Tripp Lite SMART2200RM2UN Features And Specifications

Model #: SMART2200RM2UN
SmartPro 2.2kVA 1.92kW Line Interactive Sine Wave UPS, Pre-installed SNMPWEBCARD, 2U, LCD, USB,
Serial, EPO, 120V
Description
Tripp Lite SmartPro Line Interactive UPS with enhanced LCD interface offers network-grade power protection for critical server, network and
telecommunications equipment. Line Interactive Uninterruptible Power Supply (UPS) with built-in Auto-Voltage Regulation (AVR) actively corrects
brownouts and overvoltages back to usable levels while maintaining a full battery charge in case of power failure. Tripp Lite's unique configuration
excels in exceptionally poor-power environments with two separate levels of voltage boost to correct both slight undervoltages and severe brownout
conditions. Interactive LCD interface reports UPS operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and
configuration options. Super-fast switchover from line to battery power occurs within milliseconds to maintain operation of connected equipment
without interruption or reboot. 96% line-mode efficiency offers reduced heat emissions and operating costs. Network management interfaces support
communications via USB, RS-232 and Pre-installed SNMPWEBCARD network interface. HID-compliant USB interface enables integration with
built-in power management and auto shutdown features of Windows and Mac OS X. Network communications ports enable detailed monitoring of
equipment load levels, self-test data and utility power conditions. Includes PowerAlert monitoring software and complete cabling. Switched output
load banks enable scheduled and real-time remote reboot and load shedding of select outlets. Emergency Power Off (EPO) interface. LCD display
panel easily rotates for viewing in rackmount or tower configurations. Audible alarm with push-button momentary alarm-cancel and silent-mode
configuration options. Programmable self-test. Field-replaceable, hot-swappable battery modules.
Applications
Ideal for server, networking and telecommunications equipment
Package Includes
SMART2200RM2UN UPS system with Pre-installed SNMPWEBCARD
PowerAlert Software with USB, Serial & EPO cabling
4 post rackmount installation kit
Instruction manual
Features
Tripp Lite SMART2200RM2UN line interactive 2U rack/tower UPS with 2200VA / 2.2kVA / 1920W capacity
Line interactive UPS with Automatic Voltage Regulation (AVR) corrects brownouts and overvoltages from 83 to 145V
NEMA 5-20P input plug; 4 NEMA 5-15R & 4 NEMA 5-15/20R output receptacles, Two independently switchable output load banks
Maintains uninterrupted operation of connected networking equipment during blackouts, surges, brownouts and overvoltages
High 96% efficiency rating in line-power mode offers reduced power consumption and BTU emisssions
Internal batteries offer 12 minutes at 50% load (960W) and 4.5 minutes at 100% load (1920W)
Hot-swappable, user-replaceable internal batteries can be replaced with no disruption to connected equipment
Front panel LCD monitoring screen with MODE and ENTER buttons reports operating mode with 5-bar battery charge graphic, plus 7
selectable screens of detailed UPS and site power information
LCD interface also supports a number of advanced user setup and operating preferences
Ships with 4 post rackmount installation hardware; Optional 2POSTRMKITWM enables 2 post rackmount/wallmount installation; Optional
Highlights
2.2kVA / 2200VA / 1920W line interactive 2U rack/tower UPS; 0.87 power
factor
120V nominal output during brownouts to 83V and overvoltages to 145V
Interactive LCD provides UPS status information and advanced configuration
options
Hot-swap batteries, 96% efficiency, Sine wave output
USB, RS232 & EPO ports, Pre-installed SNMPWEBCARD interface
2 independently switchable output load banks
NEMA 5-20P input; 4 NEMA 5-15R & 4 5-15/20R outlets
