features of your new

air conditioner

• Cool Summer Offer
On those hot sweltering summer days and long restless nights, there is no better escape
from the heat than the cool comforts of home. Your new air conditioner brings an end to
exhausting hot summer days and lets you rest. Beat the heat with your own air conditioner
this summer.
• Cost Efficient System
Your new air conditioner not only provides maximum cooling power in the summer, but also
can be an efficient heating method in the winter with the advanced "Heat pump" system.
"Heat pump" system is 3 times more efficient compare to the other electrical heating
appliance, so you can further reduce its running cost. Now, meet year-round needs with one
air conditioner.
• Look for Everywhere
The elegant and harmonious design gives priority to the esthetics of your space and
complements any of your existing interior décor. With its soft color and rounded-edge shape,
the new air conditioner adds class to any room. Enjoy what your air conditioner offers both
functionally and esthetically.
and having sound sleep.
For easy future reference write the model and serial number
down. You can find your model number on the bottom side
of the air conditioner.
02_ features
AQ09R@@ series_IB_E_29893_10.20.08.indd 2
function
function allows you to set a comfortable sleep temperature while saving energy
Model #
Serial #
2008-10-20 9:28:19

Advertisement

Table of Contents
loading

Summary of Contents for Samsung AQ09R Series

  • Page 1: Air Conditioner

    features of your new air conditioner • Cool Summer Offer On those hot sweltering summer days and long restless nights, there is no better escape from the heat than the cool comforts of home. Your new air conditioner brings an end to exhausting hot summer days and lets you rest.
  • Page 2: Safety Information

    Because the following operating instructions cover various models, the characteristics of your air conditioner may differ slightly from those described in this manual. If you have any questions, call your nearest contact center or find help and information online at www.samsung.com. Important safety symbols and precautions: Hazards or unsafe practices that may result in severe personal injury or death.
  • Page 3 safety information SEVERE WARNING SIGNS WARNING Do not place the air conditioner near hazardous substances or equipment that releases free flames to avoid fire, explosions or injuries. • Potential risk of fire hazard or explosion. Do not install the outdoor unit at an unstable place or elevated surface where there is potential risk of falling.
  • Page 4 Make sure that children take precautions against access to the air conditioner and they do not play with the unit. Do not clean the interior of air conditioner on your own. • You may damage the parts which can cause electric shock or fire. •...
  • Page 5 safety information SEVERE WARNING SIGNS (CONT’D) WARNING Use a receptacle that has a ground terminal. The receptacle must be used exclusively for the air conditioner. • Improper electrical grounding may cause electric shock or fire. Be sure to ground the unit. Do not connect the ground wire to gas or water pipes, lighting rods, or telephone grounding lines.
  • Page 6 Do not touch the pipe connected to the air conditioner. Install the indoor unit away from lighting apparatus using the ballast. • If you use the wireless remote control, reception error may occur due to the ballast of the lighting apparatus. Install the outdoor unit where operating noise and vibration will not disturb your neighbor and in a well-ventilated area with no obstacle.
  • Page 7 safety information CAUTION SIGNS (CONT’D) CAUTION Inspect the condition, electric connections, pipes and external case of the air conditioner regularly by a qualified service technician. Do not open doors and windows in the room being cooled during operation unless necessary. Do not block the air conditioner vents.
  • Page 8: Table Of Contents

    contents VIEWING YOUR AIR CONDITIONER 10 Checking the indoor unit and display Main parts Display 11 Opening the front panel Power button and Room temperature sensor 11 Checking the outdoor unit 12 Checking the remote control Remote control display Using the remote control Inserting the batteries OPERATING BASIC FUNCTION 14 Turning the air conditioner on and off...
  • Page 9: Checking The Indoor Unit And Display

    viewing your air conditioner Congratulations on the purchase of the air conditioner. We hope you enjoy the features of your air conditioner and stay cool or warm with optimal efficiency. Please read the user manual to get started and to make the best use of the air conditioner. CHECKING THE INDOOR UNIT AND DISPLAY Carefully unpack your air conditioner and check the indoor unit to make sure it is not damaged.
  • Page 10: Opening The Front Panel

    The room temperature sensor measures indoor room temperature. Make sure room temperature does not get damaged. CAUTION Room temperature sensor Power button CHECKING THE OUTDOOR UNIT AQ09R Series AQ09U Series/AQ12U Series Air Inlet (Rear) Air Inlet (Rear) Connection Valve Connection Valve Air Outlet Air Outlet...
  • Page 11: Checking The Remote Control

    viewing your air conditioner CHECKING THE REMOTE CONTROL You can activate the air conditioner by pointing the remote control away from it. When using the remote control, always point it directly at the air conditioner. Remote control display Turbo Operate in auto fan speed to Power cool/warm quickly.
  • Page 12: Remote Control Display

    Remote control display Operation mode indicator On Timer indicator Set temperature/ indicator time indicator Off Timer indicator Low battery indicator Transmit indicator Fan speed indicator Turbo indicator Auto (Turbo) Smart Saver indicator Medium Air swing indicator High Using the remote control •...
  • Page 13: Turning The Air Conditioner On And Off

    operating basic function TURNING THE AIR CONDITIONER ON AND OFF Press the Power button on the remote control. You will hear a beep and the air flow blade will move up and down automatically when the air conditioner is properly on. The air conditioner will operate in the most recent operation mode used or Auto mode.
  • Page 14: Cool

    Cool In Cool mode, the air conditioner will cool your room. You can adjust the temperature and the fan speed to feel cooler in hot season. 1. Turn on the air conditioner. Press the Power button on the remote control. 2.
  • Page 15: Dry

    operating basic function SELECTING OPERATION MODE The air conditioner in Dry mode acts like a dehumidifier by removing moisture from the indoor air. Dry mode makes the air feel refreshing in a humid climate. 1. Turn on the air conditioner. Press the Power button on the remote control.
  • Page 16: Fan

    Fan mode can be selected to ventilate your room. Fan mode will be helpful to refresh the stale air in your room. 1. Turn on the air conditioner. Press the Power button on the remote control. 2. Set the operating mode. Press the Mode button on the remote control until Fan mode indicator appears on the remote control display.
  • Page 17: Heat

    operating basic function SELECTING OPERATION MODE Heat The air conditioner heats as well as cools. Warm your room with this versatile appliance in the cold of winter. 1. Turn on the air conditioner. Press the Power button on the remote control. 2.
  • Page 18: Adjusting The Air Flow Direction

    ADJUSTING THE AIR FLOW DIRECTION Air flow can be directed to your desired position. Vertical air flow Air flow blades move up and down. 1. Press the Air swing button on the remote control. Air swing indicator will be on and air flow blades move up and down continuously to circulate the air.
  • Page 19: Using The Turbo Function

    using advanced functions USING THE TURBO FUNCTION Turbo function will be helpful to cool or heat your room quickly and effectively by operating at the maximum fan speed for 30 minutes. 1. Turn on the air conditioner. Press the Power button on the remote control.
  • Page 20: Setting Timer

    SETTING TIMER This advanced Timer function allows you to turn on/off your air conditioner automatically even when you are away. Simply set the time and your air conditioner will turn on/off automatically. On Timer This function allows you to turn on the air conditioner automatically within the time range of 24 hours.
  • Page 21: Off Timer

    using advanced functions SETTING TIMER Off Timer This function allows you to turn off the air conditioner automatically within the time range of 24 hours. Off timer is available while your air conditioner is on. 1. Press the Off Timer button on the remote control. Off timer indicator blinks on the remote control display.
  • Page 22: Combining On Timer And Off Timer

    Combining On Timer and Off Timer You can combine the On timer and Off timer together for more convenient use of the timer function. 1. Set the On timer. Press the On Timer button. Set the time with On Timer button. Press Set/Cancel button to activate the On timer.
  • Page 23: Mode

    using advanced functions SETTING TIMER mode mode allows you to set a comfortable sleep temperature while saving energy and having sound sleep. mode can be set up when the air conditioner is on. 1. Set the operating mode. Press the Mode button on the remote control until Cool or Heat appears on the remote control display.
  • Page 24: Temperature Changes In Mode

    Temperature changes in mode To prevent excessive cooling/heating during sleep, the mode automatically modifies the temperature setting in accordance with the time setting. Temperature and air current change according to the three stages; Fall asleep, Sound sleep, and Wake up from mode, and then the air conditioner will automatically turn off when the set time has elapsed.
  • Page 25: Using The Smart Saver Function

    using advanced functions USING THE SMART SAVER FUNCTION This function will set the temperature range limit to help you save energy while the air conditioner is operating in Cool mode. 1. Press the Smart Saver button on the remote control while the air conditioner is operating in Cool mode.
  • Page 26: Cleaning The Exterior

    cleaning and maintaining the air conditioner Make sure the power is turned off and unplugged from the wall socket when cleaning the air conditioner. CAUTION If system contains 3 kg or more of fluorinated greenhouse gases. In this case, it has to be checked for leakage at least once every 12 months, according to regulation n°842/2006.
  • Page 27: Bio Filter (Option)

    cleaning and maintaining the air conditioner Bio filter (Option) Washable foam based Bio filter leads to reduction in allergens that thrive in polluted air. The filter is cleaned with a vacuum or by hand washing. 1. Open the front panel. Tightly grab front side of the front panel and lift up the panel to open.
  • Page 28: Replacing The Filter

    REPLACING THE FILTER Replacement filter may be purchased from the retail store or ordered from the dealer where you purchased the unit. If you cannot find one, please call a contact center. Deodorizing filter (Option) Deodorizing filter absorbs efficiently cigarette smoke, pet odors and other unpleasant smells. Deodorizing filter cleaning is simple, just remove old filter and install a new one.
  • Page 29: Maintaining Your Air Conditioner

    cleaning and maintaining the air conditioner MAINTAINING YOUR AIR CONDITIONER If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best condition. 1. Dry the air conditioner thoroughly by operating in Fan mode for 3 to 4 hours and disconnect the power plug.
  • Page 30: Internal Protections Via The Unit Control System

    Internal protections via the unit control system This internal protection operates if an internal fault occurs in the air conditioner. Type Description The internal fan will be off to against cold air when the heat pump is Against cold air heating.
  • Page 31: Troubleshooting

    appendix TROUBLESHOOTING Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expenses. PROBLEM SOLUTION The air conditioner does • Because of the protective mechanism, the appliance does not start not operate immediately operating immediately to keep the unit from overloading.
  • Page 32: Operation Ranges

    OPERATION RANGES The table below indicates the temperature and humidity ranges the air conditioner can be operated within. Refer to the table for efficient use. OPERATIONAL TEMPERATURE MODE INDOOR HUMIDITY IF OUT OF CONDITIONS INDOOR OUTDOOR Condensation may occur on the indoor unit with risk to have COOLING 16˚C to 32˚C...
  • Page 33 OR VISIT US ONLINE AT BELGIUM 02 201 2418 www.samsung.com/be 800-SAMSUNG (800-726786) Distributor pro Českou republiku: CZECH REPUBLIC www.samsung.com/cz Samsung Zrt., česká organizační složka, Oasis Florenc, Sokolovská394/17, 180 00, Praha 8 DENMARK 8-SAMSUNG (7267864) www.samsung.com/dk FINLAND 30-6227 515 www.samsung.com/fi 3260 SAMSUNG (7267864, €0,15/Min) FRANCE www.samsung.com/fr...
  • Page 34: User Manual

    AQ09R Series AQ09U Series AQ12U Series AQ18U Series AQ24U Series Air Conditioner user manual imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/global/register AQ09R@@ series_IB_E_29893_10.20.08.indd 35 2008-10-20 9:29:41...

This manual is also suitable for:

Aq18u seriesAq24u seriesAq12u series

Table of Contents
