- Page 1 PORTABLE CELLULAR TELEPHONE SCH-611 Owner’s Manual ELECTRONICS Printed in Korea Code No. : GH68-00709A Hong Kong China. 8/99. Rev.1.0...
-
Page 2: Table Of Contents
Table of Contents GETTING STARTED Unpacking ... 7 Phone Layout ... 8 Key Functions ... 9 Display ... 10 Icons ... 10 Installing Battery ... 11 To Install the Battery ... 11 To Remove the Battery ... 12 Charging a Battery ... 13 Low Battery Indicator ... - Page 3 CALLS Outgoing ... 30 (MENU 1-1) Incoming ... 31 (MENU 1-2) Erase Logs ... 32 (MENU 1-3) Air Time ... 32 (MENU 1-4) PHONE BOOK Find Name ... 33 (MENU 2-1) My Phone Number ... 34 (MENU 2-2) Add Entry ...
- Page 4 MESSAGES Voicemail ... 52 1-1) Page ... 53 1-2) Text ... 54 1-3) Alert ... 54 1-4) Erase All ... 54 1-5) ACCESSORIES Batteries ... 55 Dual-Slot Desktop Charger ... 55 Cigarette Lighter Adapter ... 55 Ear-Microphone ... 55 USING THE BATTERIES Precautions When Using Batteries ...
-
Page 5: Getting Started
IMPORTANT! Use only accessories approved by the phone manufacturer. This apparatus is intended for use when supplied with power from SAMSUNG approved Travel adapter and Desktop charger. The use of any other types will invalidate any approval or warranty applying to the phone, and may be dangerous. -
Page 6: Phone Book
Phone Layout The following illustrations shows the main elements of your phone. Lamp Strap hole Earphone jack Memo key Volume keys O K / See the opposite M E N U E N D / C L R page S E N D D EF AB C . -
Page 7: Display
Display The display comprises two areas: an upper line of static icons, and the lower text and graphic area. The following icons display at power-on: Icons Shows the received signal strength. The greater the number of bars, the better the signal strength. Indicates that the phone is outside a service area and cannot send or receive calls. -
Page 8: To Remove The Battery
Your phone is powered by a rechargeable Li-ion battery. A travel adapter is provided with your phone. Use only approved batteries and chargers. Ask you local SAMSUNG dealer for further details. The phone can be used while the battery is charging. -
Page 9: Low Battery Indicator
3. When charging is finished, disconnect the adapter from the power outlet. Disconnect the adapter from the phone by pressing the grey tabs on either side of the connector and pulling the connector out. Low Battery Indicator When the battery is weak and only a few minutes of talk time remain, a clear battery icon (no bars displayed) flashes in the upper right corner of the screen. -
Page 10: General Functions
General Functions Making a Call When the idle screen is displayed, key in the area code and phone number and press key. SEND Note: If you have set Auto Retry option (7-1) to On (see page 45) and the call does not connect, the phone automat- ically retries to make the call. -
Page 11: Making A Call From The Phone Book
Making a Call from the Phone Book You can store the phone numbers called regularly in memory, called the Phone Book. You then simply recall the number to dial. For further information on Phone Book, refer to page 33. FINDING ENTRIES BY NAME, THEN DIAL 1. -
Page 12: Last Number Redial
Last Number Redial The phone stores the last 10 numbers dialled. To recall any of these numbers, proceed as follows. 1. If there are any characters on the display, clear the display by holding down the key for more than one second. 2. -
Page 13: Viewing Missed Calls
Viewing Missed Calls If you are unable to answer a call for any reason, you can find out who was calling you, if this service is available. In this way, you can call the person back, if necessary. The number of missed calls is displayed on the idle screen immediately after the call was missed. -
Page 14: Call Forwarding
Call Forwarding This feature provides the option of forwarding incoming calls to another phone number, even while your phone is off. Activating Call Forwarding does not affect outgoing calls made from this phone. Contact your service provider to activate Call Forwarding. Adjusting the Volume During a call, if you want to adjust the earpiece volume, use the volume keys on the left side of the phone. -
Page 15: Using The Menus
Using the Menus A three-level menu structure is available to set the various options available on your phone. You can set the menu options in two different ways. Using the Scroll Keys The following keys are used to set menu option by scrolling then selecting an option. -
Page 16: Menu Map
Menu Map Main Menu Menu Level 1 1. Calls 1: Outgoing 2: Incoming 3: Erase Logs 4: Air Time 2. Phone Book 1: Find Name 2: My Phone # 3: Add Entry 4: Find Entry 3. Sounds 1: Ring 2: Key Volume 3: Alert 4: Alarm 5: Diff. -
Page 17: Outgoing (Menu 1-1)
Calls You can use the CALLS menu to: • View and dial the last outgoing or incoming numbers. • Erase the numbers in the CallLog memory • View the duration of calls. Outgoing The phone stores up to nine outgoing calls you dialed. When you access this menu, the list of outgoing calls are displayed. -
Page 18: Erase Logs (Menu 1-3)
Erase Logs You can erase the numbers stored in the Call Log memory. Outgoing: The numbers you called are erased. Incoming: The numbers you received are erased. All: All calls you dialed and received are erased. Air Time Using this option, you can view the call time of the last call, as well as total air time for all calls since you last reset the timer. -
Page 19: Find Entry (Menu 2-4)
My Phone Number You can check your own phone number. If you have more than one phone number, press key to check the next number. Note: You can block this feature by setting Block Own Number option to ON. Refer to page 50. Add Entry Using this option, you can store a phone number with a name in your Phone Book. -
Page 20: Sounds
Sounds You can use the Sounds feature to customize various sound settings, such as the: • Ring volume, type, and tone • Alert sounds Ring Ring Volume This option allows you to adjust the ringing volume to one of nine levels. You can also turn the ringer off. Use the key on the left side of the phone. -
Page 21: Language Menu
To set the alarm, proceed as follows. 1. Select Set. 2. Choose the alarm frequency option. 3. Enter the required time. 4. Press key. To stop the alarm when it rings, simply open the flip cover or press any key. To deactivate the alarm, select Release. -
Page 22: Voice Memo
Voice Memo You can use the Voice Memo feature to: • Record up to 10 voice memos • Play the recorded voice memos • Erase one or all voice memos Review This option allows you to play back all memos recorded, starting with the most recent memo. -
Page 23: Voice Dial
Voice Dial You can call up to 20 stored entries by speaking the name into the microphone. Before using the Voice Dialing feature, you must record the name in your phone. Record This option allows you to register numbers for subsequent voice dialing. -
Page 24: Auto Hyphen (Menu 7-3)
Erase All This option allows you to delete all voice dialing entries. Press key, when you asked to confirm. Otherwise, press key to exit the function without deleting the END/ voice dialing entries. Set Active Voice Dialing is always active once you have recorded a name and have entered the associated phone number. -
Page 25: Set Time (Menu 7-7)
Tone Length Some phones you call can recognize only longer tones. You may have to change the length to LONG for some calls. When calling a paging system, your phone should be in the SHORT mode. Tone Release Tone: You can set your phone to sound the release tone when a call is released or dropped. -
Page 26: Restrict Menu
Restrict This feature allows you to restrict your calls. Call Restriction can be set up in the following ways. Phone Book: the phone restricts the use of the Phone Book. Incoming: calls cannot be received. Outgoing: calls cannot be made. Each option can be restricted or unrestricted individually. -
Page 27: Reset Phone (Menu 0-0)
NAM Mode The NAM (Number Assignment Module) enables you to subscribe to one or more service networks. The following options are available: Manual NAM: You set the phone to the network you want to use. You can select a NAM from a maximum of 4 NAMs. -
Page 28: Voicemail ( 1-1)
Messages Your phone receives voicemail notification, text messages, and pages. And your phone transmits text messages and pages if your system supplier provides this service. When the phone receives a message, an alert sounds, and a text notification displays. The icon remains on the screen until you read the pending text messages or until you listen to the voicemail notification messages... -
Page 29: Text ( 1-3)
Text An indexed list of text messages displays. An exclamation point next to an entry indicates an urgent message. A check mark next to an entry indicates that you have read and stored the message. Select the desired message to review, then press After reviewing the message, press MENU following options. -
Page 30: Using The Batteries
• If left unused, a fully charged battery will discharge itself over time. Using the Batteries • Use only Samsung-approved batteries and recharge your battery only with Samsung-approved chargers. When a charger is not in use, disconnect it from the power source. -
Page 31: Safety Information
Safety Information Road Safety • Remember, road safety always comes first! • Do not use a hand-held phone while driving a vehicle. Always park the vehicle before having a conversation. • Make sure that the phone is stored safely and will not fall or be broken in the event of a collision or emergency stop. -
Page 32: Care And Maintenance
Care and Maintenance Your phone is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you fulfill the warranty obligations and enjoy this product for many years. • Keep the phone and all its parts and accessories out of the reach of small children. -
Page 33: Glossary Of Terms
Glossary of Terms Airtime - Actual time spent talking on the wireless phone. Most carriers bill customers based on how many minutes of airtime they use each month. Antenna - A device for transmitting or receiving signals. The size and shape of antennas is determined, in part, by the frequency of the signal they receive. - Page 34 Roaming - The ability to use a wireless phone to make and receive calls in places outside of the home service area. Service Charge - The amount paid each month to receive wireless service. Standby Time - The amount of time a fully charged wireless portable or transportable phone can be on and idle without being in use.
-
Page 35: Quick Reference Card
Quick Reference Card Licensed by QUALCOMM Incorporated under one or more of the following Patents. U.S Patent No. 4,901,307 5,056,109 5,099,204 5,101,501 5,103,459 5,107,225 5,109,390...
