. Specification 1-1 General Frequency Range Transmitter : 1850 ¡- 1910 MHz Receiver : 1930 ¡- 1990 MHz Channel Bandwidth : 1.23 MHz Channel Spacing : 50 KHz Number of Channels : 1200 Duplex Separation : 80 MHz Type of Emission : G7W Input/Output Impedance : 50 ohms...
  • Page 3 1-2 Transmitter Waveform Quality : 0.944 or more Open Loop Power Control Range ¡¤ -25 dBm : -60.5dBm ¡- -41.5dBm ¡¤ -65 dBm : -20.5dBm ¡- +1.5dBm ¡¤ -104dBm : +15.0dBm ¡- +30.0dBm Minimum TX Power Control : -50dBm below Closed Loop Power Control Range : ¡¾...

  • Page 4: Nam Programming

    2. NAM Programming NAM features can be programmed as follows: Notes: - If you enter the NAM program mode, each item shows the currenly stored data. Go to the next item by pressing <OK/ •• >. - You can modify the data by entering a new data. - If you enter a wrong digit, press <CLR>...
  • Page 5 Slot Index Slot mode index. The higher, the longer sleeping time -to change,enter new one. -stores it. OK/ •• Browser Up Browser Enable - changes the status. ¡ç ¡æ -stores it. OK/ •• 2-2 Setting Up NAM1 ------------------------------------------------------------------------------------------------------------------- LCD Display Key in Function -------------------------------------------------------------------------------------------------------------------...
  • Page 6 CDMA fNID CDMA foreign NID, current status is displayed. - changes the system. ¡ç ¡æ -stores it. OK/ •• Home SID first SID written in the list, current status is displayed. 4120 number -to change, enter new one. -stores it. OK/ ••...

  • Page 7: Test Procesure - Test Command

    3. Test Procesure - Test command List of Equipments - DC Power Supply - Test Jig - Test Cable - CDMA Mobile Station Test Set HP8924C, HP83236A, CMD-80, etc - Spectrum Analyzer(include CDMA test mode) HP8596E Configuration of Test Spectrum Analyzer RF In HP8924C In/Out...
  • Page 8 Configuration of Test(Hands-Free) HANDS FREE KIT BOX ANTENNA CRADLE DATA DC POWER Orange SUPPLY Black (+13.7V) CDMA Portable PCS Telephone...
  • Page 9 (USE BNC CABLE) TEST CABLE DB25 CONNECTOR I/F CONNECTOR CONNECT TO DB25 CONNECTOR OF CONNECT TO HHP TEST INTERFACE BOX Items needed to purchase from SAMSUNG ITEMS SEC CODE REMARK Cable Loss : 2.1dB,1.9 GHz RF Cable GH39-00007A Connection between Phone and Test Equipment (Ex. 8924C)
  • Page 10 Test Mode A. To change the phone's state from Normal Mode to Test Mode, You should enter the following keys. "4 7 * 8 6 9 # 1 2 3 5" B. Press the keys "0 1"(Suspend) always in the Test Mode. C.

  • Page 11: Test Command Table

    TEST COMMAND TABLE COMMAND NO COMMAND SW NO DESCRIPTION (OP,AB,RB) 01(1F,0,0) T_SUSPEND_I Enter to test menu 02(3F,0,0) T_RESTART_I Escape from test menu 03(FD,0,0) T_SAVE_VAL_I Save values in EEPROM only in auto test 04(1D,0,1) T_GET_MODE_I Get mode CDMA/FM 05(1C,1,0) T_SET_MODE_I Set mode CDMA/FM 06(1E,0,0) T_WRITE_NV_I Write the EEPROM item...
  • Page 12 COMMAND NO COMMAND SW NO DESCRIPTION 47(B3,3,0) T_FM_AUD_GAIN_I FM audio gain 48(B4,0,0) T_VIBRATOR_ON_I Activate a vibrator 49(B5,0,0) T_VIBRATOR_OFF_I Inactivate a vibrator 50(B6,0,4) T_BATT_TYPE_I Battery Type 52(B9,2,2) T_HW_VERSION_I HW version 55(AC,1,0) T_EXT_AUDIO_I External Audio Path On/Off 57(BC,0,0) T_MIC_ON_I Mute MIC Path 58(BD,0,0) T_MIC_OFF_I Unmute MIC Path...
  • Page 13 COMMAND NO COMMAND SW NO DESCRIPTION (OP,AB,RB) 90(F0,2,0) T_HW_CHANFLAT_I ------- 91(F1,4,0) T_SW_CHANFLAT_I ------- 92(F2,3,0) T_FM_TX_PWR_I Setting the volume for power level 2 93(F3,3,0) T_CH_FLATNESS_I 94(EF,3,0) T_RXRAS_ADJ_I 95(F4,4,0) T_PCS_H W_ CHA NFL AT_ I 96(F5,4,0) T_PCS_SW _CH ANFLAT_I 97(F6,3,0) T_PCS_CH_FLATNESS_I 98(F7,3,0) T_PCS_CH_MAX_MIN_I Edge Channel Max/Min Power Code 99(FC,3,0)

  • Page 14: Product Support Tool

    IMPORTANT INFORMATION Purpose The Product Support Tool (PST) offers you the ability to interface with the SAMSUNG PCS telephone using a PC. With this tool you can program the phones network system requirements and functionality, swap phone data, and download software upgrades.
  • Page 15 The Main Menu Screen shows the basic tasks that are available. CAUTION: DO NOT attempt to program phone with a low battery. PST SETUP UniPst supports SAMSUNG PCS portable telephone. You can select serial port COM1 or COM2. 4-2-2 Operation Procedure...
  • Page 16 Edit Items Click this icon to edit Number Assignment Module (NAM) items or UI items. There are two types of screens: 1. Parameters associated with a particular Number Assignment Module (NAM) 2. UI items settings Phone Book Click this icon to edit Phone Book. While you edit cell, you can use <Enter>...
  • Page 17 1. From the main menu screen choose DOWNLOAD MODE Click open icon to choose a BIN file of the new software to be loaded. Choose the appropriate BIN file, then Click <Open> 2. Click Download to begin downloading the file. You will notice various messages and a progress bar that informs the user what percentage of the downloading has already occurred.

  • Page 18: Exploded Views And Parts List

    5. Exploded View and Parts List 5-1 Main Set Exploded View 12 13 29 28 CDMA Portable PCS Telephone...

  • Page 19: Main Set Parts List

    5-2 Main Set Parts List LEVEL DESCRIPTION SEC CODE Q’TY REMARK MEA FRONT-SCH6100 GH97-01499A ASS’Y MEC-FRONT COVER GH75-00332A ASS’Y PMO-FRONT COVER GH72-00560A PMO-REFLECTOR LED GH72-00561A MPR-SPONGE LCD GH74-00286A MPR-TAPE WINDOW GH74-00287A PCT-WINDOW LCD GH73-00297A WINDOW-LCD BOHO VINYLE GH74-00555A RMO-KNOB VOLUME GH73-00316A CUSHION-EARPHONE (A) GH74-00530A...
  • Page 20 LEVEL DESCRIPTION SEC CODE Q’TY REMARK RMO-HOLDER MIC GH73-00183A RMO-CUSHION MIC GH73-00297A MEA REAR-SCH6100 GH97-01500A ASS’Y MEC-REAR COVER GH75-00335A ASS’Y PMO-REAR COVER GH72-00563A PMO-LOCKER MAIN GH72-01224A SPRING-LOCKER GH70-10516A PMO-EARPHONE COVER GH72-00564A NDC-ANT. BUSHING GH71-00035A VIBRATOR GH31-00007A SPONGE-MOTOR GH74-00516A LABEL(R)-QUALCOMM GH68-30846A ANTENNA-CONTACT GH71-00056A COVER CONNECTOR...

  • Page 21: Electrical Parts List

    6. Electrical Parts LIST Location No. Description SEC CODE Remark PBA MAIN-ONE BOARD;SCH-6100,SPR GH92-00808A ANTENNA-FIXED GH42-00034A NDC-ANTENNA CONTACT GH71-00056A BATTERY-STANDARD GH43-00162A BATTERY-EXTENDED GH43-00150A ELA ETC-VOLUME KEY ASS’Y GH96-00868A ELA ETC-MIC FPC ASS’Y GH96-00867A D301 DIODE-VARACTOR;1SV279,15V 0405-001035 D302 DIODE-VARACTOR;1SV279,15V 0405-001035 D413 DIODE-VARACTOR;1SV279,15V...
  • Page 22 Location No. Description SEC CODE Remark U203,U205 ILC7082AIM5-30 1203-001850 U303 KT16-DCV30L-19.680M-T 2809-001230 U204 ILC7082AIM5-31 1203-001887 U202 IC REGULATOR;2988AIMMX-2.8 1203-001879 U207 LRS1349 1109-001153 TH421 THERMISTOR-NTC;10Kohm,5%, 1404-001040 R170 R-CHIP;100ohm,5%,1/16W,DA 2007-000138 R171 R-CHIP;100ohm,5%,1/16W,DA 2007-000138 R174 R-CHIP;100ohm,5%,1/16W,DA 2007-000138 R175 R-CHIP;100ohm,5%,1/16W,DA 2007-000138 R191 R-CHIP;100ohm,5%,1/16W,DA 2007-000138 R308 R-CHIP;100ohm,5%,1/16W,DA 2007-000138...
  • Page 23 Location No. Description SEC CODE Remark R201 R-CHIP;100Kohm,5%,1/16W,D 2007-000162 R203 R-CHIP;100Kohm,5%,1/16W,D 2007-000162 R206 R-CHIP;100Kohm,5%,1/16W,D 2007-000162 R212 R-CHIP;100Kohm,5%,1/16W,D 2007-000162 R221 R-CHIP;100Kohm,5%,1/16W,D 2007-000162 R230 R-CHIP;100Kohm,5%,1/16W,D 2007-000162 R101 R-CHIP;150Kohm,5%,1/16W,D 2007-000164 R240 R-CHIP;150Kohm,5%,1/16W,D 2007-000164 R251 R-CHIP;150Kohm,5%,1/16W,D 2007-000164 R204 R-CHIP;200Kohm,5%,1/16W,D 2007-000165 R113 R-CHIP;1Mohm,5%,1/16W,DA, 2007-000170 R310 R-CHIP;1Mohm,5%,1/16W,DA, 2007-000170 R478...
  • Page 24 Location No. Description SEC CODE Remark R151 R-CHIP;7.5Kohm,5%,1/16W,D 2007-001329 R108 R-CHIP;18Kohm,5%,1/16W,DA 2007-001333 R484 R-CHIP;62KOHM,5%,1/16W,DA 2007-003023 R464 R-CHIP;43KOHM,5%,1/16W,DA 2007-007101 R492 R-CHIP;100Kohm,1%,1/16W,D 2007-007107 R301 R-CHIP;15Kohm,1%,1/16W,DA 2007-007132 R427 R-CHIP;15Kohm,1%,1/16W,DA 2007-007132 R472 R-CHIP;15Kohm,1%,1/16W,DA 2007-007132 R470 R-CHIP;18Kohm,1%,1/16W,DA 2007-007135 R141 R-CHIP;3.9Kohm,1%,1/16W,D 2007-007315 R465 R-CHIP;47Kohm,1%,1/16W,DA 2007-007139 R471 R-CHIP;47Kohm,1%,1/16W,DA 2007-007139 R473...
  • Page 25 Location No. Description SEC CODE Remark C252 C-CERAMIC,CHIP;10nF,10%,1 2203-000254 C304 C-CERAMIC,CHIP;10nF,10%,1 2203-000254 C307 C-CERAMIC,CHIP;10nF,10%,1 2203-000254 C331 C-CERAMIC,CHIP;10nF,10%,1 2203-000254 C333 C-CERAMIC,CHIP;10nF,10%,1 2203-000254 C335 C-CERAMIC,CHIP;10nF,10%,1 2203-000254 C337 C-CERAMIC,CHIP;10nF,10%,1 2203-000254 C339 C-CERAMIC,CHIP;10nF,10%,1 2203-000254 C381 C-CERAMIC,CHIP;10nF,10%,1 2203-000254 C383 C-CERAMIC,CHIP;10nF,10%,1 2203-000254 C410 C-CERAMIC,CHIP;10nF,10%,1 2203-000254 C426 C-CERAMIC,CHIP;10nF,10%,1 2203-000254 C429...
  • Page 26 Location No. Description SEC CODE Remark C274 C-CERAMIC,CHIP;1nF,10%,50 2203-000438 C275 C-CERAMIC,CHIP;1nF,10%,50 2203-000438 C276 C-CERAMIC,CHIP;1nF,10%,50 2203-000438 C277 C-CERAMIC,CHIP;1nF,10%,50 2203-000438 C278 C-CERAMIC,CHIP;1nF,10%,50 2203-000438 C279 C-CERAMIC,CHIP;1nF,10%,50 2203-000438 C280 C-CERAMIC,CHIP;1nF,10%,50 2203-000438 C282 C-CERAMIC,CHIP;1nF,10%,50 2203-000438 C315 C-CERAMIC,CHIP;1nF,10%,50 2203-000438 C316 C-CERAMIC,CHIP;1nF,10%,50 2203-000438 C317 C-CERAMIC,CHIP;1nF,10%,50 2203-000438 C321 C-CERAMIC,CHIP;1nF,10%,50 2203-000438 C332...
  • Page 27 Location No. Description SEC CODE Remark C151 C-CERAMIC,CHIP;47nF,10%,1 2203-001432 C309 C-CERAMIC,CHIP;47nF,10%,1 2203-001432 C311 C-CERAMIC,CHIP;5pF,0.25pF 2203-001437 C421 C-CERAMIC,CHIP;5pF,0.25pF 2203-001437 C430 C-CERAMIC,CHIP;5pF,0.25pF 2203-001437 C233 C-CERAMIC,CHIP;4700NF,+80 2203-001724 C243 C-CERAMIC,CHIP;4700NF,+80 2203-001724 C253 C-CERAMIC,CHIP;4700NF,+80 2203-001724 C270 C-CERAMIC,CHIP;0.56nF,10% 2203-002525 C325 C-CERAMIC,CHIP;0.56nF,10% 2203-002525 C105 C-CERAMIC,CHIP;100nF,+80- 2203-005061 C110 C-CERAMIC,CHIP;100nF,+80- 2203-005061 C131...
  • Page 28 Location No. Description SEC CODE Remark C263 C-TA,CHIP;1uF,20%,16V,GP, 2404-001101 C266 C-TA,CHIP;1uF,20%,16V,GP, 2404-001101 C268 C-TA,CHIP;1uF,20%,16V,GP, 2404-001101 L451 INDUCTOR-SMD;120nH,10%,1. 2703-000265 L493 INDUCTOR-SMD;1uH,10%,0.8x 2703-000300 L498 INDUCTOR-SMD;1uH,10%,0.8x 2703-000300 L302 INDUCTOR-SMD;8.2nH,0.3nH, 2703-001955 L301 INDUCTOR-SMD;100nH,5%,1.6 2703-001956 L452 INDUCTOR-SMD;100nH,5%,1.6 2703-001956 L456 INDUCTOR-SMD;3.3nH,0.3nH, 2703-001178 L492 INDUCTOR-SMD;10nH,5%,1x0. 2703-001943 L495 INDUCTOR-SMD;10nH,5%,1x0.

  • Page 29: Block Diagrams

    7. Block Diagrams CDMA Portable PCS Telephone...

  • Page 30: Pcb Diagrams

    SCH-6100/B4 2/17/59 6:45 PM Page 1 8. PCB Diagrams 8-1 Top View CDMA Portable PCS Telephone...
  • Page 31 SCH-6100/B4 2/17/59 6:45 PM Page 2 8-2 Bottom View CDMA Portable PCS Telephone...

  • Page 32: Schematic Diagrams

    SCH-6100/B4 2/16/59 3:09 PM Page 1 9. Schematic Diagrams 9-1 Logic Circuit Diagram CDMA Portable PCS Telephone...
  • Page 33 SCH-6100/B4 2/16/59 3:09 PM Page 2 9-2 Logic Circuit Diagram MENU SCROLL H100 H101 H102 H103 SPK+ BUZZ+ TALK PWR/END SPK- BUZZ- VBAT +3.0VR CN201-2 CN201-1 CDMA Portable PCS Telephone...
  • Page 34 SCH-6100/B4 2/16/59 3:09 PM Page 3 9-3 Transmitter Circuit Diagram VPAA2 VPAA2 VPAA2 +3.1VT T3.6V +3.1VT +3.1VT T3.6V +3.1VT +3.1VT VPAA2 CDMA Portable PCS Telephone...
  • Page 35 SCH-6100/B4 2/16/59 3:09 PM Page 4 9-4 Receiver Circuit Diagram +3.0VR VPAA1 +3.0VR KFF6637 +3.0VR +3.0VR +3.0VR VBAT TCXO_VPA VPAA1 CDMA Portable PCS Telephone...
