Options - Icom IC-F44GS Instruction Manual

D BATTERY PACK
Battery pack Voltage Capacity
BP-230 7.4 V 800 mAh
7.4 V 1150 mAh
BP-231
7.4 V 2000 mAh
BP-232
* Operating periods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
D CHARGERS
•BC-119N
DESKTOP CHARGER
+ BC-145
AC ADAPTER
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions. Charging
time: approx. 2 hours when BP-231 is attached.
•BC-121N - + AD-106
MULTI CHARGER
+ BC-124
AC ADAPTER
For rapid charging of up to 6 battery packs (six AD-106's are
required) simultaneously. An AC adapter should be pur-
chased separately. Charging time: approx. 2 hours when
BP-231 is attached.
•BC-160 + BC-145
DESKTOP CHARGER
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions. Charging
time: approx. 2 hours when BP-231 is attached.
Battery life*
6 hrs.
IC-F34GT/GS 9 hrs.
IC-F44GT/GS 8 hrs.
16 hrs.
+ AD-106
CHARGER ADAPTER
(6 pcs.)
CHARGER ADAPTER
AC ADAPTER

OPTIONS

D BELT CLIPS
• MB-93
SWIVEL BELT CLIP
• MB-94
BELT CLIP
Exclusive alligator-type belt clip. The same as supplied with
the transceiver.
• MB-96N/96F
LEATHER BELT HANGER
D OPTIONAL UNITS
• UT-108
DTMF DECODER UNIT
Provides pager and code squelch capabilities.
• UT-109 (#02)/UT-110 (#02)
Non-rolling type (UT-109)/Rolling type (UT-110) voice
scrambler unit provides higher communication security.
• UT-113
MAN DOWN UNIT
Provides a measure of safety when working in a hazardous
environment, etc.
• UT-105
SmarTrunk II™
LOGIC BOARD
Provides SmarTrunk II™ capabilities.
• UT-117/117S*
SmarTrunk 3G™
Provides SmarTrunk 3G™ capabilities.
*In addition to SmarTrunk 3G™ capabilities, UT-117S sup-
ports the voice scrambler capability.
9
SCRAMBLER UNITS
LOGIC BOARD
39
