- Page 1 AmPlus 100 and AmPlus 50 Business Music Amplifiers Installer’s Guide...
-
Page 2: Information You Should Read
9. Be Careful with Accessories – Mount the product only as recom- mended by Bose Corporation. Do not put this product on an un- stable cart, stand, tripod, bracket, or table. The product may fall, causing serious injury to a person or damage to the product. -
Page 3: General Cabling Information
Information You Should Read 10. Protect the Power Cord – Route all power supply (mains) cords so that they are not likely to be walked on or pinched. Pay particular attention to cords at plugs, at outlets on the product, and at the point where the cord connects to the product. 11. -
Page 4: Warranty Period
Refer to the table of contents for the location of your amplifier’s information. The AmPlus 100 and AmPlus 50 amplifiers are each available in two versions: A 70V constant voltage audio output version for use with 120V AC mains supply, and a 100V constant voltage audio output version for use with 220-240V AC mains supply. -
Page 5: Table Of Contents
Installing the remote control ................7 All About The AmPlus 100 Amplifier ............... 8 AmPlus 100 amplifier controls ................8 AmPlus 100 Amplifier Configurations ..............10 AmPlus 100 Amplifier Specifications ..............15 All About The AmPlus 50 Business Music Amplifier ..........16 AmPlus 50 amplifier controls ................ -
Page 6: Getting Started
Getting Started What you bought The amplifier comes in one box and the accessory kit comes in another. Figure 1 Amplifier Product contents Declaration of Conformity Power cord Remote control Warranty Rubber feet card Quick connectors Installer’s Guide Owner’s Guide Amplifier comparison This table shows the major features of the different amplifiers. -
Page 7: Removing The Amplifier's Feet
Getting Started Removing the amplifier’s feet Use a screwdriver to loosen the foot and pull it out. Installing the option cards ® Refer to the installation instructions that come with the equalizer card, Opti-voice page card, and Opti-source source card. Using the quick connectors The quick connectors are supplied so you can connect the amplifier to sources and other equipment. -
Page 8: All About The Amplus 100 Amplifier
1. This pot may also be used to fine-tune the bass level when using the AmPlus 100 amplifier to drive a 70/100V load connected to the 70/100V output and a Model 1B Acoustimass module connected to... - Page 9 1 (+) pin and the ground pin. Set the internal remote volume switch (Figure 4) to 1_REMOTE. When using the AmPlus 100 amplifier for 2- zone applications, connect a second remote to the zone 2 (+) pin and ground pin. Set the internal remote volume switch to 2_REMOTE.
-
Page 10: Amplus 100 Amplifier Configurations
AmPlus 100 Amplifier Configurations AmPlus 100 Amplifier Direct-coupled Model 1B Installation Source Left 1 Right 1 Model 1B AmPlus™100 Amp Module Right 2 Left 2 Remote Volume Control INPUTS A INPUT LEVEL BASS REMOTE LINE OUTPUT POWER AMPLIFIER MODE LEVEL... - Page 11 AmPlus 100 Amplifier Configurations AmPlus 100 Amplifier 70/100V/Model 1B Installation Source AmPlus™ 100 Model 1B Module Remote Volume Control INPUTS A INPUT LEVEL BASS REMOTE LINE OUTPUT POWER AMPLIFIER MODE LEVEL VOLUME Zone 2 ZONE 1 ZONE 2 ZONE 1...
- Page 12 AmPlus 100 Amplifier Configurations AmPlus 100 Amplifier Simple Monophonic Installation Source AmPlus™ 100 Remote Volume Control INPUTS A INPUT LEVEL REMOTE LINE OUTPUT POWER AMPLIFIER BASS MODE VOLUME LEVEL Zone 2 ZONE 1 ZONE 2 ZONE 1 ZONE 2 70/100V...
- Page 13 AmPlus 100 Amplifier Configurations AmPlus 100 Amplifier Large Monophonic Installation Source 1 Source 2 AmPlus™ 100 Remote Volume Control AmPlus™ 100 INPUTS A INPUT LEVEL BASS REMOTE LINE OUTPUT POWER AMPLIFIER MODE LEVEL VOLUME Zone 2 ZONE 1 ZONE 2...
-
Page 14: Amplus100 Amplifier Configurations
AmPlus 100 Amplifier Configurations AmPlus 100 Amplifier With Two 70/100V Zones Installation Source Zone 1 Remote Volume Control AmPlus™ 100 Zone 2 Remote Volume Control Accessory 70/100V Transformer INPUTS A INPUT LEVEL BASS REMOTE LINE OUTPUT POWER AMPLIFIER MODE LEVEL... -
Page 15: Amplus 100 Amplifier Specifications
AmPlus 100 Amplifier Specifications Power output LED indicator Stereo: 65W per channel into 4 Power: front panel 50W into 8 AC power consumption 70V bridged mono: 100W into 49 100V bridged mono: 100W into 98 120V~AC, 50/60Hz, 350W max 70V/4 : 50W @70V output into 98 220-240V~AC, 50/60Hz, 350W max 65W @Ch2 output into 4 100V/4 : 50W @70V output into 196... -
Page 16: All About The Amplus 50 Business Music Amplifier
All About The AmPlus 50 Amplifier AmPlus 50 amplifier controls Figure 5 INPUTS A LEVEL BASS REMOTE POWER AMPLIFIER GAIN VOLUME AmPlus 50 amplifier controls MODE 70/100V 4-16 -40 dB -40 dB OFF +10 70/100V 4-16 Inputs – The AmPlus 50 amplifier comes with two balanced inputs. They can be left and right from a stereo source;... -
Page 17: Amplus 50 Amplifier Configuration
AmPlus 50 Amplifier Configuration AmPlus 50 Amplifier Simple Monophonic Installation Source AmPlus™ 50 Remote Volume Control INPUTS A LEVEL BASS REMOTE POWER AMPLIFIER GAIN VOLUME MODE 70/100V 4-16 -40 dB -40 dB 70/100V 4-16 Internal Switch Settings: High Pass Filter: OFF Tap settings: Remote Source... -
Page 18: Amplus 50 Amplifier Specifications
1. Mono into 4 load Remote volume control 2. Mono into 70/100V load Turn on/off muting 3. As an extension to the Clip detection and limiter AmPlus 100 amplifier Short circuit protection DC offset protection Input impedance Thermal limiting 32k balanced... -
Page 19: Bose Corporation
