  • Page 1 Operating Manual For Easy Clicker UR3-SR3 Universal Remote Control, Inc. www.universalremote.com...

  • Page 3: Replacing Batteries

    Introduction This remote control is designed to operate most Digital and Analog Cable Boxes, as well as TVs, and a VCR or DVD player. Replacing Batteries Before you program or operate the remote control, you must install two new AAA alkaline batteries. STEP1 Remove the battery compartment cover from the back of your remote control.

  • Page 4: Quick Set-Up Method

    Button Functions Programming the Remote Control. *Note : In this section, when you are instructed to press a [DEVICE] button, that means you should press either the CBL, TV, or DVD button, depending on which device you are programming the remote to operate. A.
  • Page 5 Continue to hold the [DEVICE] key and press the number key assigned to your brand in the Quick Set-up Code Table. The component should turn off as soon as the number key is pressed. (If it does not turn off, release the [DEVICE] key and use the Pre- Programmed 3-Digit code Method or Scanning Method.) STEP4...

  • Page 6: Manual Programming

    Manufacturer/Brand Quick Number HITACHI SONY PHILIPS SAMSUNG PHILIPS MAGNAVOX PANASONIC DENON PIONEER C. Manual Programming C. Manual Programming The remote control can be programmed by entering a three- digit code number that corresponds to particular brands and models of equipment. The three-digit code numbers are listed in the code tables sections of this instruction manual.

  • Page 7: Auto Search Method

    blink twice to confirm that the code has been stored. *Note : Try all the functions on the remote control. If any of the functions do not operate as they should, repeat the instructions from Step 2 using the next three-digit code number from the same brand list.
  • Page 8 The next step must be performed while the LED is on. STEP2 Press the [INFO] button. The device LED will blink a number of times indicating the number of each digit for the code. Each digit is separated by a one second interval of the LED being off.
  • Page 9 enter the code for the next channel (for example, 050), then press the [STOP] button. Repeat this process for the third channel. The [CBL] button will blink once for each channel entered. STEP4 Press the [CH5] button to store the channels that were selected.

  • Page 10: Low Battery Warning

    operate your Cable Box, press the [CBL] button in Step3. Assigning the Channel keys to a Different Assigning the Channel keys to a Different Device Device By default, the CH+, CH-, NUMERIC and LAST keys operate through your Cable Box. If you would like those keys to operate those functions on a different device, follow these steps.
  • Page 11 Set-up Code Tables CABLE TV CONVERTER CODE No MAKER(BRAND) NAME CISCO/SA EXPLORER Series 001 007 8600X 8600 8540,8570,8590 8500 IPN Series MOTOROLA DCT Series (DVR Model) VIP Series GENERAL INSTRUMENT DCT Series,DCH Series, CFT2200 DL4,DQNV/DRX,DPBB,DPV/DP/DQN,DRZ JERROLD BMC9012/BMC9022 DSR470 CFT2000 DL4,DP(V),DQN(V),DPBB Some Model DL4,DQNV/DRX,DPBB,DPV/DP/DQN,DRZ ADB Series...
  • Page 12 CABLE TV CONVERTER CODE No MAKER(BRAND) NAME MYRIO Evo Series 054 055 NBOX ADB-5720SX ABD5720SX NFUSION NUVENIO SD PHOENIX, NUVENIO HD, SOLARIS, NOVA NOW TV NOWTV IM781R IM781 SIGMAONE, P1,P2,P3, SIGMA 2000 RTC56,RKDM SIGMA 2001,2002 SIGMA 450,500,550 PACE 500 Series 001 007 TDC Series DTA Series...
  • Page 13 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST ADMIRAL 072 081 160 161 096 AD NOTAM ADVENT AFFINITY AIWA 141 145 AKAI 070 146 004 148 124 226 104 108 244 AKIO ALARON AMARK 112 127 AMERICA ACTION AMPRO 073 167 ANAM 043 054 056 080 112 131 058 070 004 112 245...
  • Page 14 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST DUMONT 004 073 DWIN 131 132 161 DYNASTY DYNATECH FISHER 007 057 ELECTROBAND ELECTROHOME 024 076 127 ELEMENT 004 110 622 EMERSON 005 028 043 048 076 096 155 004 051 151 153 154 127 121 ENVISION EPSON...
  • Page 15 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST JCPENNEY 004 008 024 030 065 070 101 160 156 127 JENSEN 038 001 034 083 195 159 227 639 KENWOOD 070 001 KLEGG KLOSS 002 059 KREISEN 070 043 154 127 004 106 112 127 086 236 648 LODGENET LOEWE 196 164...
  • Page 16 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST OPTONICA 019 081 ORION 096 201 203 204 205 028 PANASONIC 034 056 080 164 190 230 248 237 240 664 PHILCO 070 003 004 024 056 059 060 063 064 127 164 PHILIPS 164 005 038 093 127 070 003 004 059 199 218 161 232 629...
  • Page 17 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST 004 043 STARLITE SUNBRITE 633 634 635 236 SUNBRITE TV SUPRE MACY SUPREME SYLVANIA 070 003 059 060 063 064 127 160 164 044 056 168 121 231 SYMPHONIC 052 168 SYNTAX OLEVIA 219 004 161 144 160 TANDY TATUNG...
  • Page 18 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST ADMIRAL 025 053 AIKO AIWA 034 101 163 AKAI 016 043 046 124 142 146 AMERICA ACTION AMERICAN HIGH AMPRO ANAM ASHA AUDIO DYNAMICS 012 023 039 043 AUDIOVOX BEAUMARK BROKSONIC 035 037 044 046 153 231 025 CALIX CANON 028 031...
  • Page 19 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST KENWOOD 014 034 047 048 023 KODAK 031 101 101 123 012 013 114 LLOYD LOGIK 034 003 009 017 101 MAGIN MAGNASONIC MAGNAVOX 067 031 034 041 068 154 160 MARANTZ 067 069 031 012 023 MARTA MATSUI 027 030...
  • Page 20 MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST SAMSUNG 040 032 107 109 017 113 115 124 122 159 SANKY SANSUI 043 048 022 034 153 025 SANYO 003 010 007 014 134 040 SCOTT 037 044 046 131 017 159 SEARS 003 008 009 010 013 014 017 081 101 031 034 SHARP...
  • Page 21 DVD(VCR) MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST ADCOM AIWA 210 214 AKAI ALPINE ANTHEM APEX DIGITAL 240 197 247 248 196 ARCAM 165 148 AUDIOVOX BOSE 244 245 CAMBRIDGE AUDIO 224 145 360 CARY AUDIO DESIGN 249 149 CLASSE COBY CYBERHOME 170 212...
  • Page 22 DVD(VCR) MAKER(BRAND) NAME CODE NUMBER (3 DIGIT) LIST MEMOREX MERIDIAN MINTEK 240 196 MITO MITSUBISHI MOXI MYRYAD 198 182 092 ONKYO 207 236 128 OPPO OPTIMUS ORITRON PANASONIC 076 173 184 219 192 103 104 PARASOUND PHILIPS 074 164 176 177 191 195 209 127 PIONEER 175 180 187 221 223 093 364 POLAROID...
  • Page 24 OCE-0009E Rev 09...
