Code Identification Chart

Enter your code here for easy reference.
TV CODE AUX 1
VCR CODE AUX 2
SAT • CBL CODE
DVD CODE

Learning

Learning Tips

Before transferring commands from your original remote to the RCU807,
check out these useful tips on Learning.
1. Make sure you are using fresh batteries in both the RCU807 and
your original remote(s).
2. It is recommended that you clear all Learned commands under all
component modes before attempting any Learning. (See section on
Clear all Stored Learned Commands Under a Component Mode.)
3. Point the top of the original remote at the base of the RCU807 so the
IR LED on the original remote is in line with the RCU807 Learn sensor,
located at the bottom of the remote.
4. The distance between the two remotes should be approximately
2-3 inches apart.
5. To ensure that your units are compatible and to increase your
familiarity with the Learning process, you may wish to experiment
by learning two or three keys initially. Then, carry out a Clear all
Stored Learned Commands Under a Component Mode operation
before learning all the desired functions from your original remote.
6. Incandescent or low-energy light can cause interference with the
IR transmissions. When using the Learning function, keep the
remotes at least three feet away from such light sources.
7. When learning a key, do not release the key on your original remote
until the Success Screen is displayed on the RCU807 status display,
which takes approximately 2-3 seconds. Until this occurs, the LCD
will display the Learn Screen.
8. Any key on your RCU807 can be programmed with Learned
commands, with the exception of the MACRO (M), SETUP (S),
INPUT or any component key. In addition, the L1, L2
and L3 keys are generic keys to be programmed as you wish.
9. If there is a problem during the Learning process, the Learn Error
Screen appears in the display. The unit still remains in Learning Mode.
10. All Learned keys are saved automatically.
11. When the memory is full, the display shows the Full Screen.
It is not possible to learn any additional keys without first clearing
Learned commands under a component mode.
8
10:18 Page 8
AUDIO
device:______
Tuner Tape
AMP
CD CODE
device:______
