ZyXEL Communications EXT-118 Quick Sales Manual

Wireless Service Gateway Series
Model Name
VSG-1200v2 G-4100v2
Main Design
Wireless Technology N/A 802.11g
Number of 10/100M LAN/Switch 1 4
WAN 1 1
PoE Yes
PoE Power Draw 6 W
WLAN Features (G-4100 v2 only)
802.11b/g Yes
Number of Antenna 2
Maximum Throughput 22 ~ 24 Mbps
WEP Yes
WPA (Wi-Fi Certified)
Yes
WPA2 (Wi-Fi Certified) Yes
Others Features
Built-in Authentication Yes Yes
RADIUS Authentication Support Yes Yes
IP Plug-and-play Yes Yes
Layer-2 Isolation Yes Yes
Customization Log-in Page Yes Yes
Max. Concurrent User 250 100
PMS Integration Yes
Ticket Printer-SP300E - Button x 3
- Input: 5 V DC, 2.5 A
- Paper Width: 58 (+0/-1) mm
- Paper length (max.): 50 meters
- Support 802.3af Power over Ethernet
Accessories
Antenna
Model EXT-108 EXT-109 EXT-114 EXT-118 ANT2206
Product
Frequency Band 2400 ~ 2500 MHz 2400 ~ 2500 MHz 2400 ~ 2500 MHz 2400 ~ 2500 MHz 2400 ~ 2500 MHz
Gain1 8 dBi 9 dBi (peak) 14 dBi 18 dBi
VSWR 2.0:1 Max 1.5:1 Max 1.5:1 Max 1.5:1 Max 2.0:1 Max
Polarization Linear, vertical Linear, vertical Linear, vertical Linear, vertical Linear, vertical
HPBW/
360° 65° 30° 15°
Horizontal
HPBW/Vertical
15° 60° 30° 5°
Front to Back
N/A 15 dB 15 dB 26 dB
Ratio
Impedance 50 Ω 50 Ω 50 Ω 50 Ω
Connector N type jack N type jack N type female N type female RP SMA Plug
Survival Wind
216 km/hr 216 km/hr 216 km/hr 180 km/hr
Speed
Temperature -40°C to 80°C -40°C to 80°C -40°C to 80°C -40°C to 80°C -10°C to 55°C
Humidity 95% at 25°C 95% at 55°C 95% at 55°C 95% at 55°C 95% at 55°C
Radome Color Gray-white Gray-white White White White, Black
Radome
Fiber glass ABS ABS, UV resistant ABS, UV resistant ABS, UV resist
Material
Weight 337 g 107 g 407 g 1.6 kg
Dimensions f 19 x 250 mm 114 x 114 x 40 mm 200 x 200 x 50 mm 360 x 360 x 16 mm 76 x 86 x 118 mm
Cable
Cable Kit for
Product LMR 200 LMR 400 EXT-300
Outdoor AP
Product
Specifications RP-SMA plug to N-plug to N-plug RJ-45 CAT 5e STB Jumper Cable &
N-plug Cable w/ Water- Surge Arrstor
Proof cover 15 m
Others
Ceiling NWA3550
Product PSE Kits
Mounting Kit Mounting Kit
Product
Specifications For NWA-3160, For NWA3550 - Input: AC 100 V to AC 240 V
NWA-3163,
- Output:
NWA-3165, NWA-
48 Vdc/350 mA (IEEE 802.3af
3500
compliant)
48 Vdc/500 mA
24 Vdc/800 mA
18 Vdc/1 A
- Operation Temperature -40°C to 85°C
- Storage Temperature -10°C to 70°C
- Operation Humidity 5% to 90%
F o r m o r e p r o d u c t i n f o r m a t i o n , v i s i t u s o n t h e w e b a t w w w . Z y X E L . c o m
Copyright © 2009 ZyXEL Communications Corp. All rights reserved. ZyXEL, ZyXEL logo are registered trademarks of ZyXEL Communications Corp. All other brands,
product names, or trademarks mentioned are the property of their respective owners. All specifications are subject to change without notice.
ANT3108 ANT3218
2400 ~ 2500 MHz 2400 ~ 2500 MHz
6 dBi 8 dBi 8 dBi
2.0:1 Max 2.0:1 Max
Linear, vertical Linear, vertical
65° 50° 360°
75° 50° 20°
12 dB N/A 25dB
50 Ω 50 Ω 50 Ω
N type female N type Jack
216 km/hr 216 km/hr
-40°C to 80°C -40°C to 80°C
95% at 55°C 95% at 55°C
White Gray-white
ABS, UV resist ABS, UV resist
110 g 206 g 640 g
f 20 x 260 mm 210 x 210 x 73 mm
ZyXEL
Wireless LAN
Quick Sales Guide
2009
65-100-000042B 02/09
