MICROWAVE OVEN
OPERATING INSTRUCTIONS
Before operating this oven, please read these instructions completely.
KOR-619Q
Model No.:
STAGE
1
LOCK
Popcorn
Baked
Potato
Fresh
Vegetable
Speedy cook
Auto Def.
1
4
7
Power
Stop/Clear
DEFROST
AUTO
2
WEIGHT
TIME
START
g
NO
CUPS
Muffin
Soup
Frozen
Dinner
Pizza
Plate
Feeding
Beverage
Bottle
+
2
3
5
6
8
9
0
Clock/A.Start
Start
Advertisement
Table of Contents
Related Manuals for Daewoo KOR-619Q
Summary of Contents for Daewoo KOR-619Q
-
Page 1: Microwave Oven
MICROWAVE OVEN OPERATING INSTRUCTIONS KOR-619Q Model No.: STAGE DEFROST AUTO WEIGHT TIME START LOCK CUPS Popcorn Muffin Soup Baked Frozen Dinner Potato Pizza Plate Fresh Feeding Beverage Vegetable Bottle Speedy cook Auto Def. Power Clock/A.Start Stop/Clear Start Before operating this oven, please read these instructions completely. -
Page 2: Table Of Contents
PRECAUTIONS TO AVOIDE POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. (b) Do not place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces. -
Page 3: Earthing Instructions
EARTHING INSTRUCTIONS This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a earthing wire with a earthing plug. The plug must be plugged into an outlet that is properly installed and earthed. -
Page 4: Specifications
SPECIFICATIONS POWER SUPPLY 230V ~50Hz, SINGLE PHASE WITH EARTHING MICROWAVE POWER CONSUMPTION 1200 W OUTPUT POWER 800 W(IEC 705) FREQUENCY 2450 MHz OUTSIDE DIMENSIONS (W X H X D) 465 X 274 X 352 mm CAVITY DIMENSIONS (W X H X D) 290 X 200 X 290 mm NET WEIGHT APPROX. -
Page 5: Safety Instructions For General Use
SAFETY INSTRUCTIONS FOR GENERAL USE isted below are, as with all appliances, certain rules to follow and safeguards to assure top performance from this oven: 1. Do not use the oven for any reason other than food preparation, such as for drying clothes, paper, or any other nonfood items or for sterilizing purposes. -
Page 6: Features Diagram
FEATURES DIAGRAM STAGE AUTO DEFROST WEIGHT TIME START LOCK CUPS STAGE DEFROST AUTO WEIGHT TIME START LOCK CUPS Popcorn Muffin Popcorn Soup Muffin Soup Baked Frozen Dinner Potato Pizza Plate Fresh Feeding Beverage Vegetable Bottle Baked Frozen Dinner Speedy cook Potato Pizza Plate... -
Page 7: Operation Procedure
OPERATION PROCEDURE This section includes useful information about oven operation. 1. Plug power supply cord into a 230V 50Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. -
Page 8: Controls
CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash ":0" and a tone will sound. If the AC power ever goes off, the display will flash ":0" when the power comes back on. DO THIS... THIS HAPPENS... -
Page 9: Weight Defrosting
WEIGHT DEFROSTING WEIGHT DEFROST lets you easily defrost food by eliminating guesswork in determining defrosting time. The minimum weight for WEIGHT DEFROST is 200 grams. The maximum weight for WEIGHT DEFROST is 3000 grams. Follow the steps below for easy defrosting. DO THIS... -
Page 10: Time Defrosting
TIME DEFROSTING When TIME DEFROST is selected, the automatic cycle divides the defrosting time into periods of alternating defrost and stand times by cycling on and off. DO THIS... THIS HAPPENS... The WEIGHT DEFROST AUTO STAGE DEFROST AUTO indicator lights and "0" is DEFROST START WEIGHT... -
Page 11: Cooking In One Stage
COOKING IN ONE STAGE DO THIS... THIS HAPPENS... The STAGE 1 indicator lights POWER STAGE DEFROST AUTO and "P- " is displayed. START WEIGHT TIME 1. Touch POWER pad. LOCK CUPS The display will show what you STAGE DEFROST AUTO touched. -
Page 12: Cooking In Two Stages
COOKING IN TWO STAGES For best results, some recipes call for one Power Level for a certain length of time and another power level for a different length of time. Your microwave oven can be set to change from one to another. DO THIS... -
Page 13: Weight Defrosting And Cooking In Two Stages
WEIGHT DEFROSTING AND COOKING IN TWO STAGES Some recipes require frozen foods to be thawed before cooking. This oven can be programmed to automatically defrost foods before cooking. DO THIS... THIS HAPPENS... The WEIGHT DEFROST AUTO STAGE DEFROST AUTO START indicator lights and "0"... - Page 14 DO THIS... THIS HAPPENS... The STAGE2 indicator lights and POWER STAGE DEFROST "P-" is displayed. AUTO START WEIGHT TIME 6. Touch POWER pad. LOCK CUPS The display will show what you STAGE DEFROST touched. AUTO START WEIGHT TIME 7. Touch the number pads for the power level you want in the second stage.
-
Page 15: Auto Start
AUTO START Allows you to program cooking to start at a time you select. The food will automatically start cooking at the desired time. Program is able up to 2 stages (not acceptable DEFROST) DO THIS... THIS HAPPENS... 1. Program the desired power level and cooking time. The AUTO START indicator CLOCK/ STAGE... -
Page 16: To Check Auto Start Time
TO CHECK AUTO START TIME Once you have correctly programmed the oven for AUTO START, the present time will appear on the display. DO THIS... THIS HAPPENS... The programmed AUTO START CLOCK/ time will appear on the display A.START for 3 seconds. 1. -
Page 17: One Touch Cooking
ONE TOUCH COOKING One touch cook allows you to cook or reheat many of your favorite foods by touching just one pad. To increase quantity, touch chosen pad until number in display is same as desired quantity to cook. (except for MUFFIN & DINNER PLATE) DO THIS... - Page 18 * FROZEN PIZZA * • 200g: Touch FROZEN PIZZA once. • 300g: Touch FROZEN PIZZA twice within 1.5 seconds. NOTE: 1. Use only one frozen pizza at a time. 2. Use only frozen pizza for microwave oven. 3. If the cheese of frozen pizza does not melt sufficiently, cook a few seconds longer.
- Page 19 DO THIS... THIS HAPPENS... When you touch DINNER PLATE DINNER STAGE DEFROST AUTO pad, "300" is displayed. START PLATE WEIGHT TIME After the 1.5 seconds, the display changed into cooking time of 1. Touch DINNER quantity and the oven starts PLATE pad.
- Page 20 DO THIS... THIS HAPPENS... When you touch FRESH FRESH STAGE DEFROST AUTO VEGETABLE pad, "200" is VEGETABLE START WEIGHT TIME displayed. After the 1.5 seconds, the display 1. Touch FRESH changed into cooking time of VEGETABLE pad. quantity and the oven starts cooking.
-
Page 21: Feeding Bottle
FEEDING BOTTLE This is the key of sterilizing feeding bottle function. At first, detach the nipple from the bottle and pour the 50cc water into each bottle, arrange the bottle symmetrically on the glass tray and operate. DO THIS... THIS HAPPENS... When you touch FEEDING FEEDING STAGE... -
Page 22: Cooking Utensils
COOKING UTENSILS Microwave energy is produced by high frquency radio waves. They are reflected from metal, but will pass through most cooking utensils without heating them. As the waves come into contact with the food, they are converted into heat energy. Listed below are the suggested cooking utensils for this microwave oven and when to use them. -
Page 23: Before You Call For Service
BEFORE YOU CALL FOR SERVICE Refer to following checklist, you may prevent an unnecessary service call. * The oven doesn't work; 1. Check that the power cord is securely plugged in. 2. Check that the door firmly closed. 3. Check that the cooking time is set. 4.
