(22) Display of information about port Access Control (PORT mode)
If the -ap option is specified, the system displays information about the Access Control (PORT mode) of a
specified port.
#iSMview -ap Storage001 00-00
--- Port Information ---
Port No.(h) : 00-00
Port Name : 10000000000000130100
Port State : ready
Port Mode : port
--- Port/LD List ---
LDN(h) OS Type
0000 WN
0001 WN
The display items are as follows:
(1) Port Information
Displays information about the Access Control (PORT mode) of the specified port.
Port No.(h): Port number
Port Name: Port name
Port State: Port state
Port Mode: Port mode
* Refer to 3.3 "Nickname Setting" for details on the setting of Port Name.
(2) Port/LD List
Lists LD information about the Access Control (PORT mode) of the specified port.
LDN(h): Logical disk number
OS Type: OS type of each LD
For details, refer to (3) "List of logical disk information".
LD Name: Arbitrary ID information (logical disk name) of each LD, which is obtained from the disk array
* This option is displayed for only the disk arrays of the 1100/1200/2100/2200/3100/4100 series.
* A port number or port name can be specified for a port.
* A 1-digit (0-0) can be specified as a port number.
* If a specified port does not exist, the error message as shown below is displayed.
iSM11175:Port doesn't exist.
LD Name
Win0000
Win0001
