  • Page 1 VISION 9200 R9001290 OWNER'S MANUAL...
  • Page 3 BARCO PROJECTION SYSTEMS VISION 9200 R9001290 OWNER'S MANUAL Date : Rev : Art. No. : 280497 R5975338...
  • Page 4 Due to constant research, the information in this manual is subject to change without notice. Produced by BARCO NV, April 1997. All rights reserved. Trademarks are the rights of their respective owners. Printed in Belgium BARCO nv/Projection Systems Noordlaan 5...

  • Page 5: Table Of Contents

    Table of Contents TABLE OF CONTENTS TABLE OF CONTENTS ................................... i-1 SAFETY INSTRUCTIONS ................................1-1 REMARQUE SUR LA SÉCURITÉ ..............................1-2 UNPACKING AND DIMENSIONS ..............................2-1 Unpacking ..................................... 2-1 Projector dimensions ................................2-1 Battery installation in the RCU............................... 2-2 INSTALLATION GUIDELINES ................................

  • Page 6: Table Of Contents

    Table of Contents Gain adjustment per color ..............................9-2 Smoothness ..................................9-2 Still Video ....................................9-2 Sync ..................................... 9-2 Color balance ..................................9-2 Screen operations ................................. 9-3 Zoom/pan ....................................9-3 Configure ....................................9-7 Conversion .................................... 9-7 Geometry ....................................9-7 SERVICE MODE ..................................10-1 How to activate the password function ..........................

  • Page 7: Safety Instructions

    The use of shielded cables is required to comply within the limits of projector. Record these numbers in the spaces provided below. Refer Part15 of FCC rules and EN55022. to them whenever you call upon your BARCO dealer regarding this product. General safety instructions.

  • Page 8: Remarque Sur La Sécurité

    L’installation et les réglages préliminaires devraient être faits par du - Brancher l’ appareil sur une autre prise de telle sorte que l’appareil personnel qualifié BARCO ou par des agents autorisés du service et le récepteur se trouvent sur différents circuits électriques.
  • Page 9 Where possible, care should also be taken to ensure that the floors risk of electric shock! Refer all projector service to a qualified BARCO and walls of the room in which the projector is to be installed are non- service center.
  • Page 10 évite tout endommagement au projecteur par la foudre ou par des N’utiliser que des lampes de projection indiquées par BARCO ou un impulsions sur le secteur. agent autorisé de BARCO ou un service.

  • Page 11: Unpacking And Dimensions

    Unpacking and Dimensions UNPACKING AND DIMENSIONS Unpacking To open the banding, pull on the clip as shown in the first drawing. Pull To open Take the projector out of its shipping carton and place it on a table. For transportation, the projector is mounted on a wooden board with 3 bolts. Use a 13 mm wrench to remove these bolts. When using the projector as a table mounted configuration, always mount the 3 supporting feet (see drawing below).

  • Page 12: Battery Installation In The Rcu

    Unpacking and Dimensions Battery installation in the RCU. A battery (not yet installed to save the battery life time) is delivered inside the plastic bag with the power cord. To install the battery, remove the battery cover on the backside of the remote control by pushing the indicated handle a little to the bottom of the RCU.

  • Page 13: Installation Guidelines

    Installation Guidelines INSTALLATION GUIDELINES Installation guidelines Careful consideration of things as image size, ambient light level, projector placement and type of screen to use are critical to the optimum use of the projection system. Max. ambient temperature : 40 °C. * Environment Do not install the projection system in a site near heat sources such as radiators or air ducts, or in a place subject to direct sunlight,...

  • Page 14: Where To Install The Projector

    Installation Guidelines * Where to install the projector? Inputs and computer video format input compatibility : Some examples : Definitions of the Abbreviation on drawings VIDEO and S-VIDEO B = Distance between ceiling and top of the screen or between floor and bottom of the screen. COMPONENT VIDEO RGB ANALOG with STANDARD SYNC (SYNC ON GREEN or A = Correction value, distance between bottom side of projec-...

  • Page 15: Location And Fucntions Of Control

    Location and Functions of Control LOCATION AND FUNCTIONS OF CONTROL Front panel terminology Th is d evice complies wit h Part 15 o f t he F CC rule s. Ope ration is subject to f ollo wing tw o co ndit ions : (1 ) Th is device may not cau se harmful int erf eren ce (2 ) Th is device must accept an y interference re ceived including inte rference tha t may cau se u ndesired ope ration...
  • Page 16 Location and Functions of Control b. Remote control This remote control includes a battery powered infrared (IR) transmit- ter that allows the user to control the projector remotely. This remote control is used for source selection, control, adaptation and set up. It includes automatic storing of : Remote Control (RCU) - picture controls (Brightness, Sharpness...) - settings...

  • Page 17: Installation Set Up

    Installation Set Up INSTALLATION SET UP The projector can be installed to project images in four different configurations : front/table, front/ceiling, rear/table and rear/ceiling. Rear/Ceiling Front/Ceiling Rear/Table Front/Table When switching on and the projector displays an image as illustrated below, an adaptation of the projector configuration is required.
  • Page 18 Installation Set Up Push the control disk up or down to highlight Systems Settings and press ENTER . MAIN MENU ENTER displays the System Settings menu. EXIT returns to operational mode. Picture Control Audio Control System Settings File service Service Mode 832b Push the control disk up or down to highlight Installation and press ENTER .

  • Page 19: Connections

    Connections CONNECTIONS Power (mains) cord connection Use the supplied power cord to connect your projector to the wall outlet. Plug the female power connector into the male connector at the front of the projector. The power input is auto-ranging from 200 to 240 VAC. This projector may be connected to an IT-power system.

  • Page 20: Switching To Stand-By

    When OK (ENTER) is pressed to go on, the warning will be repeated every 30 min. The total lifetime of the lamp for a safe operation is 1000 hours max. (normal power mode). Do not use it longer. Replace always with a same type of lamp. Call a BARCO authorized service technician for lamp replacement.

  • Page 21: Video/S-Video Input Module

    Connections Video/S-video input module To the Video input : Composite video signals from a VCR, OFF air signal decoder, etc... 1 x BNC 1.0Vpp ± 3 dB VIDEO/S-VIDEO INPUT To the S-Video input : Audio input not S-Video input Video input available Separate Y-luma/C-chroma signals for higher quality playback of Super VHS-signals.

  • Page 22: Rgb Analog Input Module

    Connections RGB analog input module. RGB analog input terminals with separate Horizontal and Vertical DIAGNOSTICS CODE IR-RECEIVER IR-ACKNO WLEDGED sync inputs(RGB-HV), with Composite sync input(RGB-S) or with RS232 OUT Sync signals on green(RGsB). IR-RECEIVED Always use an interface when a computer and local monitor have to be connected to the projector.

  • Page 23: Component Input Module

    Connections Push the control disk key up or down to select System Settings and press ENTER . MAIN MENU Picture Control Audio Control System Settings File service Service Mode Use the control disk to select Input Slots by pushing up or down and press ENTER .

  • Page 24: Rgb3S/Rg3Sb Input Module

    Connections Straps on module level : Floating or non floating input Non-Floating Floating or non-floating input. R-Y : J3 : strap "yes" : non floating strap "no" : floating Y : J4 : strap "yes" : non floating strap "no" : floating Floating B-Y : J5 : strap "yes"...

  • Page 25: Connecting A Computer, E.g. Ibm Pc (Or Compatible), Apple Macintosh To The Rs 232 Input Of The Projector

    Connections Straps on module level : Sync selection Separate sync Sync on green Floating or non-floating input. Red : J3 : strap "yes" : non floating strap "no" : floating Green : J4 : strap "yes" : non floating strap "no" : floating Blue : J5 : strap "yes"...

  • Page 26: Connecting A Rcvds 05 To The Projector

    In addition, the audio signal proper to the source, can be switched to an audio amplifier. Order number : R9827890 For more information about the use of the VS05, consult the VS05 owner's manual, BARCO order number : R5975245. Control room Projection room 5975338 BARCOVISION 9200 280497...

  • Page 27: Controlling

    Controlling CONTROLLING The projector can be controlled with c) Point the front of the RCU directly at one of the IR sensors of the a. The RCU projector. b. The hardwired RCU (cable is not included) IR sensor c. The local keypad. Ceiling Controlling the projector with the RCU and the hardwired RCU is IR-RECEI...

  • Page 28: How To Display A Projector Address

    Controlling switch value Example : address 83 DIP switch 1 2 3 4 5 6 7 8 setting 1 1 0 0 1 0 1 0 Summary : 1x1 + 1x2 + 0x4+ 0x8+ 1x16 + 0x32 + 1x64 + 0x128 = 83 b.

  • Page 29: How To Get Source Information

    Controlling Brightness Control A correct 'brightness' setting is important for good image reproduc- tion. Use the + button for a higher brightness. Use the - button for a lower brightness. Contrast Control A correct 'contrast' setting is important for good image reproduction. Adjust the contrast to the level you prefer, according to room lighting conditions.

  • Page 30: How To Get A Summary Of Your Projector

    Attention : the total lifetime of the lamp for a safe operation is 1000 hours maximum. Do not use it longer. Always replace the lamp with an original BARCO lamp kit. - Projector Serial number : indicates the fabrication number of the projector.

  • Page 31: Source Set Up

    Source Set Up SOURCE SET UP Input selection Use the numeric keys on the RCU or use the local key pad to select the corresponding input slot. The source settings has to be installed for each source when these sources are displayed for the first time.

  • Page 32: Edit File

    Source Set Up Push the control disk up or down to select the most fitting file and press ENTER to select. When scrolling through the files, the image will be adapted according the settings of the selected file (on line adaptation). When the best fitting image is displayed, press ENTER to select this file.
  • Page 33 Source Set Up During the installation of a file with LOAD, the horizontal period, the EDIT FILE (Horizontal) total number of vertical lines and the interlaced mode are automati- Total : cally measured and filled in in the menu table. These values will be 865 pixels available when starting up the EDIT procedure of an active file.

  • Page 34: Rename

    Source Set Up Vertical refresh [sync/async] : The way of updating the image information on the LCD panels. * For sources with a vertical frequency up to 60 Hz : the vertical refresh rate is the same as the vertical frequency of the incoming source.

  • Page 35: Move

    Source Set Up Move To move a selected file to the file with the name and extension given in the TO area. Use the control disk to select MOVE and press ENTER . The move FILE SERVICE menu will be displayed. Load Edit Rename...
  • Page 36 Source Set Up 5975338 BARCOVISION 9200 210497...

  • Page 37: Picture Control In Adjustment Mode

    Picture Control in Adjustment Mode PICTURE CONTROL IN ADJUSTMENT MODE The picture control menu is split up in two parts : Signal operations Screen operations. Signal operations : to manipulate the video signal, e.g. sync slow/fast, color balance adjustment etc. Screen operations : to manipulate the projection window and the picture, e.g.

  • Page 38: Gain Adjustment Per Color

    Picture Control in Adjustment Mode Gain adjustment per color If the obtained color balance is not yet correct, adjust with the separate gain controls until the desired color balance is obtained. Smoothness The lower the smoothness value, the sharper the image. The influence of this setting is visible on high density image with small characters.

  • Page 39: Screen Operations

    Picture Control in Adjustment Mode Screen operations Select the Picture Control menu on the Main menu by pushing the control disk up or down. Press ENTER to select. Push the control disk up or down to select Screen operations . Press MAIN MENU ENTER to select.
  • Page 40 Picture Control in Adjustment Mode [window] moves the window upwards [window] moves the window downwards [window] stretches the window in the horizontal direction. 870 870 [window] Compresses the window in the horizontal direction. [window] stretches the window in the vertical direction. [window] compresses the windows in the vertical direction.
  • Page 41 Picture Control in Adjustment Mode [window] reduces the window, both of horizontal and vertical direc- tions simultaniously. [window] reset button, brings the window to its maximum dimensions. Picture The picture can be moved, enlarged, reduced within a created window. [picture] Displays the covered info on the left side.
  • Page 42 Picture Control in Adjustment Mode [picture] Compresses the picture in the horizontal direction. [picture] Stretches the picture in the vertical direction. [picture] Compresses the picture in the vertical direction. [picture] Zooms in the picture, both horizontal and vertical di- rections simultanious [picture] Zooms out the picture, both horizontal and vertical direc-...

  • Page 43: Configure

    Picture Control in Adjustment Mode Configure The configure menu contains two toggle functions : geometry and SCREEN OPERATIONS conversion . Use the control disk to select Configure and press ENTER . Zoom/Pan Geometry (off) Configure 868b Conversion All incoming signals are internally converted to be displayed on its CONFIGURE maximum possible dimensions.
  • Page 44 Picture Control in Adjustment Mode Enlarge the upper part of the projected image in horizontal way. Reduce the upper part of the projected image in horizon- tal way. Enlarge the lower part of the projected image in horizontal way. Reduce the lower part of the projected image in horizon- tal way.

  • Page 45: Service Mode

    Service Mode SERVICE MODE The service mode offers : - test patterns such as convergence patterns (green, red on green, blue on green and hatch patterns). - alignments for the decoder circuit such as luminance delay, comb filter, etc. (more info in service manual) - modifying password - resetting the lamp run time.

  • Page 46: Convergence Adjustment Of The Lcd Panels

    Service Mode Factory programmed password : 0000 SERVICE MODE Modify Password Reset Lamp Run Time Lamp Run Time History Convergence Display Settings Decoder Settings Color Balance I2C Device Test Convergence adjustment of the LCD panels. Every LCD panel has 6 adjustment screws. By turning these screws you change the relative position of the panels and converge the image.
  • Page 47 Service Mode The pattern shows lines of one pixel. Near six lines on the displayed pattern, a screw is drawn with a number next to it (e.g. if displayed in green = corresponding with the screws and numbers on the green LCD panel). When turning a screw in the direction marked by the arrow above the displayed screw on the screen, the line on the screen moves in the direction of the straight arrow.
  • Page 48 Service Mode Two possibilities : 1) distance between red lines is smaller than distance between green lines. Turn screw 5 and 6 clockwise until distance between lines 5 and 6 is the same for the red and green lines. 2) distance between red lines is greater than distance between green lines.

  • Page 49: Modify Password

    Service Mode Modify password To change your password, highlight 'Modify password' and press ENTER to start up the password modification procedure. Enter your old password with the digit keys. After the fourth digit is entered, the next modify password menu is displayed. MODIFY PASSWORD Enter Old Password : ---- Your new password will be asked if your old password is correct.
  • Page 50 Service Mode When Reset Lamp Run Time is selected in the Service Mode menu, the following warning will be displayed : Risk of electrical shock. Reset lamp run time is reserved to qualified WARNING service personnel. RISK OF ELECTRICAL SHOCK If you are not qualified, press EXIT to cancel the reset operation.

  • Page 51: Standard Source Set Up Files

    Standard Source Set Up Files STANDARD SOURCE SET UP FILES Standard source set up files. Standard preprogrammed set up files. Name : name of file, contains the settings NAME RESOLUTION FVERT FHOR FPIX PTOT PACT LTOT LACT Resolution : image resolution, when fol- lowed by ...I means interlaced.

  • Page 52: Appendix A : Standard Source Set Up Files

    Standard Source Set Up Files 5975388 BARCOVISION 9200 210497...

  • Page 53: Appendix B : Battery Replacement In The Rcu

    Battery Replacement in the RCU BATTERY REPLACEMENT IN THE RCU Battery replacement in the RCU. Remove the battery cover on the backside of the remote control by pushing the indicated handle a little to the bottom of the RCU. Lift up the top side of the cover at the same time.

  • Page 54: Appendix C : Lenses

    Lenses LENSES Lens holder Fastener ring Focusing the lens Loosen the fastener ring of the lens by turning counter clockwise. Focus the image by turning the lens barrel to the left or the right. Attention : Do not turn out the lens too far, otherwise it will fall out of Lens the lens holder.
  • Page 55 Lenses Lenses This APPENDIX gives an overview of the tables and formulas for the available lenses for the BARCOVISION 9200. The next lenses are available : Name length lens diam. lens weight order number mm (inch) mm (inch) kg (lbs) HD(1.2:1) 253 (9.96) 189 (7.44)
  • Page 56 Source Numbers 90 - 99 SOURCE NUMBERS 90 - 99 Source numbers 90 - 99 These source numbers do not correspond to physical inputs. They can only be used when the projector is equipped with a RCVDS 05 or VS05. An additional adjustment file can be created for these source numbers. This file can contain different settings.
  • Page 57 Insert Card INSERT CARD INPUT SOURCES INPUT SOURCES PROJECTOR PROJECTOR INPUT SOURCES INPUT SOURCES RCVDS RCVDS 5975338 BARCOVISION 9200 210497...
