BH FITNESS TS 2 Owner's Manual
Hide thumbs Also See for TS 2:

Advertisement

BH Fitness
Owner's Manual
BH FITNESS
20155 Ellipse, Foothill Ranch, CA 92610
Phone: 949-206-0330
Fax: 949-206-0013
Email:
fitness@bhnorthamerica.com
Web:
www.BHFitnessUSA.com
TS 2
Treadmill
BH 12/6/12
V.20100429

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for BH FITNESS TS 2

  • Page 1 BH Fitness TS 2 Treadmill Owner’s Manual BH FITNESS 20155 Ellipse, Foothill Ranch, CA 92610 Phone: 949-206-0330 Fax: 949-206-0013 Email: fitness@bhnorthamerica.com Web: www.BHFitnessUSA.com BH 12/6/12 V.20100429...
  • Page 2 Please read this entire manual carefully before using your treadmill. This will allow you to get a full understanding of all the features your BH FITNESS treadmill provides. If you have any questions or concerns, please contact BH FITNESS or any authorized BH FITNESS distributors in your area.
  • Page 3: Table Of Contents

    4. WORKOUT PROGRAMS ................16 5. CALCULATING YOUR TARGET HEART RATE ...........34 6. PREVENTIVE MAINTENANCE..............35 7. TROUBLESHOOTING .................36 8. WARRANTY....................37 PART LIST......................39 T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 4: Important Safety Instructions

    12. Keep the electrical cord away from heated surfaces. 13. Connect this Treadmill to a properly grounded 110-120V, 15 or 20 Amp dedicated outlet only. 14. Call your service center or BH Fitness with your concerns before taking your treadmill in for repair.
  • Page 5 GROUNDED GROUNDING PIN WARNING! UNDER NO CIRCUMSTANCES SHOULD THE TREADMILL BE ON ITS SIDE Please save these instructions T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 6: Assembly In Structions

    Right Handrail Decoration Cover Power Cord Rear Cover Sleeve Screwdriver Bottle Round Head Philips Screw M4xP0.7x8 Washer Ø6xØ16x1.0t T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 7 T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 8 Note: During assembly, be sure to align the holes of the handrails and the computer rack T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 9 Philips Self Tapping Screw (e) on each side. Note: Be aware not to pinch or damage the wires/cables during the assembly T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.bhnorthamerica.com • Phone 949-206-0330 • Fax 949-206-0013 BHFitnessUSA...
  • Page 10 Note: While connecting the cables, be sure to match their colors: red to red, white to white, etc. T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 11: Treadmill And Console

    Keep the treadmill at that angle and wheel the unit as required. SAFETY KEY & CLIP Your BH Fitness treadmill is equipped with a safety key that will disable the treadmill if it is not in place. You should attach the clip end to your clothing.
  • Page 12 Do not hit the cylinder T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 13 24 inches at the rear of the treadmill. 2. Store the unit in a dry place away from direct sunlight and temperature changes. T S2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 14: Key Functions

    CALORIES – This reading is the amount of body heat in calories burned during your workout. As with all pieces of exercise equipment, this is an estimated value. T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 15 3. For safety reasons, the incline function of this systemwill return to level zero upon starting an exercise or when the STOP key was pressed T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 16: Workout Programs

    START/READY status, press and hold the STOP again for 3 to 5 seconds until the console beeps. T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 17 9 HOLES mode does not have WARM UP or COOL DOWN. When distance reaches 2.17 miles, the motor will stop and message ”End” will display. T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 18: Program Mode

    P7 Weight Loss LEVEL Preset 1 Range 1~10 step 1 Time Preset 30min Range 20~99min step 1 min T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 19 Time Preset 32min Range 20~99min step 1 min PROGRAM has 32 segments in all (SE01~SE32) and all the pre-set values are the lowest value T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 20 . If pulse continues to be missing for 30 seconds, the program will stop and exit to Start/Ready status. T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 21 Wireless pulse has first priority T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 22 WORKOUT PROGRAMS (cont’d) T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 23 WORKOUT PROGRAMS (cont’d) T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 24 WORKOUT PROGRAMS (cont’d) T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 25 WORKOUT PROGRAMS (cont’d) T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 26 WORKOUT PROGRAMS (cont’d) T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 27 WORKOUT PROGRAMS (cont’d) T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 28 WORKOUT PROGRAMS (cont’d) T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 29 WORKOUT PROGRAMS (cont’d) T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 30 WORKOUT PROGRAMS (cont’d) T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 31 WORKOUT PROGRAMS (cont’d) T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 32 WORKOUT PROGRAMS (cont’d) T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 33 WORKOUT PROGRAMS (cont’d) T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 34: Calculating Your Target Heart Rate

    Remember to consult your family physician or health care professional to develop a well-planned exercise program to fit your health needs. T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 35: Preventive Maintenance

    8 Miles or more / hr = lube every 3 months Check belt condition and if necessary adjust using the instructions above. T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 36: Troubleshooting

    Check if unit is turned on Fuse Check fuses on MCB Insufficient power source Plug unit in a dedicated 120V, 20A outlet T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 37: Part List

    39 Truss Philips Self Tapping Screw 5x25 95 Round Head Philips Screw M5x35 40 Truss Philips Screw M5xP0.8x15 96 Washer Ø6xØ13x1.5t 97 Wheel T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 38 139 Water Bottle 124 Nylon nut M10xP1.5,8t 140 SILICON 125 Side fixed plastic 141 Sound insulation pad T S 1 T S 2 BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610 www.BHFitnessUSA.com • Phone 949-206-0330 • Fax 949-206-0013...
  • Page 40 For more detailed warranty information or to register your product warranty easily online, visit our website at: www.BHFitnessUSA.com FOR WARRANTY REPAIRS, PLEASE DO NOT TAKE YOUR MACHINE BACK TO THE RETAIL STORE. CONTACT BH FITNESS FIRST. BH North America Corporation 20155 Ellipse Foothill Ranch, CA 92610 Phone: 949.206.0330;...
