Storage Hardware Requirements
Supported Fibre Channel Supported Fibre Channel Supported Fibre Channel Supported Fibre Channel
Hardware Hardware Hardware Hardware
Device Device Device Device
KGPSA-BC
KGPSA-CA
KGPSA-DA
KGPSA-EA (302784-B21, FCA2384)
HSG60
HSG80
HSV110
XP128/1024
XP512/48
MSA1000 (3R-A4328-AA, 201723-B22)
HSG60 and HSG80 controllers may be contained in many cabinet configurations including MA6000, RA8000, MA8000, ESA12000, EMA12000, and
EMA16000. HSV110 controllers may be contained in many cabinet configurations. Any model of the Enterprise Virtual Array (EVA) product set based on the
HSV110 controller is supported.
For more information on the supported XP array hardware, see the XP/Tru64 Connectivity Streams at the following URLs:
http://www.XP128/1024 Connectivity Streams and Other Documents.com
http://www.XP48/512 Connectivity Streams and Other Documents.com
Fibre Channel Arbitrated Fibre Channel Arbitrated Fibre Channel Arbitrated Fibre Channel Arbitrated
Loop Support Loop Support
Loop Support Loop Support
Supported SCSI Supported SCSI Supported SCSI Supported SCSI
Controllers Controllers Controllers Controllers
Supported SCSI Signal Supported SCSI Signal Supported SCSI Signal Supported SCSI Signal
Converters Converters Converters Converters
Signal Converter Signal Converter Signal Converter Signal Converter
DWZZA-AA
DWZZA-VA
DWZZB-AA
DWZZB-VW
DS-DWZZH-03
DS-DWZZH-05
3X-DWZCV-BA
TruCluster Server supports the following Fibre Channel hardware. For more information on the supported Fibre Channel
solutions, see the TruCluster Server Release Notes and the Cluster Hardware Configuration manual. For a list of supported
Fibre Channel switches, see the SAN Product Support Tables for the SAN Design Reference Guide
http://www.hp.com/products/StorageWorks/san/documentation.html.
TruCluster Server supports Fibre Channel arbitrated loop for clusters with a maximum of two members only. The KGPSA-CA
is the only Fibre Channel adapter supported for arbitrated loop configurations. The DS-SWXHB-07 seven-port Fibre
Channel hub is required to build an arbitrated loop configuration and is restricted to use with DS10, DS20, DS20E, and
ES40 systems. The other AlphaServers including the DS10L and ES45 systems are not supported for arbitrated loop.
The systems are connected to shared SCSI buses using an adapter from the following list. The TruCluster Server Cluster
Hardware Configuration manual and Release Notes provide more information regarding SCSI controller configuration,
respectively:
KZPSA - PCI to Fast Wide Differential SCSI-2 adapter
KZPBA-CB/CC - PCI to UltraSCSI wide differential adapter
1
KZPEA-DB - LVD Multimode U3 PCI SCSI Adapter
NOTE: KZPEA only supported for shared bus with one or two hosts. TruCluster V5.1B-1 Initial Patch Kit (IPK) is required. NOTE: NOTE: NOTE:
TruCluster Server supports the following SCSI signal converters. The Cluster Hardware Configuration manual provides
information regarding supported SCSI signal converters configuration.
DA - 11444 Worldwide — Version 4 — December 8, 2003
HP TruCluster Server V5.1B-1 HP TruCluster Server V5.1B-1 HP TruCluster Server V5.1B-1 HP TruCluster Server V5.1B-1
Description Description Description Description
PCI-to-Fibre Channel host adapter
PCI-to-Fibre Channel host adapter
PCI-to-Fibre Channel host adapter
2Gb PCI or PCI-X to FibreChannel Host Bus Aadapter
Array Controller
Array Controller
Array Controller
Array Controller
Array Controller
Storage Works modular SAN array
Description Description Description Description
Standalone unit, single-ended/narrow to differential/narrow
SBB, single-ended/narrow to differential/narrow
Standalone unit, single-ended/wide to differential/wide
SBB, single-ended/wide to differential/wide
UltraSCSI hub
UltraSCSI hub
HVD to LVD converter
at the following URL:
