Tripp Lite SMART2200VS Specification Sheet

Model #: SMART2200VS
SmartPro 2.2kVA Line Interactive UPS, SNMPWEBCARD option, Tower, USB, Serial, 120V
Description
Tripp Lite's SMART 2200VS intelligent, line interactive UPS protects server, networking and telecommunications equipment from blackouts, voltage
fluctuations and transient surges. Small footprint, tower UPS system occupies only 106 square inches of floor space with a height of only 14.25
inches. Large capacity 2200 VA/ 1600 watt rated UPS system offers 7 minutes runtime at full load and 19 minutes at half load during power failures.
Line interactive voltage regulation corrects brownouts as low as 79V and overvoltages as high as 147V to fully regulated 120V nominal output for
smooth continuous operation of connected equipment. Includes a total of 9 outlets, 3 pairs of which can be individually powered off and back on via
software interface to selectively reboot remote equipment or shed less critical loads to extend battery runtime for more critical loads. Includes slot for
internal SNMPWEBCARD, plus 2 DB9 and 2 USB enhanced monitoring ports for unattended shutdown, remote control and monitoring of UPS
system and power data. Ships in attractive gray color scheme. Compatible with Tripp Lite's PowerAlert and Watchdog service software.
Package Includes
SMART 2200VS UPS System, PowerAlert Software and cabling, Instruction manual
Features
2200VA/1600 watt output capacity accommodates a variety of server, networking and telecom devices
High power density 2.2kVA UPS system occupies only 106 square inches of floor space with a height of only 14.25 inches
Compatible with North American 120V/60 Hz power as found in the USA, Canada and Mexico
Offers 7 minutes runtime with a full load of 2200VA and 19 minutes with a half load of 1100VA
Line interactive voltage regulation corrects severe brownouts and overvoltages from 79 to 147v back to normal 120v levels without using
battery power
9 total outlets (7 NEMA5-15R; 2 NEMA5-15/20R)
Includes NEMA 5-20 straight blade 20 amp input plug connection
Notification of system status via 5 LEDs and multi-function audible alarms
Included PowerAlert Software provides e-mail notification of power problems and the simultaneous automatic unattended shutdown of
multiple servers
4 built-in communications ports (2-DB9, 2-USB) for remote monitoring and unattended shutdown
Slot for SNMP/web card (part#: SNMPWEBCARD) and environmental sensor (part#: ENVIROSENSE) for remote communications in large
IP environments
Supports Tripp Lite's WatchDog software application to restore unresponsive programs by automatically restarting them and rebooting
completely locked computers by automatically switching UPS power off and back on again
Communication ports support on battery, low battery, power restored, AC line voltage, DC battery voltage, load percentage, battery charge
current, battery capacity, internal UPS temperature and line frequency status messaging. Interface supports timed inverter shutoff after
unattended shutdown, activate self-test and 10 second reboot of connected equipment
3 pairs of customized load management receptacles can be individually powered off and back on again via software interface to reboot
remote equipment or shed less critical loads to extend battery runtime for the most critical equipment
Highlights
2.2kVA / 2200VA line interactive tower UPS system
120V nominal output during brownouts to 79V and overvoltages to 147V
Front panel status LEDs with load and battery capacity level display
USB, RS232, EPO and optional SNMP/Web card are available for
simultaneous use
NEMA 5-20P input; 2 NEMA 5-15/20R & 7 5-15R outlets
