Hardware Requirements - HP TruCluster Server V5.1B-1 Specification

QuickSpecs

Hardware Requirements

Supported Terminators Supported Terminators Supported Terminators Supported Terminators
and Connectors and Connectors and Connectors and Connectors
Device Device Device Device
H879-AA or 330563-001
H885-AA
H8861-AA
H8863-AA
H8574-A
H8860-AA
341102-001
152732-001
3X-H32CT-AA
Supported Disk Devices Supported Disk Devices Supported Disk Devices Supported Disk Devices
Data Routers and Network Data Routers and Network Data Routers and Network Data Routers and Network
Storage Routers Storage Routers Storage Routers Storage Routers
TruCluster Server supports the following terminators and connectors:
Every SCSI and Fibre Channel storage disk currently sold by HP that appears in the supported options list for a supported
AlphaServer are supported for use in a cluster on a shared bus.
Some legacy disk devices are not supported for use on a shared bus. TruCluster Server supports the following list of disk
devices on shared storage. Any SCSI or Fibre Channel storage disk manufactured by HP later than the ones in the following
list, and appearing in the supported options list for a supported AlphaServer, is supported.
RZ26-VA Narrow
RZ26L-VA Narrow
RZ26L-VW Wide
RZ26N-VA Narrow
RZ26N-VW Wide
RZ28-VA Narrow
RZ28-VW Wide
RZ28B-VA Narrow
The HP Fibre Channel Tape Controller, Modular Data Router (MDR), and Network Storage Router (NSR) are Fibre Channel-
to-SCSI bridges that allow a SCSI tape device to communicate with other devices on a Fibre Channel. Tapes and tape
libraries supported by the MDR or NSR are supported for use in a TruCluster when deployed on the MDR or NSR.
The following tape controllers and modular data routers are supported on shared storage:
340654-001 Fibre Channel Tape Controller
152975-001 Fibre Channel Tape Controller II
163082-B21 (3R-A2673-AA) Fibre Channel Modular Data Router (MDR)
163083-B21 (3R-A2774-AA) Fibre Channel Modular Data Router (MDR)
218240-B21 (3R-A3292-AA) Fibre Channel Modular Data Router (MDR)
218241-B21 (3R-A3312-AA) Fibre Channel Modular Data Router (MDR)
280823-B21 (3R-A3747-AA) Network Storage Router (N1200)
262672-B21 (3R-A3746-AA) Network Storage Router (E1200)
286694-B21 (3R-A3871-AA) Network Storage Router (E1200)
262665-B21 (3R-A3935-AA) Network Storage Router (E2400)
262664-B21 (3R-A3745-AA) Network Storage Router (E2400)
262653-B21 (3R-A3740-AA) Network Storage Router (M2402)
262654-B21 (3R-A3741-AA) Network Storage Router (M2402)
1 Note that TruCluster support for tape libraries with N1200, E1200, E2400, and M2402 is restricted to DLT and SDLT
based libraries only, i.e. MSL5026SL/DLX, ESL9198SL/DLX, and ESL9326SL/DL/DLX.
For a list of tape automation devices supported by HP Nearline Storage, go to
http://h18006.www1.hp.com/products/storageworks/ebs/index.html
DA - 11444 Worldwide — Version 4 — December 8, 2003
HP TruCluster Server V5.1B-1 HP TruCluster Server V5.1B-1 HP TruCluster Server V5.1B-1 HP TruCluster Server V5.1B-1
Description Description Description Description
HD68 terminator
HD68 tri-link connector
VHDCI tri-link connector
VHDCI terminator
50-pin LD terminator
50-pin LD terminator
50-pin HD terminator
VHDCI 68-pin LVD terminator
LVD U160 Terminator
RZ28D-VA Narrow
RZ28D-VW Wide
RZ28L-VA Narrow
RZ28L-VW Wide
RZ28M-VA Narrow
RZ28M-VW Wide
RZ29-VA Narrow
RZ29-VW Wide
1
1
1
1
1
1
1
to see the the
RZ29B-VA Narrow
RZ29B-VW Wide
RZ29L-VA Narrow
RZ29L-VW Wide
RZ40-VA Narrow
RZ40-VW Wide
RZ40L-VA Narrow
RZ40L-VW Wide
EBS Compatibility Matrix.
Page 16
