Initial Assembly and Setting Up

Typ.2 small eye
bolts
Fig 1
Typ.2 M6 x 12mm
caphead bolt
Fig 2
Fence mounting
bracket
Typ. 2 elongated fence
support brackets
Planer fence base
Typ. 2 handled
clamp nuts
Fig 3
Fence mounting
bracket
Fence securing
clamp
NOTE: The pictures in this manual show the AW106PT2, the
AW128PT & AW168PT is exactly the same but on a larger scale.
