Frymaster Electric Cooker 8BC Specifications

Frymaster
™
8SMS Spaghetti
Magic® System
Models
8SMS
Shown with optional casters

Specifications

The 8SMS Spaghetti Magic® incorporates all the
features the industry has been looking for in a
pasta cooker. Electronic, programmable controls
make it easy to turn 6 lbs. (3 kg) of dry pasta
into 15 lbs. (7 kg) of cooked pasta (1,080 10 oz.
servings per hour), exactly as desired every time
and do it all automatically and reliably. The 8SMS
features Frymaster's exclusive smooth-surfaced,
easy-clean, touch-pad timer/controller.
The unit delivers 8 kW of power, meaning faster
preheat and recovery performance, which saves
time and allows the operator to turn pasta orders
faster. The system is safeguarded against boil-
over by a 1-1/4" (32 mm) overflow drain. This
drain carries away any excess water that might
be added to the cookpot and starch that might
accumulate with repeated cooks.
Another labor-saver and performance feature is
a large 1-1/4" (32 mm) drain, which reduces the
time needed to drain the system and virtually
eliminates the chance of clogs, which is common
in pasta cookers with smaller drain openings.
8700 Line Avenue Tel: 318-865-1711
Shreveport, LA 71106-6800 Tel: 1-800-221-4583
USA Fax: 318-868-5987
E-mail: info@frymaster.com
®
8BC

Standard Features

• 8 kW incoloy heating element -- faster
preheat & recovery performance
• Swing away hot/cold rinse faucet
• Electronic Timer/Controller
• Autofill sensor
• Push-button skimmer
• Solid-state thermostat
• Stainless steel cookpot, enamel cabinet
• 1-1/4" (32 mm) drain valve
• Overflow drain
• 6" adjustable legs
• Bulk pasta basket
• Portion cup rack with 24 (10 oz.) cups
Frymaster's automatic basket lift feature delivers
precise cook times without constant monitoring.
The skim feature keeps the water surface free
from excessive starch residue within the cookpot
with the push of a button. Water sprayed from
jets moves the starch across the surface water to
the overflow drain. The starch skim feature elimi-
nates lost cooking time draining the cookpot.
The autofill sensor keeps cooking water at the
desired level by replacing water which is evapo-
rated away during the cooking process. It also
saves energy since there is no need to reheat a
refilled cookpot.
All the many features of Frymaster's pasta cooker
make it the most advanced, most automatic,
most reliable cooker on the market today; and
because it's electric, it can be installed without
hood venting in many markets.
8C
www.frymaster.com
Bulletin No. 818-0137 9/08
Project
Item
Quantity
CSI Section 11400
Approval
Date
Options &
Accessories
Casters
Stainless steel cabinet
Round pasta baskets
Rack support
Rinse tank screen
