Troubleshooting

Problem Potential Reasons
No picture Power isn't connected
The power switch is not on
Screen shows Not connect DVB-T cabl
No Signal
Incorrect setting
No sound from No or incorrect connection
speaker with audio cable
Mute the sound
Incorrect sound track
Only sound, No or incorrect connection
no image on the with AV cable
screen
The program is a radio
program

Remote control

The battery is exhausted
unit is not workable
Remote control unit is not
in the right opposite of the
front panel or too far from it
The image stop The signal is too weak
suddenly or mosaic

Technical Specifications

What to do Item
Connect the power
Tuner
Switch on the power
Plug in the DVB-T cable
Set up correct parameter
Connect the audio cable
correctly
Video
Switch on the correct
volume control
Try another sound track
Connect the audio cable
Audio
correctly
Press <TV/RADIO> key to
shift into TV mode
Power
Change new battery
Adjust the way of holding
remote control unit and
near from the panel
After the implementation of the European Directive 2002/96/EU in the national legal
system, the following applies: Electrical and electronic devices may not be disposed
of with domestic waste. Consumers are obliged by law to return electrical and
Strengthen the signal electronic devices at the end of their service lives to the public collecting points set
up for this purpose or point of sale. Details to this are defined by the national law of
the respective country. This symbol on the product, the instruction manual or the
package indicates that a product is subject to these regulations. By recycling,
reusing the materials or other forms of utilizing old devices, you are making an
important contribution to protecting our environment.
Sub Item Parameter
Input Frequency 170~230MHz
470~860MHz
RF Input level
-25~-78dBm
IF Bandwidth 7MHz and 8MHz
Modulation QPSK,16QAM,64QAM
MPEG4 AVC/H.264 HP@L4
Decoder Format
MPEG2 MP@ML.HL
Output Format
576P , 720P , 1080i,1080p,
4:3 and 16:9
Output Port
HDMI, Dual SCART
Decoder Format MPEG-1 (layer1&2)
Audio output Digital audio: S/PDIF
Voltage
100-240V~ 50/60Hz
Power Max 6W
