Tripp Lite SMART2200NET Specification Sheet

Model #: SMART2200NET
SmartPro 2.2kVA Line Interactive UPS, Serial, 120V
Description
Tripp Lite's SMART 2200NET intelligent, line interactive large tower UPS system protects servers, networking accessories and telecommunications
equipment from blackouts, voltage fluctuations and transient surges. Large internal batteries offer 27 minutes half load runtime and 11 minutes fully
loaded. Runtime is expandable with optional BP24V28-2U (limit 1) and BP24V70-3U external battery packs. 2200VA/1700 watt power handling
capability supports a variety of networking, telecom and other sensitive electronic applications. Includes 6 protected outlets. Supports remote
monitoring of UPS and site power conditions via built-in RS-232 enabled monitoring port, plus standard UPS monitoring via 2 built in contact closure
ports. Includes PowerAlert UPS monitoring and unattended shutdown software with complete cabling. Built-in audible alarm and front panel LEDs
indicate line power, battery power, battery charge level, load level, plus voltage regulation status. Network grade AC surge suppression protects
equipment from damage and performance problems resulting from transient surges.
Package Includes
SMART 2200NET UPS System
PowerAlert Software and three 6 foot network cables
Instruction manual
Features
SMART 2200NET line interactive UPS offers battery derived AC output during power outages, voltage regulation during brownouts and
overvoltages, plus network-grade AC surge suppression
2200VA/1700 watt power handling capability supports a variety of networking, telecom and other sensitive electronic devices
Large internal batteries offer runtimes of 27 minutes at half load (1100VA/850 watts) and 11 minutes at full load (2200VA/1700 watts)
Runtime is further expandable with optional external BP24V28-2U (limit 1) and BP24V70-3U (multi-pack compatible) battery packs
Automatic Voltage Regulation (AVR) circuits maintain 120V nominal output over an input voltage range of 87-140V
Includes 6 fully protected NEMA 5-15R outlets with 2 single outlet load banks that can be individually powered off and back on again via
software interface
PowerAlert UPS monitoring and unattended shutdown software enables configurable network broadcast messaging, email notification,
event logging and running user defined script commands
Offers simultaneous monitoring of up to 3 directly connected devices through included DB9 contact closure and RS-232 enabled interfaces,
or the monitoring of any number of additional servers over IP with included PowerAlert monitoring software
In addition to the contact closure monitoring of on battery, low battery and power restored messaging, built-in RS-232 interface supports
messaging of UPS and line power status, including AC line voltage, DC battery voltage and remaining battery capacity
Supports activate self-test and UPS output power control for delayed or immediate reboot of connected equipment
Diagnostic LEDs (indicate 17 performance conditions)
Specifications
Highlights
2.2kVA / 2200VA line interactive, extended-run tower UPS
120V output, Corrects brownouts and overvoltages from 87V to 140V
3 DB9 communication ports (1 RS232 / 2 contact-closure)
Front panel status LEDs with load and battery capacity display
2 independently switchable output load banks
NEMA 5-15P input, 6 NEMA 5-15R outlets
